Chapter1 Technical Parameters

Applicable Fiber Type

＊ SM(ITU-TG.652&G.657)/MM(ITU-TG.651)/DS(ITU-TG.653)/NZDS(ITU-
TG.655)
＊ Fiber count: Single
＊ Applicable fiber / cable diameter: 0.25mm to 3.0mm/Indoor Cable
＊ Applicable fiber diameter: Cladding diameter: 80mm to 150μm / Coating
diameter:125 to 1000μm

Splice Loss

Same fiber is spliced, measured by cut-back method relevant to ITU-T standard.
The typical values of splice loss are:
＊ SM:0.02dB
＊ MM:0.01dB
＊ DS:0.04dB
＊ NZDS:0.04dB
＊ G.657:0.02dB

Splice Mode

＊ It can be preset 45 kinds of splice mode.
＊ It can store 10000 records of the latest splice results.
＊ Splice time: SM Quick mode: 6s.

Heat Oven

＊ 5 kinds of applicable protection sleeve: 20mm, 30mm, 40mm, 50mm, 60mm
＊ Heating time: 20 to 900s optional.
＊ Typical heating time: 20s.
＊ Fast heating time: 9s.
＊ Heating mode: various in-built heat modes available
＊ Heater: Specific heater for VIEW8+ fusion splicer.

Power Supply

＊ Standard AC power voltage: AC 100 to 240V, 50 to 60Hz；
＊ Standard DC power voltage: DC 19V to 3.42A

Size and Weight

＊ Size：Length×width×height= 157mm×144mm×162mm
＊ weight：2.78kg (battery included)
