5.7.15 Expert menu (MIG/MAG)

The expert menu includes functions and parameters which are either not set on the machine control, or
which do not require regular setting.

5.7.15.1 Selection

ENTER (Enter the menu)
•
Keep the "welding parameters" push-button pressed for 3 s.
NAVIGATION (Navigate the menu)
•
Select parameters by pressing the "welding parameters" push-button.
•
Set or change the parameters by turning the "welding parameter setting" rotary knob.
EXIT (Exit the menu)
•
After 3 s, the machine will return automatically to the ready-to-operate status.
099-004846-EW501
8.01.2014
ENTER NAVIGATION
3 s
NOTE
m /m in
Figure 5-16
Design and function
MIG/MAG welding
EXIT
3 s
