HMC3-M1210P0201

Configuration

Use MAPware-7000 to assign input (X and XW), output (Y and YW) and configuration (M and MW) memory
addresses to the module. These addresses are created according to the slot location of the module, where nn
refers to the slot number (ex. 01...05):
Function
X0-X11 Digital Inputs
Y0-Y9 Digital Outputs
High-speed Counter Option
HSC Input Pin
Quadrature Inputs
Counter Inputs
HSC Configuration Register
HSC Counter Register (Current Value)
HSC Preset Register
HSC Enable Bit
HSC Reset Bit
Output Flag
PWM Outputs
Output
PWM Configuration Register
Frequency Setting Register
ON Duty Setting Register (Duty Cycle)
Pulse Enable Flag
ON Duty Setting Error Flag
Frequency Setting Error Flag
Analog Inputs
Input Channel 0 Data
Input Channel 1 Data
Input Channel 0 Config Register
Input Channel 1 Config Register
Analog Outputs
Output Channel 0 Data (Voltage)
Output Channel 0 Data (Current)
Output Channel 0 Config Register
Reference the table below when configuring each HSC Configuration Register:
Input Mode
Normal Input
High Speed,
Single Phase,
Up/Down Counter
Quadrature 4X
HMC3000 Series I/O Module Guide
Xnn000-011 (XWnn00)
Ynn000-009 (YWnn00)
HSC Channel 1
X0
Pair 1
X0, X1
MWnn00
MWnn01
MWnn03
Mnn080
Mnn081
Y2
Channel 1
Y0
MWnn24
MWnn25
MWnn27
Mnn576
Mnn466
Mnn467
Output Mode
N/A
Output ON when preset is reached
Output ON when counter is enabled,
OFF when preset is reached
Output ON when preset is reached
Output ON when counter is enabled,
OFF when preset is reached
Register
HSC Channel 2
X2
Pair 2
X2, X3
MWnn06
MWnn07
MWnn09
Mnn176
Mnn177
Y3
Channel 2
Y1
MWnn30
MWnn31
MWnn33
Mnn577
Mnn471
Mnn472
Register
XWnn11
XWnn13
MWnn60
MWnn61
Register
YWnn01
YWnn02
MWnn68
51
Access
Read Only
Read/Write
Read Only
Read Only
Read/Write
Read/Write
Read/Write
Read/Write
Read/Write
Read Only
Read/Write
Read/Write
Read/Write
Read/Write
Read Only
Read Only
Read Only
Read Only
Read/Write
Read/Write
Read/Write
Read/Write
Read/Write
Register Value
0
2
258
131
387
