① After you have selected [Arc Calibration] in maintenance menu, an image of [Arc

Calibration] will be displayed on the screen.

② Set prepared fibers on the splicer, press [S] button to begin ARC Calibration.

③ After Arc calibration, 2 numeric values will be displayed on the screen. When

values on the right side are up to 11±2, the splicer will prompt out message

for completion, otherwise the fiber needs to be cleaved again for Arc discharge

calibration till message for completion prompted out.

This function is used to set electrode. Electrodes are recommended to be replaced

with new one every 4500 times' splicing operation to ensure splice quality.

① Enter into [Maintenance Menu] to select [Electrode Setting].

② Set electrode caution and electrode warning.

Parameter

Electrode caution

Electrode warning

① Select [Update Software] in the [System Setting] interface.

② After you have clicked [OK], the splicer will automatically start the upgrade

process, and the splicer will restart after the upgrade is complete.

PAGE

Note:* Use standard SM, DS or MM fiber for arc calibration.

* Ensure clean fibers for arc calibration. Dust on the fiber

surface affects arc calibration.

When discharge count of electrode more than set count,

message

"caution! Replace

out as you start fusion splicer. The count's parameter is

recommended to be set as "4500".

When discharge count of electrode more than set count,

message

"warning! Replace

out as you start fusion splicer. The count's parameter is

recommended to be set as "5500".
