LTC1736
TYPICAL APPLICATIO
12A Converter with FCB Tied to PGOOD for CPU Power; Optimized for Output Voltages of 1.3V to 1.6V
C
OSC
47pF PGOOD
C 01.µF
SS
R 33k
C 330pF
C C1
C 47pF
C2
100k
INTV
CC
1000pF
47pF
C : 4-180µF/4V PANASONIC EEFUEOG181R (AS SHOWN)
OUT
3-470µF/6.3V KEMIT T51CX447M006AS (ALTERNATE)
1-820µF/4V SANYO 4SP820M + 1-180µF/4V PANASONIC EEFUE0G181R (ALTERNATE)
C : SANYO OS-CON 305C22M
IN
L1: PANASONIC ETQP6RZ1RZ0HFA

RELATED PARTS

PART NUMBER DESCRIPTION
LTC1147 High Efficiency Step-Down Controller
LTC1148HV/LTC1148 High Efficiency Synchronous Step-Down Controllers
LTC1149 High Efficiency Synchronous Step-Down Controller
LTC1159 High Efficiency Synchronous Step-Down Controller
LTC1265 1.2A Monolithic High Efficiency Step-Down Switching Regulator
LT1375/LT1376 1.5A 500kHz Step-Down Switching Regulators
LTC1435A High Efficiency Synchronous Step-Down Controller, N-Ch Drive
LTC1436A/LTC1436A-PLL High Efficiency Low Noise Synchronous Step-Down Converters, N-Ch Drive Adaptive Power
LTC1474/LTC1475 Ultralow Quiescent Current Step-Down Monolithic Switching Regulators
LTC1625/LTC1775 No R
LTC1628 Dual High Efficiency 2-Phase Step-Down Controller
LTC1703 550kHz Dual Output Synchronous Step-Down DC/DC Controller
LTC1735 High Efficiency Synchronous Step-Down Controller, N-Ch Drive
LTC1735-1 High Efficiency Step-Down Controller with Power Good
Adaptive Power and No R are trademarks of Linear Technology Corporaton.
SENSE
Linear Technology Corporation
28
1630 McCarthy Blvd., Milpitas, CA 95035-7417
(408) 432-1900 FAX: (408) 434-0507 www.linear-tech.com
1 24
C TG
OSC
2
23
RUN/SS BOOST
3 22
I SW
TH
4 21
FCB LTC1736 V
IN
5
20
SGND INTV
CC
6 19
PGOOD BG
7
18
–
SENSE PGND
8 17
+
SENSE EXTV
CC
9 16
V VIDV
FB CC
10 15
V VID4
OSENSE
11 14
VID0 VID3
12
13
VID1 VID2
10Ω
10Ω
TM
Current Mode Synchronous Step-Down Controllers
SENSE
M1 +
FDS6680A
C 0.22µF
B
L1
1.2µH
D
B
CMDSH-3
+
1µF
M2
4.7µF
FDS6680A
× 2
OPTIONAL:
CONNECT
TO 5V
OUTPUT VOLTAGE
PROGRAMMING
V
IN
4.75V TO 24V
C
IN
22µF/30V
× 2
OS-CON
R
SENSE
0.004Ω V
1.35V TO 1.6V
12A
+
C
OUT
180µF/4V
D1
× 4
MBRS340T3
SGND
1736 TA02
