Summary of Contents for LEGRAND CHIEF CSPS
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S (CSPR with Fusion wall mount and FCAV1U accessory) Component Storage Panel Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description...
-
Page 2: Important Safety Instructions
The information contained in this document is subject WARNING: Use this accessory only for its intended use as to change without notice or obligation of any kind. Legrand described in these instructions. Do not use attachments not makes no representation of warranty, expressed or implied, recommended by the manufacturer. - Page 3 Installation Instructions CSPS/CSPR DIMENSIONS CSPR 1.00 21.50 25.4 546.1 18.50 469.9 CSPS ( 22.41 569.1 20.18 512.6 ( 0.86 21.9 0.57 0.41 14.6 0.46 0.69 10.4 11.8 17.5 10.15 6.25 3.25 257.8 158.8 82.6 0.31 R0.07...
- Page 4 CSPS/CSPR Installation Instructions LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación Perforar...
-
Page 5: Tools Required For Installation
Installation Instructions CSPS/CSPR TOOLS REQUIRED FOR INSTALLATION 5/32" (security) 1/2" (12.7mm) (included) PARTS With CSPR (ONLY) B (2) [Wall bracket] A (1) E (4) [Accessory wall plate] D (4) C (4) #10-24 x 1 1/4" #10-24 anchor With CSPS (ONLY) G (2) H (1) F (4) -
Page 6: Site Requirements
CSPS/CSPR Installation Instructions Site Requirements Component Storage Panel Installation Location If back side of wall is unfinished, drywall must be installed to a minimum of one stud left and right of the studs being used to install the mount. Drywall must be secured to studs with screws 12"... -
Page 7: Side View
Installation Instructions CSPS/CSPR Assembly And Installation Drywall CSPS Installation Position accessory wall plate (A) onto wall at desired Plastic Cap mounting location. Use a level to ensure of an even mount. (See Figure 1) Mark and drill four 1/2" (12.7mm) holes at the desired mounting locations. - Page 8 CSPS/CSPR Installation Instructions CSPR Installation Drywall Position top wall bracket (B) on wall at desired mounting location. Use a level to ensure of an even mount. (See Figure 6) Plastic Cap Mark and drill four 1/2" (12.7mm) holes at the desired mounting locations.
-
Page 9: Component Installation
Installation Instructions CSPS/CSPR Loosely install four #10-24 x 3/4" Phillips pan machine screws (F) into top and bottom holes on accessory wall plate (A). Two #10-24 x 1/2" button head security screws (G) may be used in place of two Phillips screws (F) on the top or bottom if greater security is desired. - Page 10 CSPS/CSPR Installation Instructions Accessory Plate Removal (CSPR ONLY) Loosen four screws holding accessory wall plate (A) to wall brackets (B). (See Figure 13) Grab handle and pull accessory wall plate (A) straight up until removed from wall brackets (B). (See Figure 13) handle Figure 13...
- Page 11 Installation Instructions CSPS/CSPR...
- Page 12 P +31 (0) 495 580 852 F +31 (0) 495 580 845 Asia Pacific A Office No. 918 on 9/F, Shatin Galleria 8800-002943 Rev01 18-24 Shan Mei Street 2019 Legrand Fotan, Shatin, Hong Kong www.legrandav.com P 852 2145 4099 05/19 F 852 2145 4477...
