8.2. Overview

Optidrive Compact 2 uses a Macro approach to simplify the configuration of the Analog and Digital Inputs. There are two key parameters which
determine the input functions and drive behaviour:-

P-12 – Selects the main drive control source and determines how the output frequency of the drive is primarily controlled.

P-15 – Assigns the Macro function to the analog and digital inputs.
Additional parameters can then be used to further adapt the settings, e.g.

P-16 – Used to select the format of the analog signal to be connected to analog input 1, e.g. 0 – 10 Volt, 4 – 20mA

P-30 – Determines whether the drive should automatically start following a power on if the Enable Input is present

P-31 – When Keypad Mode is selected, determines at what output frequency / speed the drive should start following the enable command,
and also whether the keypad start key must be pressed or if the Enable input alone should start the drive.

P-47 – Used to select the format of the analog signal to be connected to analog input 2, e.g. 0 – 10 Volt, 4 – 20mA
The diagrams below provide an overview of the functions of each terminal macro function, and a simplified connection diagram for each.
8.3. Macro Function Guide
Function Explanation
STOP Latched Input, Open the contact to STOP the drive
RUN Latched input, Close the contact to Start, the drive will operate as long as the input is maintained
FWD Latched Input, selects the direction of motor rotation FORWARD
REV Latched Input, selects the direction of motor rotation REVERSE
RUN FWD Latched Input, Close to Run in the FORWARD direction, Open to STOP
RUN REV Latched Input, Close to Run in the REVERSE direction, Open to STOP
ENABLE Hardware Enable Input.
In Keypad Mode, P-31 determines whether the drive immediately starts, or the keypad start key must be pressed.
In other modes, this input must be present before the start command is applied via the fieldbus interface.
START Normally Open, Rising Edge, Close momentarily to START the drive (NC STOP Input must be maintained)
˄- START -˄ Simultaneously applying both inputs momentarily will START the drive (NC STOP Input must be maintained)
STOP 
Normally Closed, Falling Edge, Open momentarily to STOP the drive
STARTFWD Normally Open, Rising Edge, Close momentarily to START the drive in the forward direction (NC STOP Input must be
maintained)
STARTREV Normally Open, Rising Edge, Close momentarily to START the drive in the reverse direction (NC STOP Input must be
maintained)
˄-FAST STOP (P-24)-˄ When both inputs are momentarily active simultaneously, the drive stops using Fast Stop Ramp Time P-24
FAST STOP (P-24) Normally Closed, Falling Edge, Open momentarily to FAST STOP the drive using Fast Stop Ramp Time P-24
E-TRIP Normally Closed, External Trip input. This input may be used for:
o
o
When the input opens momentarily, the drive trips showing External Fault or Thermistor Over Temperature
depending on P-47 setting.
Fire Mode Activates Fire Mode, see section 8.5.1 Fire Mode
Analog Input AI1 Analog Input 1, signal format selected using P-16
Analog Input AI2 Analog Input 2, signal format selected using P-47
AI1 REF Analog Input 1 provides the speed reference
AI2 REF Analog Input 2 provides the speed reference
P-xx REF Speed reference from the selected preset speed
PR-REF Preset speeds P-20 – P-23 are used for the speed reference, selected according to other digital input status
PI-REF PI Control Speed Reference
PI FB Analog Input used to provide a Feedback signal to the internal PI controller
KPD REF Keypad Speed Reference selected
INC SPD Normally Open, Close the input to Increase the motor speed
DEC SPD Normally Open, Close input to Decrease motor speed
FB REF Selected speed reference from Fieldbus (Modbus RTU / CAN / Master depending on P-12 setting)
(NO) Input is Normally Open, Close momentarily to activate the function
(NC) Input is Normally Closed, Open momentarily to activate the function
28
Optidrive Compact-2 Engineering Guide Issue 07.docx
External Trip function
Motor thermistor connection (see section 6.7 Motor Thermistor Connection)
