As VIEW8+ is designed for fusion splicing silica glass optical fibers,
that the splicer should not be used for any other purposes.
instrument and must be handled with caution. Therefore, you must read the following
safety rules and general precautions in this manual regarding the use and handling of
VIEW8+ at any time. Any behaviors that do not follow the warnings and cautions will
break the safety standard about design, manufacture, and usage of the fusion splicer.
INNO Instrument will not take the responsibility for those consequences caused by
misuse!
① Never operate the splicer in an environment where flammable liquids or vapors
exist.
② DO NOT touch the electrodes when the splicer is on.
Note: Only use specified electrodes for the fusion splicer. Select
[Replace electrode] in maintenance menu to replace electrodes, or turn
off the splicer and disconnect the AC power source or remove battery
before replacing electrodes. Discharging is prohibited before the
electrodes are placed as a pair.
③DO NOT disassemble or modify any components of the splicer without approval, except for
the permitted-to-disassemble / modify components or parts by users stated in this manual.
Component replacement and its internal adjustment must be implemented by INNO or its
authorized technicians or engineers.
④ Never operate the splicer in an environment where fammable liquids or vapors exist.
Risk of dangerous fire or explosion could result from the splicer's electrical arc in such an
environment. DO NOT operate the splicer near heat source or in high temperature and dusty /
humid atmosphere, or when condensation is present on the splicer. This may result in electric
shock, splicer malfunction, or poor splicing performance.
⑤ Safety glasses should always be worn during fiber preparation and splicing operation. Fiber
fragments can be extremely dangerous if they come into contact with the eye, skin, or are
ingested.
⑥ Take out the battery immediately if the followings are observed when using the splicer:
＊ Fumes, bad smell, abnormal noise or over heat.
＊ Liquid or other matter falls into cabinet
＊ The splicer is damaged or dropped.
If any of these faults occurs, please contact our service center immediately. Leaving the splicer
in a damaged state without any prompt measures may cause equipment failure, electric
shock, or fire and may result in injury or death.
⑦ Do not use compressed gas or canned air to clean the splicer. They may contain
flammable materials that could ignite during the electrical discharge.
⑧ Please use VIEW8+ specific standard battery only. Using an improper AC power source
may cause fuming, electric shock or equipment damage and may even result in fire, injury or
death.
⑨ Please use VIEW8+ specific charger only. Do not place any heavy objects on the AC
power cord. Keep the power cord away from heat source. Using an improper cord or a
damaged cord may cause fuming, electric shock or equipment damage and may even result
in fire, injury or death.
Chapter 2 - Installation
Safety Warning and Precautions
INNO Instrument, Inc.
it is very important
The splicer is a precision
Operational Safety Warnings
PAGE
User's Manual
07
