8.4. Example Connection Diagrams

Diagram 1
P-16 = 0 – 10V,
4- 20mA, etc.
Diagram 5
(NO) (NC)
Close Open
Start Stop
Diagram 9
(NO) (NC) (NO)
Speed Open Speed
 
E-Trip
Diagram 13
(NO) (NC) (NO)
Close Open Close
FWD Stop REV
Optidrive Compact-2 Engineering Guide Issue 07.docx
Diagram 2
Diagram 6
(NO) (NC) (NO)
Close Open Close
FWD Stop REV
Diagram 10
(NO) (NC)
Diagram 14
www.invertekdrives.com
Diagram 3
(NC) P-16 = 0 – 10V
4- 20mA, etc.
Diagram 7
(NC)
Open Fast Stop
P-24
Diagram 11
(NC)
Open
Trip
Diagram 15
P-47= P-16=
0-10V 0-10V
4-20mA 4-20mA
Diagram 4
P-47 = 0 – 10V, P-16 = 0 –
10V,
4- 20mA, etc. 4- 20mA, etc.
Diagram 8
(NO) (NO)
Speed
 
Diagram 12
(NO) (NC) P-47= P-16=
Close Open 0-10V 0-10V
Start Stop 4-20mA 4-20mA
Diagram 16
(NC) P-16=
Open 0-10V
Trip 4-20mA
