2.3 OUTPUTS

MAXinBOX 66 incorporates 6 relay outputs, each configurable as a:
Individual binary output, which allows an independent control of a load (up
to 6 different loads can be controlled by a MAXinBOX 66).
Shutter channel, which allows controlling the motion of one blind (up to 3
blinds can be controlled by a MAXinBOX 66).
For detailed information about the functionality and the configuration of the related
parameters, please refer to the following specific manuals, all of them available under
the MAXinBOX 66 product section at the Zennio homepage (www.zennio.com):
Individual outputs.
Shutter channels.

2.3.1 MANUAL CONTROL

MAXinBOX 66 allows manually switching the state of its output relays through the
respective pushbuttons on the top of the device. A specific pushbutton is therefore
available per output.
Manual operation can be done in two different ways, named as Test On Mode (for
testing purposes during the configuration of the device) and Test Off Mode (for a
normal use, anytime). Whether both, only one, or none of these modes should be
accessible needs to be parameterised in ETS. Moreover, it is possible to enable a
specific binary object for locking and unlocking the manual control in runtime.
Note:
The Test Off mode will be active (unless it has been disabled by parameter)
after a download or a reset with no need of a specific activation – the
pushbuttons will respond to user presses from the start.
On the contrary, switching to the Test On mode (unless disabled by
parameter) needs to be done by long-pressing the Prog/Test button (for at
least three seconds), until the LED is no longer red and turns yellow. From
