SMC Networks C RB 10 Series Operation Manual page 22

Size：20，30，40
o
For 90
Component Parts
No.
1 Body (A)
2 Body (B)
3 Vane shaft
4 Stopper
5 Stopper for 90
6 Holding rubber
7 Stopper seal
8 Back-up ring
9 Bearing
10 O-ring
11
Seal washer
12
Adjustment bolt
13
Hexagon nut
14
Hexagon socket head cap screw
* The material is chrome molybdenum steel for sizes 30 and 40.
Description
o
5
For 180
Material
Aluminum alloy
Aluminum alloy
Stainless steel *
Resin
Resin
NBR
NBR
Stainless steel
Bearing steel
NBR
NBR
Chrome molybdenum steel
Steel wire
Chrome molybdenum steel
o
Note
Painted
Painted
o
For 90
For 90 o
Special seal
Special screw
