- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Column-mounted Tablet Floor Stand Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description HTSTS...
-
Page 2: Important Safety Instructions
The information contained in this document is subject WARNING: Use this mounting system only for its intended to change without notice or obligation of any kind. Legrand use as described in these instructions. Do not use makes no representation of warranty, expressed or implied, attachments not recommended by the manufacturer. -
Page 3: Installation Instructions
Installation Instructions HTSTS DIMENSIONS 1.30 33.0 DEVICE MOUN TING HOLE R.50 12.7... - Page 4 HTSTS Installation Instructions LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación Perforar...
-
Page 5: Tools Required For Installation
Installation Instructions HTSTS TOOLS REQUIRED FOR INSTALLATION (tabletop install ONLY) 1/8" (tabletop install ONLY) PARTS B (1) A (1) [Column cover] [Column] D (1) 1/8" C (4) #10-24 x 5/8"... -
Page 6: Assembly And Installation
HTSTS Installation Instructions Assembly And Installation WARNING: Exceeding the weight capacity can result in serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the combined weight of all components and accessories attached to mounting system does not exceed 10 lbs (4.5 kg). - Page 7 Installation Instructions HTSTS Bolt to Table (Optional) The HTSTS mount may be bolted to the table for increased security or stability. Hardware is NOT provided for this installation. IMPORTANT ! : Column cover (B) must be attached to column (A) before being bolted to table. Use column holes as a template to mark holes on table at desired mounting location.
- Page 8 P +31 (0) 495 580 852 F +31 (0) 495 580 845 Asia Pacific A Office No. 918 on 9/F, Shatin Galleria 8800-003238 Rev00 18-24 Shan Mei Street 2020 Legrand Fotan, Shatin, Hong Kong www.legrandav.com P 852 2145 4099 09/2020 F 852 2145 4477...
