Foundation Fieldbus CP Option Card Technical Manual
Note 1: Throughout this manual the Foundation Fieldbus may be abbreviated to FF
Note 2: Throughout this manual the FF Interface Card may simply be referred to as the FF CP card.
Note 3: The information in this manual relates to the FF CP card firmware / hardware versions:
M3.1 / T1.4 / H1.1 (or newer)
Note 4: The screen dumps used in the manual have generally be taken from a National Instruments FF
configurator tool's screen. Other configurator tools may show the same data on a different set of
screens.
Note 5: This manual is to be used in conjunction with the relevant actuator setting manual and assumes a
pre-existing level of knowledge of using both FF and the particular actuator type. It is advised that
the relevant technical manual is read before attempting to set-up FF within the actuator.
Note 6: The FF CP card described in this manual contains static-sensitive devices. Suitable
precautions, such as wearing an earthed anti-static wrist strap, should be taken before
handling the card. It should be kept in an anti-static bag or box while it is not fitted within an
actuator.
As we are continually developing our products their design is subject to change without notice.
©
The contents of this document are copyright and must not be reproduced without the written permission
of Rotork.
The name Rotork is a registered trademark.
Foundation is a registered trademark of the Fieldbus Foundation.
NI-FBUS is a registered trademark of National Instruments.
Windows is a registered trademark of The Microsoft Corporation.
The names; Allen, Bluetooth, Modbus, Rotork and Torx are registered trademarks.
