Environmental Characteristics

Table 1-21: Environmental characteristics

Characteristics
Temperature
Operating
Non-operating
Relative humidity
Operating
Non-operating
Altitude
Operating
Non-operating
Dynamics
Vibration
Operating
Non-operating
Shock
Non-operating
Installation requirements
Power dissipation
Surge current
Cooling clearance
Top and bottom clearance
Side clearance
Rear clearance
AWG7000 Series Arbitrary Waveform Generators Technical Reference
Description
+10 _C to +40 _C
- - 20 _C to +60 _C
5% to 80% (no condensation)
Maximum wet-bulb temperature 29 _C
5% to 90% (no condensation)
Maximum wet-bulb temperature 29 _C
Up to 3,000 m (approximately10,000 feet)
Maximum operating temperature decreases 1 _C each 300 m above 1.5 km
Up to 12,000 m (approximately 40,000 feet)
2
2.65 m/s rms (0.27 Grms , 5 Hz to 500 Hz, 10 min, three axes
)
2
22.3 m/s rms (2.28 Grms), 5 Hz to 500 Hz, 10 min, three axes
2
294 m/s (30 G), half-sine, 11 ms duration
560 W (600 VA maximum)
30 A peak (25 _C) for ≤ 5 line cycles, after product has been turned off for at least 30 s.
2 cm (0.8 in)
15 cm (5.9 in)
7.5 cm (3.0 in)
