Prolon C1000 Series Hardware Manual

Humidifier controller
Hide thumbs Also See for C1000 Series:

Advertisement

Quick Links

HARDWARE
GUIDE
Humidifier Controller C1000 Series
Specifications and Operational Guide
www.proloncontrols.com | info@proloncontrols.com
17 510, rue Charles, Suite 100, Mirabel, QC, J7J 1X9
REV. 7.1.0
PL-HRDW-HU-C1000-C/F-EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C1000 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Prolon C1000 Series

  • Page 1 HARDWARE GUIDE Humidifier Controller C1000 Series Specifications and Operational Guide www.proloncontrols.com | info@proloncontrols.com 17 510, rue Charles, Suite 100, Mirabel, QC, J7J 1X9 REV. 7.1.0 PL-HRDW-HU-C1000-C/F-EN...
  • Page 2: Table Of Contents

    Table of Contents General Information ..........................4 PL-C1000 Humidity Controller ........................... 4 Description ..................................4 General Behaviour ................................ 4 Operating Sequence ..........................5 Humidification ................................5 Dehumidification ................................5 Components ............................6 Component Identification ............................6 LEDs ....................................7 Address Configuration for Networking ........................7 Jumper to Supply Power to the RJ45 Plug ......................
  • Page 3 Table of Figures Figure 1 - Component Identification ..........................6 Figure 2 - LEDs Identification ............................7 Figure 3 - Addressing Dipswitches ..........................7 Figure 4 - Jumper ................................8 Figure 5 - Input and Output Identification ........................8 Figure 6 - RJ45 Pinout ............................... 8 Figure 7 - Connecting the Outside Air Sensor ......................
  • Page 4: General Information

    General Behaviour Although fully configurable, the ProLon C1000 humidity controller monitors dedicated inputs and uses pre-established control sequences to drive dedicated outputs to control standard humidification or dehumidification equipment. These sequences can be fully optimized to obtain the best results for each type of system.
  • Page 5: Operating Sequence

    The second is a by sending a network based signal to any ProLon Rooftop controller. The ProLon Rooftop controller will then take the necessary steps to begin dehumidification.
  • Page 6: Components

    Components Component Identification BIAS TERM BIAS TERM Figure 1 - Component Identification Legend: A - Addressing dipswitch B - Jumpers for terminating and bias resistors for the NET port (see J) C - Jumpers for terminating and bias resistors for the INT port (see K) D - Output 4 (Humidification) SOURCE/SINK dipswitch E - Output 3 (Dehumidification) SOURCE/SINK dipswitch F - Reset Button...
  • Page 7: Leds

    The example on Figure 3 shows the switches 1, 2 and 4 on the ON position. So the corresponding values are 1, 2 and 8, giving an address sum of 11. (1+2+8=11) The ProLon network allows a maximum of 127 addresses, therefore 127 controllers. Figure 3 - Addressing Dipswitches...
  • Page 8: Jumper To Supply Power To The Rj45 Plug

    The C1000 Humidity Controller has 2 separate communication ports offering the same functionality on each. Both act as ports for incoming Modbus communications from other ProLon devices or interfaces, such as a Network Controller or remote computer with ProLon Focus software.
  • Page 9: Inputs

    Figure 7) and will integrate this reading into its control sequence. The sensor used is a standard 10k type 3 thermistor. If the C1000 is connected to a ProLon network, it can instead receive the outside temperature from another device on the network.
  • Page 10: Proof Of Fan

    Proof of Fan The C1000 Humidity controller has an input dedicated for a proof of fan contact (see Figure 9). To confirm that there is a proof of fan, the contact must be closed. If the C1000 is connected to a network, the net- work master can transmit the proof of fan information through the network instead.
  • Page 11: Outputs

    0-10VDC modulating or pulsing output, which follows a proportional and integral algorithm (PI). This PI function is fully customizable via the ProLon Focus software. The remaining output (Output 3) is dedicated to dehumidification. Output 3 is an ON-OFF triac output.
  • Page 12: Configuration Of Outputs 3 And 4

    Configuration of Outputs 3 and 4 The digital triac outputs are configurable (SOURCE/SINK) via a switch located on the board. Simply move the switch to obtain either a SOURCE active output (1) or a SINK passive output (2). 1) Switch position to obtain a SOURCE active output (see Figure 10): Switch for Output 4 24 VAC Output (ON/O )
  • Page 13: Typical Connection Of The Analog Output

    2) Passive output (SINK). The C1000 opens and closes a contact to allow an external source to power the load (see Figure 13). 24 N External 24 V External Load Figure 13 - Connection of Passive Outputs 3 and 4 Typical Connection of the Analog Output Two types of configuration are possible: 1) The C1000 powers the load and provides a control signal (see Figure 14).
  • Page 14: Power Source / Network

    Power Source / Network Power Source The ProLon C1000 controller is powered by a 24 VAC power source connected using the "COM" terminal and the "24 VAC" terminal (see Figure 16). The common for all inputs and outputs are the same as the power source’s common (exception: when an output is set to passive, the common for this output will not...
  • Page 15: Technical Specifications

    Environment: 32-122 ºF (0-50 ºC) Non-Condensing Certification: RoHS, FCC part 15: 2012 class B The performance specifications are nominal and conform to acceptable industry standards. ProLon Inc. will not be liable for damages resulting from misapplication or misuse of its products.
  • Page 16: Compliance

    (1) this device may not cause harmful interference, and (2) this device must accept any interference re- ceived, including interference that may cause undesired operation. Caution: Any changes or modifications not approved by ProLon can void the user’s authority to operate the equipment.
  • Page 17: Overall Dimensions

    No part of this document may be photocopied or reproduced by any means, or translated to another language without prior written consent of Prolon. All specifications are nominal and may change as design improvements are introduced. Prolon shall not be liable for damages resulting from misapplication or misuse of its products.
