5.9.1.2

Arcforce

The settings are made on the wire feed unit control.
Operating
element
5.9.1.3

Hotstart

The hotstart device improves the ignition of the stick electrodes using an increased ignition current.
a) = Hotstart time
b) = Hotstart current
I = Welding current
t = Time
099-004846-EW501
8.01.2014
Action Result
Select arcforce welding parameter
LED for the button
Arcforcing setting for electrode types:
(Setting range -40 to 40)
Negative values
Values around zero
Positive values
Design and function
NOTE
is on.
Rutile
Basic
Cellulose
Figure 5-26
MMA welding
Display
61
