Constructions O - I
Z.I. La Plaine des Isles - F 89000 AUXERRE - FRANCE
Tel. : +33 (0)3.86.49.86.30 - Fax : +33 (0)3.86.49.87.17
contact@mouvex.com - www.mouvex.com
AK PUMPS
INSTRUCTIONS 1003-E00 e
Section
1003
Effective
September 2012
Replaces
September 2011
Original instructions
INSTALLATION
OPERATION
MAINTENANCE
Your distributor :
Advertisement
Table of Contents
Related Manuals for Mouvex AK Series
Summary of Contents for Mouvex AK Series
- Page 1 Replaces September 2011 Original instructions AK PUMPS Constructions O - I INSTALLATION OPERATION MAINTENANCE Your distributor : Z.I. La Plaine des Isles - F 89000 AUXERRE - FRANCE Tel. : +33 (0)3.86.49.86.30 - Fax : +33 (0)3.86.49.87.17 contact@mouvex.com - www.mouvex.com...
-
Page 2: Table Of Contents
ECCENTRIC PISTON PUMP MOUVEX PRINCIPLE SAFETY, STORAGE, INSTALLATION AND MAINTENANCE INSTRUCTIONS MODELS : AK O - AK USED PRESSURE UNITS Unit with suffix "g" : Unit without suffix : Gauge pressure, given regarding to atmospheric pressure Differential pressure, for example, pressure difference between (~101325 Pa, taken at 1 bar / 14,5 psi in this IOM). -
Page 3: Overall Dimensions
1. OVERALL DIMENSIONS Weight : 41 kg Bypass valve. Connection of heating jacket Space required for removing front cover. Draining port for heating jacket 2 threaded holes G1” B.S.P. Heating fluid : Pump plate. Steam : • Inlet ....U2 Mounting point for probe : M6 - threaded width : max. -
Page 4: Installation
2.3 Piping assembly personal injury or property damage. WARNING The MOUVEX pump is reversible; this allows it to always circulate the liquid in the desired direction by choosing FAILURE TO RELIEVE THE SYSTEM the corresponding direction of rotation. PRESSURE PRIOR TO PERFORMING... -
Page 5: Single Bypass
2. INSTALLATION (continued) 2.5 Single bypass 2.8 Anchoring the pump units The correct seating of the pump is vital for its efficient WARNING operation and its longevity. The surface must be resistant enough to absorb the FAILURE TO RELIEVE THE SYSTEM stresses due to the pump unit without deformation. -
Page 6: Electric Motors
2. INSTALLATION (continued) The 3 figures below show the operation clearly. This fundamental checking of the pump must be done without any product, with the inlet and outlet circuit open Carry out a control on 4 points: to the air, for example, to avoid any risk of an unexpec- At the top - at the bottom - on the left - on the right ted pressure rise. -
Page 7: Use
3. USE 3.1 Storage In the case where the pumping circuit is situated bet- ween isolating valves and/or has a check valve, you In the case of prolonged shutdown or storage, we must bear in mind the variations in temperature that can recommend dismantling the pump and greasing it tho- occur, leading in particular to the expansion of the pro- roughly. -
Page 8: Opening The Pump To Inspect The Cylinder/Piston And Bushings
4. OPENING THE PUMP TO INSPECT THE CYLINDER/PISTON AND BUSHINGS Before opening the pump, always ensure that it has been drained and release the pressure it may contain. Make sure the isolation valves, if any, are closed before pulling out the drain plug 434 and its seal 412. WARNING WARNING DISCONNECTING THE FLUID OR PRES-... -
Page 9: Necessary Tools
4. OPENING THE PUMP TO INSPECT THE CYLINDER/PISTON AND BUSHINGS (continued) Serial Nbr Bypass fastening For the SEALS refer to the specified drawing WARNING 4.3 Removing the piston and cylinder Remove the sleeve 521 by using the nut 523 to release it. Extract the piston 301 from the cylinder 201 (you may BE CAREFUL WITH THE WEIGHT OF have to use a lever to separate the piston from the cylin-... -
Page 10: Mechanical Seals
5. MECHANICAL SEALS comprising : comprising : WARNING 5.1 Operation Shaft 501 drives the one piece rotating part 697 (inclu- ding parts 612, 613, 614, 615 and 616) in a rotary DISCONNECTING THE FLUID OR PRES- SURE CONTAINMENT COMPONENTS motion. To do this, the rotating part is equipped with 2 DURING PUMP OPERATION CAN CAUSE lugs that fit into 2 grooves provided for this purpose on SERIOUS PERSONAL INJURY, DEATH... -
Page 11: Assembly
1. Dismantle the coupling of the pump. ry part of the seal 604. For the standard coupling supplied by MOUVEX, loo- 4. Clean the surface of the seal with a soft cloth if it is sen the hexagonal socket head screws, and by repla- dirty. -
Page 12: Bypass
6. BYPASS CAUTION 6.1 Operation The compensated bypass operates like a safety valve, by automatically limiting the discharge pressure at the THE PUMP LUBRICANT IS VERY SLIPPERY value for which it is adjusted. AND MAY CAUSE SERIOUS INJURY. When the discharge pressure reaches the adjusted ANY SPILLS MUST BE CLEANED UP. -
Page 13: Inversion
6. BYPASS (continued) Loading (bar) Spring Mini Maxi N°3 N°5* * Only available construction O. 6.3 Inversion Before commencing work, make sure that the pump cannot be started up, even accidentally. Before opening the pump, it must be drained and relieved of any pressu- WARNING re it may contain. -
Page 14: Obtaining The Flow
7. MAINTENANCE 7.1 Greasing 7.2 Checking of parts Except for special cases, the MOUVEX pump only requi- The piston 301 and the cylinder 201 are active parts res lubrication of the shaft inlet bearing. (wearing parts). These parts must be replaced if the thickness measurements are lower than the following Use a grease for good quality ball bearings. -
Page 15: Drilled Piston Pump
8. DRILLED PISTON PUMP Drilling the piston permits the circulation of the product behind If the rotation direction of the pump requires the standard the piston and therefore avoids any "dead" zone. assembly to be changed, open the plugged hole by removing the screw and use the screw to close the other hole on the It also helps to avoid any over-pressure problems related to ®... -
Page 16: Troubleshooting
10. TROUBLESHOOTING ZERO OR INSUFFICIENT FLOW PRELIMINARY CHECKS Make sure that the plastic plugs have been taken away from the ports of the pump and that the pump is running (defective drive, damaged motor, etc., faulty transmission : broken coupling, sliding belt, worn or poorly coupled clutch, etc.). - Page 17 10. TROUBLESHOOTING (continued) MEASURING THE VACUUM PRESSURE (as close as possible to the pump inlet, inlet side). If the vacuum is high, e.g. higher than or equal to 6 to 7 metres WC (0.6 to 0.7 bara i.e. about 45 or 50 cm of mercury), this can result in pump noise.
- Page 18 10. TROUBLESHOOTING (continued) ABNORMAL NOISES These noises can be caused by hydraulic and mechanical sources. They can be distinguished by the fact that only the former disappear (or at least lessen) when air is allowed into the inlet pipe. HYDRAULIC NOISES These noises can come from insufficient product being supplied to the pump, or : - the rotation speed is too high for the installation conditions (increase of viscosity due to a change of product or a reduction of temperature, etc.).
-
Page 19: Certificate Of Conformity
11. CERTIFICATE OF CONFORMITY NT 1003-E00 09.12 AK O - AK I e 19/19...
