Design and function
MIG/MAG welding

5.7.14.4 Switching between Push/Pull and intermediate drive

Do not carry out any unauthorised repairs or modifications!
To avoid injury and equipment damage, the unit must only be repaired or modified by
specialist, skilled persons!
The warranty becomes null and void in the event of unauthorised interference.
•
Appoint only skilled persons for repair work (trained service personnel)!
Test!
Before re-commissioning, it is essential that an "inspection and test during operation"
is carried out conforming to IEC / DIN EN 60974-4 "Arc welding devices - inspection and
testing during operation"!
•
For detailed instructions, please see the standard operating instructions for the welding
machine.
The plugs are located directly on the M3.7x printed circuit board.
Plug Function
on X24 Operation with Push/Pull welding torch (factory setting)
on X23 Operation with intermediate drive
50
DANGER
CAUTION
099-004846-EW501
8.01.2014
