- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Column-mounted Tablet Floor Stand Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description HFSTS...
-
Page 2: Important Safety Instructions
(not included). See Figure below for product. The information contained in this document is subject details. to change without notice or obligation of any kind. Legrand makes no representation of warranty, expressed or implied, NOTE: Both accessories shown may be used together. -
Page 3: Installation Instructions
Installation Instructions HFSTS DIMENSIONS 1.30 R1.00 33.0 25.4 R.50 12.7... - Page 4 HFSTS Installation Instructions LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación Perforar...
-
Page 5: Tools Required For Installation
Installation Instructions HFSTS TOOLS REQUIRED FOR INSTALLATION (floor install ONLY) 1/8" (floor install ONLY) PARTS C (1) [Bolt plate] D (2) [Base plate] E (6) #10-24 x 5/8" B (1) A (1) [Column cover] F (4) [Column] #10-24 x 1/2" G (1) 1/8"... -
Page 6: Assembly And Installation
HFSTS Installation Instructions Assembly And Installation Partially install six #10-24 x 5/8" button head cap screws (E) into column (A). (See Figure 1) (E) x 6 (partially install) (D) x 2 (F) x 4 Figure 2 WARNING: Exceeding the weight capacity can result in serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the combined weight of all components and accessories attached to mounting... -
Page 7: Cable Management
Installation Instructions HFSTS Connect cord to bottom of column-mounted tablet. (See Figure 4) Install column cover (B) onto column (A) making sure keyholes are onto screws and cable is routed through the bottom gap on cover. (See Figure 4) Tighten all screws (F) to secure cover (B) to column (A). (See Figure 4) component cable (E) x 6... - Page 8 P +31 (0) 495 580 852 F +31 (0) 495 580 845 Asia Pacific A Office No. 918 on 9/F, Shatin Galleria 8800-003237 Rev01 18-24 Shan Mei Street 2020 Legrand Fotan, Shatin, Hong Kong www.legrandav.com P 852 2145 4099 09/2020 F 852 2145 4477...
