I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
PAC800E
IntelliSHOT®
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
PAC810E
Video Conferencing Mount
Spanish Product Description
German Product Description
Portuguese Product Description
PAC800E/810E
Italian Product Description
Dutch Product Description
French Product Description
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for LEGRAND CHIEF IntelliSHOT PAC800E
Summary of Contents for LEGRAND CHIEF IntelliSHOT PAC800E
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation PAC800E PAC810E Video Conferencing Mount IntelliSHOT®...
-
Page 2: Important Safety Instructions
The information contained in this document is subject WARNING: Use of this accessory will decrease the weight to change without notice or obligation of any kind. Legrand capacity of the mounting system to which it is attached by the makes no representation of warranty, expressed or implied, combined weight of the accessory and all components regarding the information contained herein. -
Page 3: Installation Instructions
Installation Instructions PAC800E/810E DIMENSIONS PAC800E SHOWN WITH LSCU (SOLD SEPARATELY) 14.40 365.9 8.24 209.4 TOP OF LSCU CART INTERFACE BRCAKET FOR LSCU CART (INCLUDED) NOTE: CAMERA CAN BE INSTALLED ABOVE O R BELOW DISPLAY. DIMENSIONS ARE THE SAME FOR BOTH. SHOWN W ITH CAMERA AND CART FOR REFERENCE ONLY. - Page 4 PAC800E/810E Installation Instructions DIMENSIONS (CONTINUED) PAC810E SHOWN WITH LSCU (SOLD SEPARATELY) 19.65 499.2 12.29 312.2 M IN TOP OF LSCU CART NOTE: CAMERA CAN BE INSTALLED ABOVE OR BELOW DISPLAY. DIMENSIONS ARE THE SAME FOR BOTH. SHOWN WITH CAMERA AND CART FOR REFERENCE ONLY.
-
Page 5: Tools Required For Installation
Installation Instructions PAC800E/810E TOOLS REQUIRED FOR INSTALLATION 5/32" 1/4" M8 (if installing to LSCU) PARTS B (1) 5/32" C (2) D (2) 1/4-20 x 1/2" 1/4-20 x 3/4" E (2) LSCU Adapter kit 1/4-20" F (1) G (2) [LSCU adapter] A (1) [Main bracket] (PAC800E shown) - Page 6 PAC800E/810E Installation Instructions Installation Attach to LSCU Faceplate (LSCU only) Install two M8 hex nuts (G) onto back of LSCU faceplate NOTE: The PAC800/810E video conferencing shelf can be leaving 1/8" between nuts and faceplate. (See Figure 3) mounted before or after the display is mounted to the Install adapter bracket (F) over nuts (G) and slide over into faceplate.
-
Page 7: Height Adjustment
Installation Instructions PAC800E/810E Installing Camera (not included) Adjustments Height Adjustment WARNING: Exceeding the weight capacity can result in Loosen two adjustment knobs on the back of the main serious personal injury or damage to equipment! It is the bracket (A). (See Figure 7) installer’s responsibility to make sure the combined weight Raise or lower bracket to desired height. - Page 8 P +31 (0) 495 580 852 F +31 (0) 495 580 845 Asia Pacific A Office No. 918 on 9/F, Shatin Galleria 8800-003375 Rev00 18-24 Shan Mei Street 2023 Legrand Fotan, Shatin, Hong Kong www.legrandav.com P 852 2145 4099 01/2023 F 852 2145 4477...
