Strobel VTD410EV-SEPC1 Operating Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
For the professional user
Für den professionellen Anwender
Operating Instructions
Betriebsanleitung
Class:
Klasse:
Model:
Ausführung:
Machine number:
Maschinen-Nr.:
Dated:
Stand:
VTD410EV-SEPC1
1
S p e z i a l m a s c h i n e n G m b H

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VTD410EV-SEPC1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Strobel VTD410EV-SEPC1

Summary of Contents for Strobel VTD410EV-SEPC1

  • Page 1 For the professional user Operating Instructions Für den professionellen Anwender Betriebsanleitung Class: VTD410EV-SEPC1 Klasse: Model: Ausführung: Machine number: Maschinen-Nr.: Dated: Stand: S p e z i a l m a s c h i n e n G m b H...
  • Page 2 The sign of quality ou find the Strobel trademark on every Strobel machine leaving our works. And with good reason. This symbol is a guaranteen of the high quality of our products. Quality which creates trust – trust in our technology, our service and, not least of all, in our good name.
  • Page 3 Justify your trust. If you wish to profit from the performance and efficiency of your Strobel machine as long as possible, exact handling and thorough care is necessary. For this reason we kindly request that you read the operating instructions closely.

  • Page 5: Table Of Contents

    Operating Instructions STROBEL Class 410EV-SEPC1 Contents General notes on safety .................... 3 General ........................5 Operating instructions ..................5 Class identification, serial number and orientation of the machine....5 Range of application ..................5 Technical data ....................6 Installation and putting into service ................7 Unpacking the machine ..................
  • Page 6 Operating the machine .................... 21 Right hand treadle ..................21 Operating the gathering device (EV) ............21 5.2.1 Knee lever ..................22 5.2.2 Gathering (left hand treadle) ............22 5.2.3 Operating the shaft coupling for the front cup ........23 5.2.4 Setting the differential feed (Fig.

  • Page 7: General Notes On Safety

    General notes on safety The non-compliance with the following notes on safety can lead to bodily injuries or to damages of the machine. The machine must only be operated by persons familiar with the relevant operating instructions and who have been instructed accordingly. Before commissioning also read the notes on safety and the operating instructions of the sewing drive manufacturer.
  • Page 8 13. Warning notes in the operating instructions of the machine, which point out special points of danger, are marked at the appropriate positions with the safety symbol. Warning notes in the operating instructions of the machine which point out special dangers of injury for operating or qualified staff, are marked at the appropriate positions with the symbol it is essential that you observe and follow these notes as well as the generally valid safety regulations.

  • Page 9: General

    General Operating instructions Any person involved in the installation, operation, maintenance and repair of the machine must have read and understood the operating instructions and mainly the safety instructions before starting the machine. Class identification, serial number and orientation of the machine The operating side of the machine is the starting point for the description referring to sides.

  • Page 10: Technical Data

    Technical data Speed: max. mechanically admissible 1800 min Recommended rated speed 1500 min Min. Motor power 550 W Machine/pulley diameter dw 80 V-belt profile 10 x 6 mm Stitch length 3 – 8 mm Kind of stitch single thread overseam Needle system Needle size 120 –...

  • Page 11: Installation And Putting Into Service

    Installation and putting into service Unpacking the machine The machines of the series 400 are only supplied complete. The thread stand, oil and other machine tool accessories located with in the package. Make sure that all accessories have been unpacked before throwing away any packing material.
  • Page 12 Fig. 1 BA_VTD410EV-SEPC1_A1_140417_en...

  • Page 13: Sense Of Rotation

    Sense of rotation The correct sense of rotation of the hand wheel is clockwise in line of vision on the hand wheel. Motor drive via V-belts 3.4.1 Tensioning the V-belt C a u t i o n ! Danger of injury! When checking the belt tension, switch off the machine at the mains.
  • Page 14 Fig. 2 To adjust or remove, loosen the two clamping screws (2), Fig. 3. Retighten them well before restarting. Fig. 3 The proper position of the position transmitter to the flange is marked with a spot of paint. BA_VTD410EV-SEPC1_A1_140417_en...
  • Page 15 Positions: The machine requires two needle positions and, depending on sewing drive, possibly also a reference position. Reference position (if necessary, e.g. sewing drive DC1500-AB322A (Fig. 4)): The reference position needs to be set so that the tip of the needle concludes with the outer transport table edge in the direction of the piercing.
  • Page 16 Needle position (when stop in the stitch (Fig. 6)): This needle position is important when stopping in the stitch (pedal position 0), when swiveling in the separating plate of the hold-back device and for the threading. The needle position needs to be set so that the tip of the needle concludes at a distance of 10 mm after the transport table edge in the direction of the piercing.

  • Page 17: Lubrication

    193.0473 of the pump (Fig. 7). Fig. 7 The special STROBEL oil (viscosity 46 c St) supplied with the machine should always be used. The oiling points are lubricated automatically, thus no maintenance is required (see also point “6.1 Checking the oil leve/oil quantity”).

  • Page 18: Instructions For Use

    G u a r a n t e e d r e m a r k ! This machine has been set and sewn off with genuine Strobel needles. No guarantee can be granted if the settings are modified for using different needle types.
  • Page 19 Fig. 8 Fig. 9 BA_VTD410EV-SEPC1_A1_140417_en...

  • Page 20: Threading And Thread Courses

    Threading and thread courses A T T E N T I O N ! Danger of bodily injuries Switch off machine electrically and confirm that the machine is really in standstill position by operating the treadle for the motor control before threading. Otherwise danger of finger bruises and needle through stitches.
  • Page 21 The thread course is as follows (Fig. 10): Put the thread reel over the supporting bolt of the reel stand and pull the thread end through the eye of bow 294.0052. Guide the thread through the rear eyes of the thread guide 116.0355 (through 1 to 3 eyes depending on the thread) and the thread tension discs 184.0049, through the front eye of thread guide 116.0355 to the thread tensions discs 184.0049 of the front thread tension device, then through thread retaining spring 163.0008 (when sewing certain...

  • Page 22: Thread Tension

    Fig. 11 Thread tension The thread tension is regulated by means of the tension nut 279.0624 (Fig. 10) depending on the thread type, quality and thickness. A thick and strong thread requires a tight thread tension. BA_VTD410EV-SEPC1_A1_140417_en...

  • Page 23: Setting The Stitch Length

    Setting the stitch length A T T E N T I O N ! Switch off the machine electrically and make sure that the machine is really in standstill position by stepping the treadle for the motor control before setting the stitch length.

  • Page 24: Setting The Material Guide

    Setting the material guide A T T E N T I O N ! Switch off machine electrically and make sure that the machine is really in standstill position by stepping the treadle for the motor control. Otherwise: DANGER of finger bruises and danger of injuries through the screw driver.

  • Page 25: Operating The Machine

    Operating the machine The machine is operated with an electronic-pneumatic control. The operation is very easy: Right hand treadle By means of the right hand treadle the motor is operated, the front cup is opened and the needle is positioned. The process is as follows: Usually the front cup is opened.

  • Page 26: Knee Lever

    5.2.1 Knee lever By means of the knee lever the partial cup opening needed for the swivelling of the gathering device is operated. The front cup opens up to the previously set extent (setting see point “3.6.2.2 Mounting of pneumatically controlled shaft” in mechanics instruction).

  • Page 27: Operating The Shaft Coupling For The Front Cup

    5.2.3 Operating the shaft coupling for the front cup To eliminate the blocking effect between material and feed cups, mainly when sewing a small radius (heel parts) caused by the double feed system, the front cup drive is equipped with a shaft coupling which can be operated electro pneumatically by means of the left hand treadle.

  • Page 28: Inserting And Removing The Fabric

    Inserting and removing the fabric A T T E N T I O N ! The operating personnel should observe the sewing range carefully during the sewing. Otherwise: DANGER of finger bruises and needle through stitches/punctures. When the machine is in standstill position and the needle is placed approx. 7 mm within the feed cup, by opening the front cup up to approx.

  • Page 29: Machine Maintenance

    Machine maintenance A T T E N T I O N ! Switch off the machine electrically and confirm that the machine is really in standstill position by stepping the treadle for the motor control. Otherwise: DANGER of finger bruises and needle through stitches/punctures.

  • Page 30: Oil Drain Tube

    Oil drain tube For easier machine maintenance there is a oil draining tube 133.0742 going through a table plate boring at the lower cover, i.e. waste oil can be drained without the necessity to dismantle the machine head. Oil drain tube 133.0742 is sealed by means of an oil retainer ring 190.0124 and a screw 170.0900 (Fig.
  • Page 31 Class VTD410EV-SEPC1 Standard Optional Extra for California shoes 182.0252 182.0254 feed cup saw-teethed feed cup saw-teethed Ø68,8 mm, pitch 2,25 mm Ø68,8 mm, pitch 2,25 mm Optional Extra for California shoes 182.0255 feed cup Ø68,8 mm, pitch 1,5 mm Optional Extra...
  • Page 35 Und wir können noch mehr für Sie tun! Unser Lieferprogramm bietet für jede Branche und jegliche Anforderung genau die richtige Problemlösung. And we can do a lot more for you! Our range offers the correct problem solution for every branch and for all requirements. Für die Bekleidungs- Für die Schuh- Für die Polster-...
  • Page 36 Then phone, write or simply come and see us. You can have further information about our products at any time, or experience the Strobel machines live in our show room. We’re looking forward to meeting you! Spe zi a l ma s c hine n G m bH...
