Specifications and Features
Operating Spectrum:
Frequency Adjustment Range:
Sampling Size and Rate:
Digital Modulation:
Data Encoding:
Encryption:
Latency:
Digital Source:
Analog Source:
Audio Performance:
Frequency Response:
THD+N:
Dynamic Range:
Adjacent Channel Isolation:
Diversity Technique:
Sensitivity:
Antenna Inputs/Outputs:
Audio Outputs:
XLR:
Headphone:
Dante:
External DC Power:
Weight:
Dimensions:
Specifications subject to change without notice.
Rio Rancho, NM
470.100 - 614.375 MHz
25 kHz steps
24-bit, 48 kHz
8PSK with Forward Error Correction
Proprietary ADPCM
AES 256-CTR
(per FIPS 197 and FIPS 140-2)
1.0 ms plus Dante network
<1.4 ms
20 Hz - 20 KHz, +\-1 dB
0.05% (1 KHz @ -10 dBFS)
108 dB A-wtd, NR=NORMAL
>85 dB
Noiseless antenna switching
-98 dBm for 10-5 BER
Dual BNC female, 50 ohm impedance
Balanced, -35 to +8 dBu
1/4 inch phone jack
RJ45
7 to 18 VDC; 2.5A (max)
2.04 lbs.; 926 grams
8.375 x 1.75 x 7.375 in.
213 x 44.5 x 187 mm.
