TDE MACNO DVS200 User Manual page 105

Code Name
P .340 Undervoltage thr
P .341 Max pwrloss time
P .342 UV alarm storage
P .343 UV Trip mode
User Manual
Vdc
Internal
ctrl setpoit
Rated value
Internal
ctrl setpoit
UV threshold
Speed
Set speed
Dig out
Emg
stop
Figure 7.6.12: Emergency Stop
(F.208 - Dec time 4
[Code] & Function.
[0] Disable
[1] Enable
[0] Disabled
[1] CoastThrough
[2] Emg Stop
Mains loss
b
a
UV alarm
Zero speed
Default
0
0
1
0
Run command
**
Emg Stop
MIN MAX Unit
0 80 % of P .061
0 25 sec
0 1
0 2
Chapter 7 - Parameters Description • 105
Variation IPA
462
0,1 463
464
491
