  • Page 1 System Operating Manual FUJITSU Workstation CELSIUS M770 / M770power...
  • Page 2 Thank you for buying an innovative product from Fujitsu. Latest information about our products, useful tips, updates etc. is available on our website: "http://www.fujitsu.com/fts/" You can find driver updates at: "http://support.ts.fujitsu.com/download" Should you have any technical questions, please contact: •...
  • Page 4 Published by / Contact address in the EU Fujitsu Technology Solutions GmbH Mies-van-der-Rohe-Straße 8 80807 Munich, Germany "http://www.fujitsu.com/fts/" Copyright © Fujitsu Technology Solutions GmbH 2017. All rights reserved. Publication Date 11/2017 Order No.: A26361-K1507-Z320-1-7619, edition 1...
  • Page 5 FUJITSU Workstation CELSIUS M770 / M770power Operating Manual Your CELSIUS... Ports and operating elements Important notes Getting started Rack mounting (optional) Operation Troubleshooting and tips System expansions Technical data Index...
  • Page 6 Information on the product description meets the design specifications of Fujitsu and is provided for comparison purposes. Several factors may cause the actual results to differ. Technical data is subject to change without prior notification. Fujitsu rejects any responsibility with regard to technical or editorial mistakes or omissions.

  • Page 7: Table Of Contents

    Fujitsu rack systems ........
  • Page 8 Install loudspeaker ..............91 Fujitsu...
  • Page 9 Index ................. . 99 Fujitsu...
  • Page 10 Contents Fujitsu...

  • Page 11: Your Celsius

    "BIOS Setup" manual • • in the operating manual for the monitor • in the manual for the mainboard • in the documentation for your operating system in the information files (e.g. *.PDF, *.HTML, *.DOC, *.CHM, *.TXT, *.HLP) • Fujitsu...

  • Page 12: Notational Conventions

    Do This font not switch off the device Validity of the Reference Manual This Reference Manual is valid for the following systems: • FUJITSU Workstation CELSIUS M770 • FUJITSU Workstation CELSIUS M770power Fujitsu...

  • Page 13: Ports And Operating Elements

    3 = Module bay for an UltraSlim drive 9 = Headset jack 4 = Module bay for a 5 inch drive 10 = Casing lock (optional) 5 = On/Off switch 11 = Hard disk cover 6 = Slot for memory cards 12 = Side cover latch Fujitsu...
  • Page 14 3 = Module bay for an UltraSlim drive 9 = Casing lock (optional) 4 = Module bay for a 5 -inch drive 10 = Hard disk cover 5 = ON/OFF switch 11 = Side cover latch 6 = 2 x USB port 2.0 (USB Type-A™) Fujitsu...

  • Page 15: Rear

    Ports and operating elements Rear 1 = Holes for a padlock 4 = Device for a Security Lock 2 = Ports for external devices 5 = Alternating voltage socket (AC IN) (device-dependent) 3 = Slot covers / boards Fujitsu...

  • Page 16: Important Notes

    If the device is brought from a cold environment into the room where it will be used, condensation may occur. Before operating the device, wait until it is absolutely dry and has reached approximately the same temperature as the installation site. Fujitsu...

  • Page 17: Cleaning The Device

    Energysaving Recycling You can find information on these subjects in the "Environment and Energy Information" manual or on our website ("http://www.fujitsu.com/fts/about/fts/environment-care/"). Note on the European Ecodesign Directive The hibernate state (Advanced Configuration and Power Interface ACPI S4 Save-to-disk) is not available for workstations in certain configurations. As a consequence, it is not possible for these systems to switch off automatically according to the Ecodesign directive.

  • Page 18: European Emc Standard En 55032 (Information Technology Equipment - Radio Disturbance Characteristics - Limit Values And Methods Of Measurement)

    This equipment may cause radio interference in residential areas. In this case, the operator can be requested to take appropriate measures. Fujitsu CELSIUS workstations with a model number ending with "n" are subject to certain restrictions. It is possible that these devices do not fulfil some requirements, e.g. Energy Star.

  • Page 19: Getting Started

    Drives and boards If you have received drives or boards with your device, please do not install them until after first-time setup. How to install drives and boards is described in the "System expansions", Page 41 chapter. Fujitsu...

  • Page 20: Setting Up The Device

    A minimum distance of 200 mm / 7.87 in from the device must be observed for ventilation areas. Do not stack several devices on top of each other. Do not expose the device to extreme ambient conditions (see "Technical data", Page section "Ambient conditions"). Protect the device against dust, humidity and heat. Fujitsu...

  • Page 21: Remove The Transport Lock (Configuration Dependent)

    ► Remove the hard disk cover (see "Remove the hard disk cover", Page 54). ► Remove the transport lock. ► Secure the hard disk cover (see "Secure the hard disk cover", Page 55). Fujitsu...

  • Page 22: Connecting The Machine To The Mains

    Getting started Connecting the machine to the mains Mainsadapter, ► Connect the mains cable to the machine (1). ► Plug the mains plug into a three-pin socket (2). Fujitsu...

  • Page 23: Connecting External Devices

    : black USB Type 3.0 - Universal Serial Bus: black USB Type 2.0 - Universal Serial Bus: black UniversalSerialBus Some of the connected devices require special software (e.g. drivers) (refer to the documentation for the connected device and operating system). Fujitsu...

  • Page 24: Connecting A Monitor

    1 = Screen connections of the graphics card (display adapter) ► Follow the instructions contained in the monitor manual to prepare the monitor for operation (e.g. connecting cables). ► Plug the data cable into a suitable monitor port of the device. Fujitsu...

  • Page 25: Connecting A Usb Mouse

    Plan a reasonable amount of time for this, as this process must not be interrupted. You may need the licence number for Windows during the installation. You can find the licence number as a label on your device (no longer applies to Windows 8 or higher). Fujitsu...

  • Page 26: Switch On The Monitor And The Machine

    Help in your operating system. For more information on the system as well as drivers, utilities and updates, see the "Drivers & Utilities" DVD or go to "http://www.fujitsu.com/fts/support". You can find information and help on the Windows operating system functions on the Internet at "http://windows.microsoft.com".

  • Page 27: Rack Mounting (Optional)

    Type IEC 309 connection plug, the fusing of the power supply network must meet the requirements for non-industrial power supply networks for plug type A. Fujitsu rack systems The following Fujitsu rack systems support the installation of CELSIUS workstations: • PRIMECENTER Rack •...

  • Page 28: 3Rd Party Racks

    ► Lay the device as shown below, on a stable, flat and clean surface. If necessary, place a slip-resistant cloth on this surface to prevent the device from being scratched. ► Remove the screws (1). ► Lift the casing cover off the casing (2). Fujitsu...
  • Page 29 Rack mounting (optional) ► Secure the corresponding rack panel on the top of the device using the screws. ► Secure the corresponding rack panel on the bottom of the device using the screws. Fujitsu...
  • Page 30 Rack mounting (optional) ► Mount the device in the rack according to the operating manual for the particular rack system. Make sure that the casing cover is facing upwards after mounting in the rack. Example: Fujitsu...

  • Page 31: Operation

    The ON/OFF switch does not disconnect the device from the mains voltage. For complete disconnection from the mains voltage, you must pull the mains plug out of the socket. ► If necessary, switch the monitor off (see the operating manual for the monitor). Fujitsu...

  • Page 32: Indicators On The Device

    The device is switched off (disconnected from the mains) or is ready to operate. If the device is ready to operate, it can be switched on with the ON/OFF switch. Hard disk indicator The indicator lights up when the hard disk drive in the device is being accessed. Fujitsu...

  • Page 33: Keyboard

    With some keyboards the ON/OFF switch can only be used with an ACPI (Advanced Configuration and Power Management Interface). Otherwise the key is inoperative. The mainboard must support this function. Keys, Keys, Keys, Enter key confirms the highlighted selection. The Enter key is also referred to as the "Return" key. Fujitsu...

  • Page 34: Settings In Bios Setup

    In BIOS Setup, you can set the system functions and the hardware configuration of the device. When the PC is delivered, the default entries are valid (see "BIOS Setup" manual or manual for the mainboard). You can customise these settings to your requirements in the BIOS Setup. Fujitsu...

  • Page 35: Property And Data Protection

    Software functions and mechanical locking offer a broad range of functions for protecting your device and your personal data against theft and unauthorised access. You can also combine these functions. Anti-theft protection and lead-sealing Device, Device, Casing, Lead-sealing Anti-theftprotection KensingtonLock Chain 1 = Holes for a padlock Fujitsu...
  • Page 36 Security Lock. Lead-sealing To prevent unauthorised persons from opening the casing, the casing can be lead-sealed. To do this, feed the sealing chain through the holes (1) and seal the chain with the lead seal. Fujitsu...

  • Page 37: Mechanical Casing Lock (Optional)

    Key turned towards the closed lock: The device is locked. • Key turned towards the open lock: The device is unlocked. Locking the casing ► Turn the key towards the closed lock Unlocking the casing ► Turn the key towards the open lock Fujitsu...

  • Page 38: Bios Setup Security Functions

    Protect the device from being switched on by an external device You can also combine these functions. You will find a detailed description of the Security menus and how to assign passwords in the manual for the mainboard or in the "BIOS Setup" manual. Fujitsu...

  • Page 39: Access Authorisation Via Smartcard

    Operation of a SmartCard reader with a RFID reader is not permitted in Taiwan. ► Connect the external SmartCard reader to your system as described in the instructions for the SmartCard reader. SmartCard reader, After the device is switched on, you will be prompted to insert your SmartCard. Fujitsu...

  • Page 40: Troubleshooting And Tips

    ► Contact the Service Desk responsible for your country for clarification of the problem: "http://support.ts.fujitsu.com/contact/servicedesk". When you do this, please have ready the ID number and serial number of your system.

  • Page 41: The Device Cannot Be Switched Off With The On/Off Switch

    ► Restart the system. Incorrect setting for the monitor ► Press while the system is booting. ► Start the system in Safe Mode. ► Set up the monitor as described in the documentation for your operating system and monitor. Fujitsu...

  • Page 42: No Mouse Pointer Displayed On The Screen

    Ventilation duct from hard disks / power supply unit does not engage during installation The ventilation duct (1) can no longer be correctly installed after the installation/removal of system expansions. Cause Remedy Locking slide on the hard drive installation kit ► Close the locking slide. not closed. Fujitsu...

  • Page 43: Service Door Cannot Be Closed

    (see "Replacing the lithium battery", Page 97). Error messages on the screen Error messages and their explanations are provided: • in the technical manual for the mainboard • in the documentation for the programs used Fujitsu...

  • Page 44: Installing New Software

    Tips Topic Out of system resources ► Close unnecessary applications. ► Run the applications in a different order. Fujitsu...

  • Page 45: System Expansions

    An update of the BIOS may be required for a system expansion or hardware upgrade. Further information can be found in the BIOS help section or if necessary in the Technical Manual for the mainboard. Fujitsu...

  • Page 46: Information About Boards

    Never touch pins or conductors on boards fitted with ESDs. Overview of the interior 1 = Ventilation duct with fan unit 4 = Power supply unit 2 = Service door 5 = Board lock 3 = Ventilation duct from hard disks / power supply unit Fujitsu...

  • Page 47: Preparation And Revision Of System Expansion

    ► Remove any plugged-in wires which are in the way. ► Lift the latch (a) in the direction of the arrow (1) and hold it in this position. ► First pull the casing cover in the direction of the arrow (2) and then lift it off the casing. Fujitsu...

  • Page 48: Close The Casing

    ► Slide the casing cover in the direction of the arrow (2) as far as it will go. When doing so, make sure that the eye fits into the opening. ► Fold down the latch on the casing cover (3). ► Connect the cables to the device. Fujitsu...

  • Page 49: Open And Close The Service Door

    Open the service door ► Open the casing (see "Open the casing", Page 43). ► Open the service door in the direction of the arrow. To prevent it folding shut by accident, fix the service door in the open position. Fujitsu...
  • Page 50 ► To release any latching of the service door, press the locking mechanism (1) on the joint of the service door. ► Close the service door in the direction of the arrow (2). ► Close the casing (see "Close the casing", Page 44). Fujitsu...

  • Page 51: Removing And Installing The Ventilation Duct

    To upgrade the main memory or replace the processor you will need to remove the ventilation duct. Removing ventilation duct ► Open the casing (see "Open the casing", Page 43). ► Lift the ventilation duct with the fan unit out of the casing. Fujitsu...
  • Page 52 System expansions Install ventilation duct ► Position the air duct with the fan unit in the guide and slide it into the casing. ► Close the casing (see "Close the casing", Page 44). Fujitsu...

  • Page 53: Remove And Secure The Front Panel

    ► Gently press in the catches on one side of the front panel (1). ► Unhook the catches from the guide openings (a) on the opposite side (b) of the casing (2). ► Remove the front panel from the casing. Fujitsu...
  • Page 54 "Installing an accessible drive", Page 65). ► If present: Install the accessible 5 inch drive (see "Installing an accessible drive", Page 70). ► If present: Install the 3½ inch or 2½ inch reader (see "Installing a module holder with reader", Page 60). Fujitsu...

  • Page 55: Removing And Installing The Front Panel Module

    "Open the casing", Page 43). ► Disconnect the front fan cable from the front panel module (1). ► Press the clip in the direction of the arrow (2). The front panel module will be pushed forward out of the slot. Fujitsu...
  • Page 56 System expansions ► Pull the front panel module completely out of the casing in the direction of the arrow. Fujitsu...
  • Page 57 ► Connect the front fan cable to the front panel module. Make absolutely certain that the polarity of the cable is correct. The connector and the socket are coded. ► Close the casing (see "Close the casing", Page 44). Fujitsu...

  • Page 58: Remove And Secure The Hard Disk Cover

    Remove the hard disk cover ► Press the release button on the front of the hard disk cover (1). ► Fold the hard disk cover in the direction of the arrow (2) and remove it from the casing (3). Fujitsu...
  • Page 59 Secure the hard disk cover ► Put the hard disk cover in the guide openings the direction of the arrow (1). ► Fold the hard disk cover in the direction of the arrow (2) until it is felt to engage. Fujitsu...

  • Page 60: Remove And Install Power Supply

    ► Open the casing (see "Open the casing", Page 43). ► To unlatch the power supply, move the grip on the power supply in the direction of the arrow (1). ► Lift the power supply out of the device (2). Fujitsu...

  • Page 61: Overview Of The Drive Bays And Drives In Your Device

    Front I/O variant 1: One further location for an M.2 module on the front panel module "Accessible drives" are e.g. DVD or CD ROM drives, into which a data medium can be inserted from outside. Examples of non-accessible drives are hard disk drives. Fujitsu...

  • Page 62: Installing/Removing A 3½ Inch Or 2½ Inch Reader (Optional, Smartcard Or Multicard)

    ► Open the casing (see "Open the casing", Page 43). ► Open the service door (see "Open the service door", Page 45). ► Disconnect the cables connected to the module holder. ► Remove the screws on the module holder. Fujitsu...

  • Page 63: Screwing The Reader Onto The Module Holder

    Screwing the reader onto the module holder ► With the component side facing downwards, slide the reader in the direction of arrow (1) into the guide on the module holder (a). ► Fasten the reader with the screws size M3x4.5 (2). Fujitsu...

  • Page 64: Installing A Module Holder With Reader

    Installing a module holder with reader ► Push the module holder into the casing in the direction of the arrow until the screw holes on the casing and the screw holes on the reader are directly one above the other. Fujitsu...
  • Page 65 ► Secure the module holder with the M3 x 4.5 screws. ► Connect the cables to the boards and the mainboard. Make sure the polarity is correct. ► Close the service door (see "Close service door", Page 46). ► Close the casing (see "Close the casing", Page 44). Fujitsu...

  • Page 66: Removing A Module Holder With Reader

    Removing a module holder with reader ► Open the casing (see "Open the casing", Page 43). ► Open the service door (see "Open the service door", Page 45). ► Disconnect the cables connected to the module holder. ► Remove the screws. Fujitsu...
  • Page 67 "Removing the reader from the module holder", Page 64) and install a blind cover in the drive bay. ► Close the service door (see "Close service door", Page 46). ► Close the casing (see "Close the casing", Page 44). Fujitsu...

  • Page 68: Removing The Reader From The Module Holder

    System expansions Removing the reader from the module holder ► Undo the screws (1). ► Pull the reader out of the module holder in the direction of the arrow. Fujitsu...

  • Page 69: Installing And Removing The Ultraslim Drive

    Do not throw away the blind cover. If you remove the drive again later, you must refit the blind cover for the purposes of cooling, fire protection and to prevent the entry of foreign bodies (see "Removing an accessible drive", Page 72). ► Remove the drive plate (1) from the bracket. Fujitsu...
  • Page 70 System expansions ► Connect the drive plate (1) to the drive. ► Slide the drive into the casing until it engages in the locking mechanism. Fujitsu...

  • Page 71: Removing An Accessible Drive

    "Open the service door", Page 45). ► Press the release button in the direction of the arrow (1) and at the same time the latch in the direction of the arrow (2). The drive will be pushed forward out of the slot. Fujitsu...
  • Page 72 System expansions ► Pull the drive completely out of the casing in the direction of the arrow. ► Remove the drive plate (1) from the drive. Fujitsu...
  • Page 73 ► Close the service door (see "Close service door", Page 46). ► Close the casing (see "Close the casing", Page 44). It may be necessary to modify the entry for the drive in the BIOS Setup. Fujitsu...

  • Page 74: Installing And Removing The Accessible 5

    fire protection and to prevent the entry of foreign bodies (see "Remove accessible drive", page 61). ► Remove the drive plate from the bracket. ► Connect the drive plate to the drive (1). Fujitsu...
  • Page 75 ► Connect the cables to the drive. Make sure the polarity is correct. ► Close the service door (see "Close service door", Page 46). ► Close the casing (see "Close the casing", Page 44). It may be necessary to modify the entry for the drive in the BIOS Setup. Fujitsu...

  • Page 76: Removing An Accessible Drive

    "Open the service door", Page 45). ► Disconnect the cables connected to the drive (1). ► Slide the retaining mechanism in the direction of the arrow (2). ► Slide the drive slightly out of the casing from the inside (3). Fujitsu...
  • Page 77 ► Push the drive a few centimetres out of the casing in the direction of the arrow. ► Pull the drive completely out of the casing in the direction of the arrow. ► Remove the drive cover from the drive (1). Fujitsu...
  • Page 78 ► Close the service door (see "Close service door", Page 46). ► Close the casing (see "Close the casing", Page 44). It may be necessary to modify the entry for the drive in the BIOS Setup. Fujitsu...

  • Page 79: Installing The Hard Disk Drive

    ► On devices with a casing lock: Unlock the casing. ► Remove the hard disk cover (see "Remove the hard disk cover", Page 54). ► Unlatch the locking mechanism (1). ► Fold the locking mechanism in the direction of the arrow (2). Fujitsu...
  • Page 80 System expansions ► Pull the hard disk carrier out of the casing. ► Undo the screws (1). Fujitsu...
  • Page 81 "Mechanically lock the hard disk cover on devices without a casing lock", Page 34) and close the casing (see "Open the casing", Page 43). It may be necessary to modify the entry for the drive in the BIOS Setup. Fujitsu...

  • Page 82: Installing A Hard Disk Drive

    "Removing the hard disk drive ", Page 75). ► Place the hard disk drive in the hard disk carrier (1). ► Fasten the screws (2). On delivery, the screws are in the accessories kit. Fujitsu...
  • Page 83 System expansions ► Slide the hard disk carrier into the casing. ► Fold the locking lever in the direction of the arrow. The locking lever must engage. Fujitsu...
  • Page 84 "Mechanically lock the hard disk cover on devices without a casing lock", Page 34) and close the casing (see "Open the casing", Page 43). It may be necessary to modify the entry for the drive in the BIOS Setup. Fujitsu...

  • Page 85: Installing And Removing An M.2 Module

    ► Install the boards (see "Installing a board", Page 87). ► Close the casing (see "Close the casing", Page 44). If necessary, you must adjust the entry for the M.2 module accordingly in the BIOS Setup. Fujitsu...

  • Page 86: Removing The M.2-Module On The Mainboard

    ► Install the boards (see "Installing a board", Page 87). ► Close the casing (see "Close the casing", Page 44). If necessary, you must adjust the entry for the M.2 module accordingly in the BIOS Setup. Fujitsu...

  • Page 87: Install The M.2 Module On The Front Panel Module (Optional)

    ► Install the front panel module (see "Installing the front panel module", Page 53). ► Close the casing (see "Close the casing", Page 44). If necessary, you must adjust the entry for the M.2 module accordingly in the BIOS Setup. Fujitsu...

  • Page 88: Remove The M.2 Module On The Front Panel Module (Optional)

    ► Install the front panel module (see "Installing the front panel module", Page 53). ► Close the casing (see "Close the casing", Page 44). If necessary, you must adjust the entry for the M.2 module accordingly in the BIOS Setup. Fujitsu...

  • Page 89: Installing And Removing A Board

    (3). Push the latch to the side to release the card. You can then remove the card as described below. ► Pull the slot cover out of the slot in the direction of the arrow (4). ► Place the board in suitable packaging. Fujitsu...
  • Page 90 "Close the casing", Page 44). If you have installed or removed a PCI board, please check the relevant PCI slot settings in the BIOS Setup. If necessary, change the settings. Further information is provided in the PCI board documentation. Fujitsu...

  • Page 91: Installing A Board

    "Open the service door", Page 45). ► Fold the board lock upwards (1). ► Remove the screw on the slot cover (2), if one is fitted. ► Pull the slot cover out of the slot in the direction of the arrow (3). Fujitsu...
  • Page 92 ► Close the casing (see "Close the casing", Page 44). If you have installed or removed a board, please check the relevant PCI slot settings in the BIOS Setup. If necessary, change the settings. Further information is provided in the PCI board documentation. Fujitsu...

  • Page 93: Connecting Display Adapters With Additional Power Supply

    This enables the use of a GFX card with 6 and/or 8-pin connectors. If you require other cables, you can purchase these from Fujitsu. The power supply (PSU) installed in the system can supply a continuous 18.5 A for display adapters via any power supply.

  • Page 94: Installing And Removing A Loudspeaker

    "Removing the front panel module", Page 51). ► Press on the tab (1). ► Take the loudspeaker out of the casing in the direction of the arrow (2). ► Install the front panel module (see "Installing the front panel module", Page 53). Fujitsu...

  • Page 95: Install Loudspeaker

    Install loudspeaker Loudspeaker ► Remove the front panel module (see "Removing the front panel module", Page 51). ► Put the loudspeaker into the location (1). ► Install the front panel module (see "Installing the front panel module", Page 53). Fujitsu...

  • Page 96: Installing And Removing Wlan Antennas

    ► Working in the direction of the arrow (1), place the WLAN antennas onto the plug-in positions of the board (2). ► Secure the WLAN antennas by turning in the direction of the arrow (3). ► Align the WLAN antennas as required. Fujitsu...

  • Page 97: Removing Wlan Antennas

    Removing WLAN antennas ► Undo the WLAN antennas by turning in the direction of the arrow (1). ► Pull the WLAN antennas in the direction of the arrow (3) and away from the plug-in positions of the board (2). Fujitsu...

  • Page 98: Installing And Removing Heat Sinks

    You can now replace the processor (see "Replacing the processor", Page 96). Never operate the device without a heat sink! Before initial startup, install the heat sink again in the same way as it was installed in the device before removal. Fujitsu...

  • Page 99: Installing The Heat Sink

    (2). ► Tighten the screws (a) with a torque of 1 Nm. ► Install the ventilation duct (see "Install ventilation duct", Page 48). ► Close the casing (see "Close the casing", Page 44). Fujitsu...

  • Page 100: Mainboard Expansions

    ► Replace the processor as described in the manual for the mainboard. ► Install the heat sink again (see "Installing the heat sink", Page 95). ► Install the ventilation duct (see "Install ventilation duct", Page 48). ► Close the casing (see "Close the casing", Page 44). Fujitsu...

  • Page 101: Replacing The Lithium Battery

    ► Press the catch in the direction of the arrow (1). The battery jumps out of the holder slightly. ► Remove the battery (2). ► Push the new lithium battery of the identical type into the holder (3) and press it down until it engages. Fujitsu...

  • Page 102: Technical Data

    10 mm / 0.39 in with air vents at least 200 mm / 7.87 in The data sheets of these devices contains further technical data. The data sheets can be found on our website at "http://www.fujitsu.com/fts/". Fujitsu...

  • Page 103: Index

    30 Cursor keys 29 Keyboard shortcuts 29 Keyboard, alphanumeric keypad 29 cursor keys 29 Data protection 31 function keys 29 Device numeric keypad 29 Connections 19 Keys 29 setting up 16 Ctrl 30 Switching on 27 Ctrl+Alt+Del 30 Device, Fujitsu...
  • Page 104 Monitor, switching off 27 Transportation 12–13 Note safety 12 Universal Serial Bus 19 Notes Upgrades important 12 Mainboard 96 Numeric keypad 29 Upgrades, device 41 USB devices, connecting 21 ON/OFF switch 29 USB port 21 Overview connecting keyboard 21 Fujitsu...
  • Page 105 Index USB port, connecting devices 21 Workstation 16 Fujitsu...
