I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
DMA1
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
Koncis™ Dynamic Monitor Arm
DMA2
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
DMA Series
Advertisement
Table of Contents
Related Manuals for LEGRAND CHIEF Koncis DMA Series
Summary of Contents for LEGRAND CHIEF Koncis DMA Series
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation DMA1 DMA2 Koncis™ Dynamic Monitor Arm Spanish Product Description German Product Description Portuguese Product Description...
-
Page 2: Important Safety Instructions
WARNING: Do not use this product outdoors. product. The information contained in this document is subject to change without notice or obligation of any kind. Legrand makes no representation of warranty, expressed or implied, WARNING: Exceeding the weight capacity can result in regarding the information contained herein. - Page 3 Installation Instructions DMA Series DIMENSIONS DMA1 1.84 46.7 DYNAMIC LIFT ARM LENGTH RANGE STRAIGHT = MAX FULL UP/DOWN = MIN 10.84 7.19 275.5 INTERFACE ROTATION 182.8 RANGE TILT RANGE 65 UP MOUNTING 10 DOWN PATTERN COMPATIBILITY 100 X 100 75 X 75 1.99 50.6 DESKTOP...
- Page 4 DMA Series Installation Instructions LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación Perforar...
-
Page 5: Tools Required For Installation
Installation Instructions DMA Series TOOLS REQUIRED FOR INSTALLATION 5/32” (included) PARTS A (1) [Arm assembly] B (1) (DMA1 shown) [Base assembly] (DMA1 shown) * - (DMA1/DMA2) Hardware bag C (4/8)* G (1/2)* E (4/8)* F (1/2)* D (4/8)* M4x10mm #10-32-3/8” M10x5.3x10 M4x4mm M4x20mm... - Page 6 DMA Series Installation Instructions Assembly And Installation Connecting Desk Clamp to Desk Standard Installation Loosen clamp screw on base assembly (B) until enough space is created between clamp and base to allow for desk mounting. (See Figure 1) or (See Figure 2) NOTE: Clamp can be turned either by turning the knob (See Figure 1) or turning the bolt with a hex key (See Figure...
- Page 7 Installation Instructions DMA Series Reattach removed piece of clamp and screws to assembly. Place mounting arm(s) (A) onto base assembly (B) by (See Figure 5) slowly lowering arm onto base assembly pin. (See Figure 7) Tighten clamp using clamp screw until mount is securely NOTE: The arm will stay on the base without any fasteners fastened to desk.
- Page 8 DMA Series Installation Instructions WARNING: (for recessed mounting holes) Exceeding the weight capacity can result in serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the combined weight of all components and accessories attached to the DMA Series quick release Monitor Arm up to (and including) the display is between the faceplate...
-
Page 9: Display Removal
Installation Instructions DMA Series Adjustments Display Removal Pitch Adjustment WARNING: Only remove display from mount when the Adjust pitch to desired tilt position. (See Figure 12) display can be lifted up from the mount! DO NOT remove display unless the display is in the upright position! (See Adjust pitch tension screw to change the adjustment tension. -
Page 10: Tool Storage
DMA Series Installation Instructions Pivot Adjustment Range (top view) pivot point of the arm NOTE: This section only applies if the pivot stop screw is removed. (See Figure 6) DMA1 Adjust arm angle as desired up to 90 degrees in either direction. - Page 11 Installation Instructions DMA Series...
-
Page 12: Installation Instructions
P +31 (0) 495 580 852 F +31 (0) 495 580 845 Asia Pacific A Office No. 918 on 9/F, Shatin Galleria 8800-003193 Rev00 18-24 Shan Mei Street 2020 Legrand Fotan, Shatin, Hong Kong www.legrandav.com P 852 2145 4099 10/2020 F 852 2145 4477...
