USER CONTROL 1/2, 2/2 Menu

The USER CONTROL 1/2, 2/2 menu is used for
adjusting the picture.
Items that cannot be adjusted depending on the input
signal are displayed in blue.
AUTO CHROMA/PHASE
Adjusts color intensity (CHROMA) and tones
(PHASE).
AUTO ADJ VALUE
Selects ON or OFF of the Auto adjustment. When set
to OFF, this parameter is reset to the factory setting.
When set to ON the automatically adjusted value is
enabled.
START...
Display the color bar signals (Full/SMPTE/EIA/HD)
on the screen and press ENTER. The AUTO
ADJUSTMENT screen starts. Exit from the AUTO
ADJUSTMENT screen using the MENU button after
finishing adjustment. When the adjustment is done
correctly, the AUTO ADJ VALUE is automatically
enabled.
Note
If you have selected the full color bars, enter eight
color bars.
USER MEMORY
SAVE
Saves the current VOLUME, CONTRAST, PHASE,
CHROMA or BRIGHT settings on the control panels.
You can select MEMORY1 or MEMORY2 area to
save the data.
LOAD
Loads the VOLUME, CONTRAST, PHASE,
CHROMA or BRIGHT setting of the control panels
from the setting saved in a memory described above. If
you select Standard, the settings are reset to the
standards.
18
SUB CONTROL
You can finely adjust the adjustment range of buttons
on the right-side of the front panel; CONTRAST,
PHASE, CHROMA and BRIGHT buttons.
CONTRAST
Adjusts the picture contrast. You can adjust the
contrast from 0 to 100.
BRIGHT
Adjusts the picture brightness. You can adjust the
brightness from –50 to +50.
CHROMA
Adjusts color intensity. The higher the setting, the
greater the intensity.
The lower the setting, the lower the intensity. You can
adjust the color intensity from 0 to 100.
PHASE
Adjusts color tones. The higher the setting, the
complexion becomes greenish.
The lower the setting, the picture becomes purplish.
You can adjust the color tones from –50 to +50.
APERTURE
Adjusts the picture sharpness. The higher the setting,
the sharper the picture. You can adjust the color
sharpness from OFF to 100.
