Error Message List
An error message may appear on the screen when using a splicer, the solution
precisely as shown in the list below. If it is not possible to eliminate the problem,
maybe some faults occur in the fusion splicer. Consult your sales agency.
Error Message
Left Fiber Place
The fiber end-face
Error
is placed on the
electrode centerline,
Right Fiber Place
or beyond it.
Error
The fiber is not
set correctly at
the bottom of the
Press Motor
V-groove. The fiber
Distance Over Limit
is not located in the
Camera's field of
view.
Motor might be
Press Motor Error
damaged.
The fiber is not
Search Fiber End set correctly at
face Failed the bottom of the
V-groove.
Arc Discharge did not
Arc Failure
occur.。
The fiber is not
Align Motor set correctly at
Distance Over Limit the bottom of the
V-groove.
The fiber is not
Search Fiber Clad set correctly at
Failed the bottom of the
V-groove.
Fiber Clad Gap There's dust or dirt
Wrong on the fiber surface
There's dust or dirt
on the fiber surface
Unknown Fiber Mismatch Fibers
Type
Non-standard optical
fibers
Cause
Press the "RESET" button, and
set the fiber end-face between the
electrode centerline and the V-groove
edge.
Press the "RESET" button; re-
position the fiber again to seat
it correctly at the bottom of the
V-groove.
Consult your nearest sales agency.
Press the "RESET" button; re-
position the fiber again to seat
it correctly at the bottom of the
V-groove.
Assure the electrodes are in proper
position; Replace the electrodes.
Press the "RESET" button , re-
position the fiber again to seat
it correctly at the bottom of the
V-groove.
Press the "RESET" button , re-
position the fiber again to seat
it correctly at the bottom of the
V-groove.
Prepare the fiber (stripping, cleaning,
and cleaving) again.
Prepare the fiber (stripping,
cleaning, and cleaving) again.
Use an appropriate splice mode other
than AUTO splice mode to re -splice.
AUTO splice mode can only identify
the standard fibers such as SM, MM,
NZ.
INNO Instrument, Inc.

Appendix II

Solution
