6.2 Navigating the menus

36 • Chapter 6 - Using the Drive’s Control Keys
0.0 Hz Output frequency
d000
Menu of read-only parameters (display)
S000
Menu of basic drive start up parameters
I000
Menu of input/output drive settings (digital/analog)
F000
Menu of multi frequencies and ramps settings
-
P000
Menu of read/write drive parameters
A000
Menu of PID function settings
C000
Menu of control-type parameters (Save, Load default, etc.)
Frequency ref 0
F100
E
d.000 Output frequency
10.0 Hz
Increase
0.0 Hz
Decrease
- 200 Hz
To confirm
E
new setting
desired
