Linak BAJL Li-Ion Quick Start Manual

Information
Information on LINAK BAJL Li-Ion battery pack
A user manual with further information is available at
www.linak.com
Safety Information
WARNING!
Risk of Injury or Damage
Improper handling of lithium batteries may cause
injury or damage.
– Do not open the battery housing as damaging
the cell or circuitry may develop excessive heat.
– Lithium batteries that are defective, have been
damaged or might produce excessive heat or
fire, are not allowed for transportation.
– In case the battery turns hot, disconnect it and
avoid contact.
– Do not crush or puncture the batteries as it
may ignite.
Charging the Battery
If the battery is completely discharged, charging will be
started at a very small rate, which is not sufficient to turn
on the LED that indicates charging. Therefore the charging
process might not be indicated from the beginning and it
may take several hours until the LED turns on.
Battery Indicator
When using with a lithium battery, the indicated battery
capacity below 50% may not correspond to the real battery
state.
Standby Mode
When the battery is not used for a longer period (more than
a week), it enters into a standby mode to save power and
protect the battery from deep discharge.
1. To exit the standby mode connect the battery to the
mains (via the control unit or the external charger) for
approximately 15 seconds before use.
Environmental Conditions
IMPORTANT!
If the lift is equipped with a lithium battery the
following environmental conditions apply and
supersede the condition stated in the user manual
and on the label of the lift.
Storage and
transportation
Temperature -10 °C to +40 °C
Relative humidity
Atmospheric
pressure
60124170-C 2020-06-23
1 / 4
Operation
+5 °C to +40 °C
20% to 80% not condensing
800 hPa to 1060 hPa
Invacare Portugal, Lda
Rua Es trada V elha 949
4465-784 Leça do Balio
Portugal
Invacare® Birdie® EVO, Invacare® ISA™
IenI
Weights
Battery Type
BAJL Li-Ion 2.25 Ah
BAJL Li-Ion 4.5 Ah
IMPORTANT!
If the lift is equipped with a lithium battery
the following weights apply and supersede the
weights stated in the user manual and on the
label of the lift.
– The values stated in the following tables are
valid for BAJL Li-Ion 2.25 Ah. For BAJL Li-Ion
4.5 Ah add 0.4 kg.
[kg]
Total weight*
Weight, mast
incl. battery*
* excluding spreader bar
[kg]
Total weight
Weight, mast
incl. battery
Disposal
WARNING!
Environmental Hazard
This product may contain substances that could
be harmful to the environment if disposed of
in places (landfills) that are not appropriate
according to legislation.
– DO NOT dispose of batteries in normal
household waste.
– Batteries MUST be taken to a proper disposal
site. The return is required by law and free of
charge.
– Do only dispose discharged batteries.
– Cover terminals of lithium batteries prior to
disposal.
Weight [kg]
Birdie EVO Birdie EVO
COMPACT
29 38
12 17
179 219
ISA ISA
COMPACT STANDARD
41 46
17 17
185 208
1.0
1.4
Birdie Birdie
EVO EVO
PLUS XPLUS
39 39
17 17
219 249
ISA ISA
PLUS XPLUS
47 50
17 18
230 250
