OPTION CONFIG Menu

Sets the option boards installed in the rear. Depending
on the installed board, the displayed screen may differ.
If no board is installed, the item settings are not
displayed. After assigning the input signal, adjust the
monitor's AUTO CHROMA/PHASE.
When installing the optional board BKM-
150CP:
O P T I O N
C O N F I G
B K M – 1 5 0 C P
S E R I A L
x x x x x x x x
F A N
· F O R M A T
S D T I – C P
· A U D I O
C H
C H 1 + C H 2
· T I M E
C O D E
FORMAT
Sets the signal type.
Select SDTI-CP or SDI.
AUDIO
Selects an audio channel.
D1-SDI:
Select from among CH1+CH2 through
CH15+CH16, or CH1 through CH16.
SDTI-CP:
Select from among CH1+CH2 through CH7+CH8,
or CH1 through CH8.
The audio signal input to the OPTION AUDIO INPUT
1/2 jack is ignored.
TIME CODE
Selects the time code display.
D1-SDI:
Select VITC, RP188 or OFF.
SDTI-CP:
Select VITC, CP-TC1, CP-TC2, ES-TC1, ES-TC2
or OFF.
The following lists the abbreviations in the menu and
their full names:
CP-TC1: SMPTE 331M System Item USER DATE/
TIME STAMP
CP-TC2: SMPTE331M System Item CREATION
DATE/TIME STAMP
ES-TC1: SMPTE 328M MPEG ES Editing
Information TIME CODE1
ES-TC2: SMPTE 328M MPEG ES Editing
Information TIME CODE2
PR188:
SMPTE RP188 Time Code
VITC:
SMPTE 12M VITC, SMPTE 266M D-VITC
O K
O F F
When installing the optional board BKM-
155DV:
O P T I O N
C O N F I G
B K M – 1 5 5 D V
S E R I A L
x x x x x x x x
F O R M A T
· A U D I O
C H
C H 1 + C H 2
F A N
AUDIO
Selects an audio channel.
Select from among CH1+CH2, CH3+CH4, CH1/3,
CH2/4, CH1/3+CH2/4, or CH1 through CH4.
The audio signal input to the OPTION AUDIO INPUT
1/2 jack is ignored.
When installing the optional board BKM-
120D:
O P T I O N
C O N F I G
B K M – 1 2 0 D
S E R I A L
x x x x x x x x
When installing the optional board BKM-
142HD:
O P T I O N
C O N F I G
B K M – 1 4 2 H D
S E R I A L
x x x x x x x x
F A N
When installing the optional board BKM-
129X:
O P T I O N
C O N F I G
B K M – 1 2 9 X
S E R I A L
x x x x x x x x
If the cooling fan in the BKM-142HD, BKM-150CP or
BKM-155DV is stopped, the screen shows the
following message in red "BKM-xxxxx FAN
ERROR". In this case, you cannot select Option A or
Option B.
D V
O K
O K
21
