- Page 1 CBJ-Home Battery Replacement User manual LINAK.COM/MEDLINE-CARELINE Page 1 of 12...
-
Page 2: Table Of Contents
Contents Preface ............................3 Important information ........................4 Safety instructions ......................... 4 General information about JUMBO Home ................... 5 Battery information ........................5 Prior to first use of batteries ......................5 Maintenance of batteries ......................5 Authorised replacement of batteries .................... 5 Tamper proof .......................... -
Page 3: Preface
LINAK systems are high-tech products based on many years of experience in manufacturing and development of actuators, electric control boxes, controls and chargers. This User Manual will tell you how to replace the batteries in your LINAK Control Box JUMBO Home (CBJ-Home). -
Page 4: Important Information
Important information Description of the various signs used in this manual. Warning! Failure to comply with these instructions may result in accidents involving serious personal injury. Failing to follow these instructions can result in the product being damaged or destroyed. Safety instructions Safe use of the system is possible only when the battery replacement is carried out according to the instructions in this user manual. -
Page 5: General Information About Jumbo Home
General information about the JUMBO Home The JUMBO Home (in short CBJ-Home) is a specially developed solution for patient lifts. The complete system consists of a control box and a battery enclosed in a single elegant module. The CBJ-Home is medically approved and contains a series of features ensuring a safe comfortable lift, e.g. -
Page 6: Types Of Batteries That Can Be Used For Replacement
Warranty and battery life If any batteries built into LINAK products are, within a period of 12 months from the production of the LINAK product as stipulated on the product label, found to be defective, LINAK will provide a new ®... -
Page 7: Replacement Of Batteries - Step By Step
Replacement of batteries - step by step: 1. Remove all external cables from the control box 2. Dismount the CBJ-Home. 3. Unscrew and remove the 7 torx screws on the rear of the CBJ-Home. 4. Remove the back cover. Please note that there are two assembly versions (Produced before 1 January 2008) (Produced after 1 January 2008) Note whether the battery poles are pointing downwards... - Page 8 8. Replace the batteries by same type or as (LINAK A/S part number BA0CBJH00 (2 batteries with 1 wireharness)) described in the section “Battery information”. 9. Remount the wires to the new batteries’ poles. (+ = red, - = black).
- Page 9 Please note that the removing of glue residue may take up to 5 minutes. The security label can be bought at LINAK A/S: Article no. 0891021-A, in rolls of 1,000 pcs. 16. Remount the CBJ-Home in the application.
-
Page 10: Disposal Of Batteries
10) must not be blocked or covered as a positive pressure may occur with risk of explosion. Disposal of the batteries The batteries, which are lead-acid batteries, can be returned to LINAK or dispose of in the same way as car batteries. Page 10 of 12... - Page 11 Page 11 of 12...
-
Page 12: Addresses
® without prior notice. LINAK cannot guarantee product availability and reserves the right to discontinue the sale of any product. The user is responsible for determining the suitability of LINAK products for a specific application. All sales are subject to the ‘Standard Terms of Sale and Delivery’, available on LINAK websites.
