Prolon C1000 Series Hardware Manual
Water loop controller
Hide thumbs
Also See for C1000 Series:
- Hardware manual (23 pages) ,
- Quick start manual (10 pages) ,
- Operational manual (19 pages)
Table of Contents
Advertisement
Quick Links
Download this manual
See also:
Hardware Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Prolon C1000 Series
Summary of Contents for Prolon C1000 Series
- Page 1 HARDWARE GUIDE Water Loop Controller C1000 Series Specifications and Operational Guide www.proloncontrols.com | info@proloncontrols.com 17 510, rue Charles, Suite 100, Mirabel, QC, J7J 1X9 REV. 7.1.0 PL-HRDW-WLC-C1000-C/F-EN...
-
Page 2: Table Of Contents
Table of Contents General Information ..........................4 PL-C1000 Water Loop Controller ..........................4 Description ..................................4 General Behaviour ................................ 4 Components ............................5 Component Identification ............................5 LEDs ....................................6 Address Configuration for Networking ........................6 Jumper to Supply Power to the RJ45 Plug ......................7 Input and Output Identification .......................... - Page 3 Table of Figures Figure 1 - Component Identification ..........................5 Figure 2 - LEDs Identification ............................6 Figure 3 - Addressing Dipswitches ..........................6 Figure 4 - Jumpers ................................7 Figure 5 - Input and Output Identification ........................7 Figure 6 - Connecting the Water Temperature Sensors ................... 8 Figure 7 - Connecting the Auxiliary Digital Input .....................
-
Page 4: General Information
General Information PL-C1000 Water Loop Controller Description The PL-C1000 Water Loop controller is designed to control a water loop system comprised of a boiler and a water tower with an internal pump. The built-in microprocessor offers precise digital control to maxi- mize performance. -
Page 5: Components
Components Component Identification BIAS TERM BIAS TERM Figure 1 - Component Identification Legend: A - Addressing Dipswitch B - Output 1 Dipswitch C - Output 2 Dipswitch D - Output 3 Dipswitch E - Output 4 Dipswitch F - Master reset button G - Terminal Blocks for Inputs and Outputs H - LEDs I - Jumpers for terminating and bias resistors for the NET port... -
Page 6: Leds
The example on Figure 3 shows the switches 1, 2 and 4 on the ON position. So the corresponding values are 1, 2 and 8, giving an address sum of 11. (1+2+8=11) The ProLon network allows a maximum of 127 addresses, therefore 127 controllers. Figure 3 - Addressing Dipswitches... -
Page 7: Jumper To Supply Power To The Rj45 Plug
The C1000 Water Loop Controller has 2 separate communication ports offering the same functionality on each. Both act as ports for incoming Modbus communications from other ProLon devices or interfaces, such as a Network Controller or remote computer with ProLon Focus software. -
Page 8: Inputs
Inputs Temperature Sensors The C1000 Water Loop controller has an analog inputs dedicated to monitoring the supply and return water temperatures and will integrate these reading into its control sequence. An auxiliary temperature sensor input in also available (for visualisation purposes only) and will not affect the sequence. The sensors used are standard 10k type 3 thermistors. -
Page 9: Outputs
Outputs The C1000 Water Loop controller contains 5 configurable outputs. The first 4 outputs are ON-OFF triac outputs. Output 5 is an analog 0-10VDC ON-OFF or modulating output, fully customizable via the ProLon Focus software. An integrated resettable fuse protects each of the outputs of the C1000 against current surges and short circuits. -
Page 10: Typical Connection Of Digital Outputs 1 To 4
2) Switch position to obtain a SINK passive output (see Figure 9): Switch for Output 4 Isolated dry contact (On/O ) Figure 9 - Output in SINK mode Typical Connection of Digital Outputs 1 to 4 Two types of configurations are possible: 1) Active output (SOURCE). -
Page 11: Typical Connection Of Analog Output
Typical Connection of Analog Output Two types of configuration are possible: 1) The C1000 powers the load and provides a control signal (see Figure 12). 24 VAC power (From terminal block #2 of the controller) Controlled 0-10v 0-10v Load Figure 12 - Connecting the Analog Output (Controller Powered) 2) The C1000 only provides the control signal to the load, which is powered by an external source (see Figure 13). -
Page 12: Power Source / Network
Power Source / Network Power Source The ProLon C1000 controller is powered by a 24 VAC power source connected using the "COM" terminal and the "24 VAC" terminal (see Figure 14). The common for all inputs and outputs are the same as the power source’s common (exception: when an output is set to passive, the common for this output will not... -
Page 13: Technical Specifications
Environment: 32-122 ºF (0-50 ºC) Non-Condensing Certification: RoHS, FCC part 15: 2012 class B The performance specifications are nominal and conform to acceptable industry standards. ProLon Inc. will not be liable for damages resulting from misapplication or misuse of its products. -
Page 14: Compliance
(1) this device may not cause harmful interference, and (2) this device must accept any interference re- ceived, including interference that may cause undesired operation. Caution: Any changes or modifications not approved by ProLon can void the user’s authority to operate the equipment. -
Page 15: Overall Dimensions
No part of this document may be photocopied or reproduced by any means, or translated to another language without prior written consent of Prolon. All specifications are nominal and may change as design improvements are introduced. Prolon shall not be liable for damages resulting from misapplication or misuse of its products.
