Smiths Medical CADD-Solis Quick Reference Manual

Ambulatory infusion pump with wireless communications, using code or key
Hide thumbs Also See for CADD-Solis:

Advertisement

Table of Contents

See also: Operator's Manual , Quick Reference Manual
B
C
D
E
F
G
Ambulatory Infusion Pump with
Wireless Communications
Quick Reference Guide using Code or Key
Battery Compartment
A
Display
B
Indicator Lights
C
USB Port
D
Blue AC Power Light
E
AC Power Jack
F
Remote Dose Cord Jack
G
CADD
Version 4.0 or higher
-Solis
®
Keypad
H
Cassette Latch
I
Cassette/Keypad Lock
J
Power Button
K
Wireless Communication
L
Module
Wireless Indicator
M
L
A
M
K
J
I
H

Advertisement

Table of Contents
loading

Related Manuals for Smiths Medical CADD-Solis

Summary of Contents for Smiths Medical CADD-Solis

  • Page 1 CADD -Solis ® Ambulatory Infusion Pump with Wireless Communications Quick Reference Guide using Code or Key Version 4.0 or higher Battery Compartment Keypad Display Cassette Latch Indicator Lights Cassette/Keypad Lock USB Port Power Button Blue AC Power Light Wireless Communication Module AC Power Jack Wireless Indicator...
  • Page 2 Setting up the pump for a new patient Prepare the pump for a new patient Confirm one of these power sources is inserted into the battery compartment: four new 1.5 volt AA alkaline batteries, rechargeable battery pack, or wireless communication module. Begin without the cassette attached to the pump.
  • Page 3 Changing a patient’s current program while the pump is running With the pump running, all parameters can be changed except reservoir volume Edit the program Scroll  or  to highlight the patient specific parameter you want to change. Press Select. Unlock the keypad using the security code or the pump key.
  • Page 4 Changing a patient’s current program with the pump stopped continued Continue until all patient specific parameters have been reviewed, accepted and display checkmarks. Press Next. “Start Pump?” displays. Press Yes. NOTE: If a security code was used to unlock the keypad, the keypad automatically relocks when the pump is started.

  • Page 5: Viewing Reports

    Clinician bolus Pump must be running From the home screen press Tasks. “Give Clinician Bolus” is highlighted. Press Select. Enter the clinician security code. The screen displays the clinician bolus scroll range available. Scroll  or  until the desired value appears. Press Deliver.

  • Page 6: Changing The Batteries

    Managing battery status Battery State Battery Image Alarm Message Fully or nearly fully charged With AA batteries ~50% charge With AA and AC adapter Low battery Battery low, replace battery <25% charge Recharge the wireless Pump emits 3 communication module or the Rechargeable beeps every 5 rechargeable battery pack, or...

  • Page 7: Screen Saver

    Screensaver The screensaver allows the pump to conserve battery power when not in an edit mode and if no keypad buttons have been pressed for 30 seconds. The pump displays a blank screen. Press any button on the keypad, except the PCA (PCEA) dose key, to turn the display on Wireless status, if Communication Module is installed...

  • Page 8: Troubleshooting

    Alarms and troubleshooting continued Troubleshooting Screen is blank and alarm is sounding Alarm Priority High. The pump has lost power and is no longer delivering. The pump was delivering and the batteries were removed or the battery door was opened. Clear this alarm by replacing the batteries or closing the battery door, if not using the Communication Module, then turn the pump back on.
  • Page 9 Alarms and troubleshooting continued Delivery pauses and resumes if the occlusion is removed. Remove the obstruction or stop the pump to silence the alarm for 2 minutes, then remove the obstruction and restart the pump. Reservoir volume low Alarm Priority Medium or Low (Depending on how the alarm is programmed in Admin Settings).
  • Page 10 Find your local contact information at www.smiths-medical.com/customer-support Smiths Medical is part of the global technology business Smiths Group plc. Product(s) described may not be licensed or available for sale in all countries. CADD and the Smiths Medical design mark are trademarks of Smiths Medical. The symbol ® indicates the trademark is registered in the U.S.
