  • Page 1 Accessories User Manual LINAK.COM/MEDLINE-CARELINE...

  • Page 2: Table Of Contents

    Rinsing aids ����������������������������������������������������������������������������������������������������������������������������� 28 IPX6 Washable DURA™ ����������������������������������������������������������������������������������������������������������� 29 Cable wash ����������������������������������������������������������������������������������������������������������������������������� 30 General maintenance ........................ 31 Maintenance of all LINAK accessories �������������������������������������������������������������������������������������� 31 Repair and disposal ........................32 Insulation class .......................... 33 Output ratings ........................... 33 Troubleshooting ........................34 BA16 ............................

  • Page 3: Accessories

    Accessories | BA19 ............................40 BA21 ............................43 BA22 Li-Ion ..........................49 DIN Junction Box (DJB) ......................53 Massage Motor ......................... 54 Modular Junction Box - MJB2 ....................55 Modular Junction Box - MJB5 Plus Port Repeater ..............56 Modular Junction Box - MJB5 Plus Port SMPS ................ 63 Modular Junction Box - MJB5 Plus Gateway ................

  • Page 4: Preface

    This User Manual does not address the end user� It is intended as a source of information for the equipment or system manufacturer only, and it will tell you how to install, use and maintain your LINAK product/system� The manufacturer of the end product has the responsibility to provide a User Manual where relevant safety information from this manual is passed on to the end user�...

  • Page 5: Declaration Of Incorporation Of Partly Completed Machinery

    DECLARATION OF INCORPORATION OF PARTLY COMPLETED MACHINERY LINAK A/S Smedevænget 8 DK - 6430 Nordborg LINAK DESKLINE ® LINAK A/S hereby declares that products, characterised by the following models and types: Control Boxes CBD6S Linear Actuators DB5, DB6, DB14, LA23, LA31 Lifting Columns...

  • Page 6: Important Information

    Persons who do not have the necessary experience or knowledge of LINAK products should not use these� Moreover, persons with reduced physical or mental abilities must not use the products, unless they are under surveillance or they have been thoroughly instructed in the use of the equipment by a person who is responsible for the safety of these persons�...

  • Page 7: General Warnings

    Do not use chemicals� Inspect the actuator system regularly for damage and wear� Do not expose LINAK actuator system components to high intensity ultraviolet radiation disinfection lamps� This may damage the enclosure, supporting parts and cables� LINAK actuators and electronics are not designed for use within the following fields: •...
  • Page 8 Accessories | A LINAK control box, actuator and accessory component must, in the final application, be placed where it is not exposed to any impact� This is to prevent damage if a passer-by accidentally hits it with an object or when cleaning the floor with a broom or a mop� On a medical bed e�g� this might be underneath the mattress support platform�...
  • Page 9 Accessories | Be aware that during the design of medical devices, the risk of personal injury (for instance squeezing of fingers or arms) must be minimised� If irregularities are observed, the actuator must be replaced� All cables must be mounted in such a way that they are not trapped or exposed to tension or sharp objects when the application is moved in different directions�...

  • Page 10: General Recommendations

    - Do not sideload the actuator� - Do not step on or kick any LINAK component� When the equipment is not in use: - Switch off the mains supply or pull out the plug in order to prevent unintentional operation�...

  • Page 11: General Warranty Periods

    Batteries are covered by a specific product warranty of 12 months� External products that are not manufactured by LINAK A/S: 12 months are added to the warranty period, for instance for transportation and stocking� Relabelling of these products only takes place, if the production date exceeds one year from the date of dispatch to the customer�...

  • Page 12: Electromagnetic Compatibility (Emc)

    2014/30/EU� The systems are designed to meet all requirements of applicable standards and have been tested to meet IEC 60601-1-2 requirements� Emission: LINAK Actuator Systems are CISPR 11, Group 1, Class B products, comply with IEC 61000-3-2, Class A and IEC 61000-3-3 unless stated otherwise in the relevant section of this document� Immunity: Test levels are according to Professional Healthcare Facility and Home Healthcare Facility Environment�...

  • Page 13: Electrostatic Discharge (Esd)

    ESD� • LINAK can only guarantee the lifetime of ESDS devices if they are handled in the same way from production at LINAK A/S until they are mounted in the manufacturer’s application� It is therefore important that the ESDS devices are not removed from the ESD protected packaging before they are physically within the EPA area at the customer premises�...

  • Page 14: Rf Transmitter/Receiver Properties

    Accessories | 14 RF transmitter/receiver properties Some LINAK products emit RF-power by intention for communication purposes� Frequency band of transmission: 2402 MHz - 2480 MHz Type: BLUETOOTH Low Energy BLE 4�2 ® Modulation: GFSK Maximum Effective Radiated Power (ERP): 10 dBm FCC and IC Statements For RF-emitting products (e�g�...

  • Page 15: Symbols

    Accessories | 15 Symbols The following symbols are used on the LINAK product labels, where applicable: IEC 60417-5172: Compliance to all relevant EC directives Class II equipment IEC 60417-5840: UK Conformity Assessment Applied part type B IEC 60417-5019: Regulatory compliance mark:...
  • Page 16 Accessories | 16 Electrical Testing Laboratories (ETL) marking Due to space limitations, the complete ETL marking demands are not represented on the marking plates� The full ETL recognised component markings are shown here: C/N 120690 C/N 4008004 C/N 4008838 Conforms to ANSI/AAMI Std. ES60601-1 Conforms to ANSI/AAMI Std.

  • Page 17: Batteries

    Do not use or store LINAK battery packs in places where the ambient temperature exceeds 50 °C, such as inside a hot automobile, in direct sunlight, or in front of a stove or a source of intense heat�...

  • Page 18: Lithium Ion Batteries

    LINAK explicitly disclaims lost profits, failure to realise expected savings, any claim against our customers by a third party, or any other commercial or economic losses of any kind, even if LINAK has been advised of the possibility of such damages or losses�...
  • Page 19 Mounting instructions must be followed in order to avoid exposing batteries to water� In general, recharging of battery must take place every 6 months� However, please note: - New Li-Ion batteries, shipped from LINAK are in a deep-sleep state, where the self-discharge is very little...
  • Page 20 Allow the battery to settle to room temperature before use� Lithium ion batteries are not intended for use in outdoor applications and indoor pool environments� If the battery is completely discharged, then recharge the battery before storage� Always use correct LINAK charger DO NOT: Heat or burn the batteries�...

  • Page 21: Lead Acid Batteries

    (silicone ring or joint filler) is not damaged and that it is correctly placed in the groove� Hereafter, the screws in the cover are to be fastened with approx� 1 Nm� If necessary, replacement sealing is available at LINAK� The battery compartment is supplied with ventilation that ensures correct and necessary airing of the battery compartment�...

  • Page 22: System Description

    Connect the different actuators to the different channels on the control box� Each channel is marked with a number (e�g� “1”, “2”, “3”……�)� Check that all plugs are well connected and firmly pushed into the connector� Due to the fact that LINAK® control boxes are designed for a high IP degree, a firm force can be required�...

  • Page 23: General Mounting Of Accessories

    Accessories | 23 General mounting of accessories • The mounting screws on accessories must be tightened with a maximum torque of 1 Nm • The mounting surface to which the accessory is attached should have a surface evenness of more than ±...

  • Page 24: General Environmental Conditions

    If the actuator is assembled in the application and is exposed to push or pull during transportation, the actuator can be damaged� Do not drop a LINAK component or otherwise damage the housing during disassembly or transportation� We do not recommend to use a LINAK component that has been damaged�...

  • Page 25: Information On Start-Up, Deinstallation And Operation

    • The actuator/lifting column system may only be used in an environment corresponding to the IP rating of the system� LINAK products are marked with the actual IP rating on the label� • If any individual parts are suspected to be damaged, do not install the parts, but return them for inspection/service�...

  • Page 26: Cleaning

    Accessories | 26 Cleaning The products can be cleaned as described in the following according to their IP protection stated on the product label� The IP code specifies the protection degree provided by the enclosures� For most products, only the protection against ingress of water (second characteristic numeral) is specified, ingress of solid foreign objects or dust (first characteristic numeral) is not specified and therefore replaced by the letter X in the code�...

  • Page 27: Ipx6 Washable

    Dekotaminationsanlagen)� Description: At LINAK, the washing test takes place in an instrument washing machine, which is fitted and programmed in such a way that it duplicates the process used in a typical hospital installation for the cleaning of beds and other medical equipment�...

  • Page 28: Rinsing Aids

    • They must not contain caustic solutions • They must not change the surface structure or adhesive properties of the plastic • Must not break down grease LINAK washing profile according to LINAK washing machine IEC 60601-2-52 °C 70.0 65.0 60.0...

  • Page 29: Ipx6 Washable Dura

    IPX6 Washable DURA™ Description of washing test LINAK washable products frequently go through a fully controlled washing test� The LINAK term “IPX6 Washable DURA” signifies that the products conform exclusively to this test� The “IPX6 Washable DURA” washing test is used to ensure that products that are rated “IPX6 Washable DURA”...

  • Page 30: Cable Wash

    Accessories | 30 LINAK washing profile for the “IPX6 Washable DURA” process LINAK washing profile according to LINAK washing machine DURA (Note: The temperature is measured at the unit) Cable wash Before the washing procedure starts In order to maintain the flexibility of the cables, it is important that the cable is placed in such a way that the cable’s own weight does not strain the coil...

  • Page 31: General Maintenance

    • LINAK products must be IPX6 Washable and IPX6 Washable DURA when cleaning in wash tunnels • O-rings: When individual parts are replaced in a LINAK IPX6, IPX6 Washable or IPX6 Washable DURA system, the O-rings must be replaced at the same time on all parts� On all products where replaceable cables or fuses have been dismounted or replaced, the O-ring must be replaced, and the O-rings and the receptacle insert must be greased with an acid-free Vaseline�...

  • Page 32: Repair And Disposal

    LINAK service centre� In order to avoid the risk of malfunction, all actuator repairs must only be carried out by an authorised LINAK Service shop or repairers, as special tools and parts must be used�...

  • Page 33: Insulation Class

    When combining LINAK control boxes, battery boxes and power supplies with other LINAK components, compatibility is ensured� When combining LINAK control boxes, battery boxes or power supplies with third party products, special precautions may be taken� In this case, contact LINAK�...

  • Page 34: Troubleshooting

    Accessories | 34 Troubleshooting Symptom Possible cause Action - The actuator is not connnected to - Connect the actuator to the the control box control box No motor sound or movement of piston rod - Blown fuse in the control box - Fuse must be changed - Cable damaged - Send actuator for repair...

  • Page 35: Ba16

    Accessories | 35 BA16 The battery box BA16 is developed for use together with the LINAK CA and CO control box series to support power backup� Usage Compatibility: Battery back-up for COxx and CAxx Duty cycle: 10%, 2 minutes continuous use followed by 18 minutes not in use...
  • Page 36 Accessories | 36 Mounting instructions BA16 must be mounted with M4 screws due to the battery weight� Make sure the surface touching the BA16 mounting surface is flat and use all 4 screws� The diameter of the screw cap must be maximum 8mm� Drawing No.: 0273044-SALES SCALE : 2:1 2 max...
  • Page 37 ® LINAK has performed various battery tests in normal use, abuse, and failure situations to verify design and production methods� These tests have not shown any unacceptable risks�...

  • Page 38: Ba18

    Legacy products : CB6,CB7, CB9, CB12, CB14, CB18, CB6S NOTE: (only specific versions may be compatible) Ambient temperature: +5 °C to +40°C Charging: Via LINAK control box with integrated charging circuit ® Charging time: Approx� 6 hours depending on built-in control box charger...
  • Page 39 Accessories | 39 Warnings • The battery case is only to be opened by authorised staff as incorrect handling may compromise the IP protection� • Take care to always keep the venting channels free� Mounting plates must be rigid to prevent blocking of the venting channels�...

  • Page 40: Ba19

    Accessories | 40 BA19 The BA19 lead acid backup battery has been developed specifically for use with the new control boxes CA30/CA40 and CO61� It is a compact and cost-efficient battery with built-in charger and cable management� Usage Duty cycle: 10%, 2 minutes continuous use followed by 18 minutes not in use Charging: Via integrated charger...
  • Page 41 Accessories | 41 Mounting instructions BA19 must be mounted with attachment screw and mounting bracket (see below) due to the battery weight� Screw M4 countersunk torque 1�1Nm +/- 0�1Nm� ° According to ISO 2009 Mounting bracket (frame flat) - article no. 1015W1001:...
  • Page 42 Accessories | 42 Recommendations • Do not exceed the storage temperature as it will shorten the product life and reduce performance� • Allow the battery to settle to room temperature before use� • Do not exceed the duty cycle 2/18 as it will shorten the life, reduce performance, and eventually activate overcurrent protection�...

  • Page 43: Ba21

    Accessories | 43 BA21 The BA21 Li-Ion back-up battery pack has been specially developed for use with the new control boxes COxx and CAxx, e�g� CO61 and CA40, etc� It is a low weight battery with built-in charger and high performance and safety�...
  • Page 44 Accessories | 44 LED functionality Indication of operation Solid yellow Charging No LED light Fully charged Flashing yellow Error during charging Buzzer functionality The buzzer will make a warning when a button on the hand control is pressed and the battery capacity is low�...
  • Page 45 Accessories | 45 Disconnect the mains cable to the Release the control box off the application Open the lid to the control box by application at the power outlet� releasing the locking clips� by pressing the tab on the mounting clip� Remove the power cable from the control box by inserting a screwdriver into the locking clip marked�...
  • Page 46 12 hours (LED ON), the battery is defect and must be disposed according to disposal instructions� If any and all of the lithium ion batteries built into LINAK products are found to be defective under warranty, LINAK will provide a new product to the OEM� LINAK explicitly disclaims all other remedies� LINAK shall not...
  • Page 47 LINAK Li-Ion batteries for medical use are designed and manufactured to be safe through the product life� LINAK has performed various tests of the batteries in normal use, abuse and failure situations to verify the design and production methods� These tests have not shown any unacceptable risks�...
  • Page 48 Any of the above mentioned can cause fire or injury� LINAK will remedy defective Li-Ion batteries built into LINAK products in accordance with the terms ® stipulated in the LINAK Li-Ion battery disclaimer available on the LINAK website� LINAK explicitly disclaims all other remedies and liability�...

  • Page 49: Ba22 Li-Ion

    The innovative BA22 Li-Ion battery has been specially developed for use with PCP 2�0 control boxes, i�e� CAXX/COXX� It is a low weight battery with built-in charger and high performance� BA22 introduces the new and improved LINAK standard for battery safety� Features and options Weight:...
  • Page 50 Accessories | 50 LED functionality Indication of operation Solid orange Charging No LED light Fully charged Flashing orange Error during charging The LED functionality matrix below describes the battery behaviour when the control box is connected to mains� Information • BA22 is not equipped with a buzzer and is therefore only compatible with PCP 2�0� •...
  • Page 51 LINAK Li-Ion batteries for medical use are designed and manufactured to be safe through the product life� LINAK has performed various tests of the batteries in normal use, abuse and failure situations to verify the design and production methods� These tests have not shown any unacceptable risks�...
  • Page 52 Any of the above mentioned can cause fire or injury� LINAK will remedy defective Li-Ion batteries built into LINAK products in accordance with the terms ® stipulated in the LINAK Li-Ion battery disclaimer available on the LINAK website� LINAK explicitly disclaims all other remedies and liability�...

  • Page 53: Din Junction Box (Djb)

    Accessories | 53 DIN Junction Box (DJB) The DIN Junction Box is designed for use where there is a need for more than 1 or 2 controls to be connected to a control box� The DIN Junction Box is constructed for connection of up to 4 controls with 8-pin DIN plugs�...

  • Page 54: Massage Motor

    Accessories | 54 Massage Motor The massage motor can be added to all kinds of couches and tables, chairs or beds for treatment and examination� It enables comfort, relaxation and tension release for patients and clients� The massage motors are directly connected to the actuator port at the control box –...

  • Page 55: Modular Junction Box - Mjb2

    Operation temperature: +5 °C to +40 °C Storage temperature: -10 °C to +50 °C Compatibility: Compatible with LINAK Bluetooth Low Energy (BLE) control boxes� Please contact LINAK� Relative humidity: 20% to 80% – non-condensing Atmospheric pressure: 700 to 1060 hPa Meters above sea level: Max�...

  • Page 56: Modular Junction Box - Mjb5 Plus Port Repeater

    Modular plug cable, narrow/wide alignment grooves: Modular plug with wide alignment groove� To be used with LINAK products� Can be connected to all ports in the MJB5 Plus, both ports with narrow and wide alignment grooves� Modular plug with narrow alignment groove�...
  • Page 57 Accessories | 57 MJB5 Plus mounting without bracket MJB5 Plus can be mounted directly on the application from the MJB5 Plus side or via the top� It is recommended to use screw type DIN912 M4 for mounting without the bracket� When mounting, ensure that a screw torque limit of 1�0 Nm is not exceeded�...
  • Page 58 Unlocking of cable locking mechanism If a cable needs to be replaced or added, we recommend to open the cable locking mechanism as described below and demonstrated in our video on LINAK�com - MJB5 Plus section brochures and manuals� Video guide available on www�linak�com...
  • Page 59 Accessories | 59 Locking of cable locking mechanism Video guide available on www�linak�com 1� Align the locking mechanism with the MJB5 Plus� 2� Press the cable locking mechanism down until you hear a click sound� CLICK 3� Slide the mechanism forward until you hear another click sound�...
  • Page 60 Accessories | 60 Multi-flexible mounting bracket for MJB5 Plus - article no. 1015W1010-A Drawing no�: 0835012 Mount the bracket on the side or the back of the MJB5 Plus� If it is necessary to dismount the MJB5 Plus from the application, we recommend to use the bracket for mounting�...
  • Page 61 Accessories | 61 The MJB5 Plus bracket is for mounting on the CO and CB OpenBus control boxes� Mounting examples MJB5 Plus with bracket mounted on the side� MJB5 Plus mounted on the side of the control box� MJB5 Plus with bracket mounted on the back� MJB5 Plus mounted on the side of the control box�...
  • Page 62 • There can be a risk of conflict with other OpenBus accessories, such as HB, etc� it is therefore recommended to make a system/bit overview� • When connecting 3rd party products to LINAK systems, the customer must take necessary precautions against Electrostatic Discharge (ESD)�...

  • Page 63: Modular Junction Box - Mjb5 Plus Port Smps

    Accessories | 63 Modular Junction Box - MJB5 Plus Port SMPS The modular junction box MJB5 Plus is designed for use together with OpenBus™ control boxes� The MJB5 Plus makes it possible to connect multiple hand controls and attendant controls� It can even be used for charging or to connect the Under Bed Light and 3rd party products�...
  • Page 64 Accessories | 64 Modular plug cable, narrow/wide alignment grooves Modular plug with wide alignment groove. To be used with LINAK products� Can be connected to all ports in the MJB5 Plus, both ports with narrow and wide alignment grooves� Modular plug with narrow alignment groove.
  • Page 65 Accessories | 65 MJB5 Plus mounting without bracket MJB5 Plus can be mounted directly on the application from the MJB5 Plus side or via the top� It is recommended to use screw type DIN912 M4 for mounting without the bracket� When mounting, ensure that a screw torque limit of 1�0 Nm is not exceeded�...
  • Page 66 Unlocking of cable locking mechanism If a cable needs to be replaced or added, we recommend to open the cable locking mechanism as described below and demonstrated in our video on LINAK�com - MJB5 Plus section brochures and manuals� Video guide available on www�linak�com...
  • Page 67 Accessories | 67 Locking of cable locking mechanism Video guide available on www�linak�com 1� Align the locking mechanism with the MJB5 Plus� 2� Press the cable locking mechanism down until you hear a click sound� CLICK 3� Slide the mechanism forward until you hear another click sound�...
  • Page 68 Accessories | 68 Multi-flexible mounting bracket for MJB5 Plus - article no. 1015W1010-A Drawing no�: 0835012 Mount the bracket on the side or the back of the MJB5 Plus� If it is necessary to dismount the MJB5 Plus from the application, we recommend to use the bracket for mounting�...
  • Page 69 Accessories | 69 The MJB5 Plus bracket is for mounting on the CO and CB OpenBus control boxes� Mounting examples MJB5 Plus with bracket mounted on the side� MJB5 Plus mounted on the side of the control box� MJB5 Plus with bracket mounted on the back� MJB5 Plus mounted on the side of the control box�...
  • Page 70 • There can be a risk of conflict with other OpenBus accessories, such as HB, etc� it is therefore recommended to make a system/bit overview� • When connecting 3rd party products to LINAK systems, the customer must take necessary precautions against Electrostatic Discharge (ESD)�...
  • Page 71 Accessories | 71 MJB5 Plus SMPS Special Recommendations • The USB cable 0834000 is not medically approved� • The MJB5 Plus with SMPS is as standard defined as a 150mA (4W ver�) type� This means that when the SMPS is delivering max� power on port 2, the remaining power on the V permanent is maximum 50 mA� This can have influence when other accessories are connected to the system�...

  • Page 72: Modular Junction Box - Mjb5 Plus Gateway

    Accessories | 72 Modular Junction Box - MJB5 Plus Gateway The modular junction box MJB5 Plus is designed for use together with OpenBus™ control boxes� The MJB5 Plus makes it possible to connect multiple hand controls and attendant controls� It can even be used for charging or to connect the Under Bed Light and 3rd party products�...
  • Page 73 Accessories | 73 Standard functionality The MJB5 Plus Gateway consists of two relays, which are connected through port 5 on the MJB5 Plus� This can be done with the special cable 0964140 (modular plug - open end) There are as standard 2 configurations, 504-010 and 504-020, see description on the next pages�...
  • Page 74 Accessories | 74 Relay 1 Relay 1 is NO when connected to mains and NC when no mains, this means the relay is “active”, when connected to mains (closed loop)� The closed loop principal is to ensure that a notification is sent if power is missing on the bed�...
  • Page 75   Modular plug cable, narrow/wide alignment grooves Modular plug with wide alignment groove. To be used with LINAK products� Can be connected to all ports in the MJB5 Plus, both ports with narrow and wide alignment grooves� with narrow and wide alignment grooves�...
  • Page 76 Accessories | 76 MJB5 Plus mounting without bracket MJB5 Plus can be mounted directly on the application from the MJB5 Plus side or via the top� It is recommended to use screw type DIN912 M4 for mounting without the bracket� When mounting, ensure that a screw torque limit of 1�0 Nm is not exceeded�...
  • Page 77 Unlocking of cable locking mechanism If a cable needs to be replaced or added, we recommend to open the cable locking mechanism as described below and demonstrated in our video on LINAK�com - MJB5 Plus section brochures and manuals� Video guide available on www�linak�com...
  • Page 78 Accessories | 78 Locking of cable locking mechanism Video guide available on www�linak�com 1� Align the locking mechanism with the MJB5 Plus� 2� Press the cable locking mechanism down until you hear a click sound� CLICK 3� Slide the mechanism forward until you hear another click sound�...
  • Page 79 Accessories | 79 Multi-flexible mounting bracket for MJB5 Plus - article no. 1015W1010-A Drawing no�: 0835012 Mount the bracket on the side or the back of the MJB5 Plus� If it is necessary to dismount the MJB5 Plus from the application, we recommend to use the bracket for mounting�...
  • Page 80 Accessories | 80 The MJB5 Plus bracket is for mounting on the CO and CB OpenBus control boxes� Mounting examples MJB5 Plus with bracket mounted on the back� MJB5 Plus mounted on the side of the control box�...
  • Page 81 • There can be a risk of conflict with other OpenBus accessories, such as HB, etc� it is therefore recommended to make a system/bit overview� • When connecting 3rd party products to LINAK systems, the customer must take necessary precautions against Electrostatic Discharge (ESD)�...
  • Page 82 Accessories | 82 MJB5 Plus Gateway Special Recommendations • If the MJB5 Plus Gateway is used as open loop, there is a risk of not sending a notification, when no mains is connected� The MJB5 Plus Gateway will only send a notification if mains is missing, when using a closed loop (see functionality description�) •...

  • Page 83: Modular Junction Box - Mjb5 Plus Ubl (Int.)

    Accessories | 83 Modular Junction Box - MJB5 Plus UBL (int.) The modular junction box MJB5 Plus is designed for use together with OpenBus™ control boxes� The MJB5 Plus makes it possible to connect multiple hand controls and attendant controls� It can even be used for charging or to connect the Under Bed Light and 3rd party products�...
  • Page 84 Accessories | 84 Standard functionality UBL: The UBL LED can be switched on and off via the patient control (Key 1) or the attendant control (Key 2)� External Switch (S1/S2): The external switch is connected to S1: Pin 2 & 8/S2: Pin 2 and 9 on Port 2, Port 4 or Port 5�...
  • Page 85 Accessories | 85 MJB5 Plus mounting without bracket MJB5 Plus can be mounted directly on the application from the MJB5 Plus side or via the top� It is recommended to use screw type DIN912 M4 for mounting without the bracket� When mounting, ensure that a screw torque limit of 1�0 Nm is not exceeded�...
  • Page 86 Unlocking of cable locking mechanism If a cable needs to be replaced or added, we recommend to open the cable locking mechanism as described below and demonstrated in our video on LINAK�com - MJB5 Plus section brochures and manuals� Video guide available on www�linak�com...
  • Page 87 Accessories | 87 Locking of cable locking mechanism Video guide available on www�linak�com 1� Align the locking mechanism with the MJB5 Plus� 2� Press the cable locking mechanism down until you hear a click sound� CLICK 3� Slide the mechanism forward until you hear another click sound�...
  • Page 88 Accessories | 88 Modular plug with wide alignment groove. To be used with LINAK products� Can be connected to all ports in the MJB5 Plus, both ports with narrow and wide alignment grooves� with narrow and wide alignment grooves� Modular plug with narrow alignment groove�...
  • Page 89 Accessories | 89 Multi-flexible mounting bracket for MJB5 Plus - article no. 1015W1010-A Drawing no�: 0835012 Mount the bracket on the side or the back of the MJB5 Plus� If it is necessary to dismount the MJB5 Plus from the application, we recommend to use the bracket for mounting�...
  • Page 90 Accessories | 90 The MJB5 Plus bracket is for mounting on the CO and CB OpenBus control boxes� Mounting examples MJB5 Plus with bracket mounted on the back� MJB5 Plus mounted on the side of the control box�...
  • Page 91 • There can be a risk of conflict with other OpenBus accessories, such as HB, etc� it is therefore recommended to make a system/bit overview� • When connecting 3rd party products to LINAK systems, the customer must take necessary precautions against Electrostatic Discharge (ESD)�...
  • Page 92 Accessories | 92 MJB5 Plus UBL (int.) Special Recommendations • When the MJB5 Plus with UBL, and switch input is being used on a system with battery, the functionality will follow the power-down mode of the control box, see table: OpenBus control box MJB5 Plus with power mode...

  • Page 93: Modular Junction Box - Mjb5 Plus Ubl (Ext.)

    Accessories | 93 Modular Junction Box - MJB5 Plus UBL (ext.) The modular junction box MJB5 Plus is designed for use together with OpenBus™ control boxes� The MJB5 Plus makes it possible to connect multiple hand controls and attendant controls� It can even be used for charging or to connect the Under Bed Light and 3rd party products�...
  • Page 94 Accessories | 94 Standard functionality UBL: The UBL LED can be switched on and off via the patient control (Key 1) or the attendant control (Key 2)� External Switch (S1/S2): The external switch is connected to S1: Pin 2 & 8/S2: Pin 2 and 9 on Port 2, Port 4 or Port 5�...
  • Page 95 Accessories | 95 MJB5 Plus mounting without bracket MJB5 Plus can be mounted directly on the application from the MJB5 Plus side or via the top� It is recommended to use screw type DIN912 M4 for mounting without the bracket� When mounting, ensure that a screw torque limit of 1�0 Nm is not exceeded�...
  • Page 96 Unlocking of cable locking mechanism If a cable needs to be replaced or added, we recommend to open the cable locking mechanism as described below and demonstrated in our video on LINAK�com - MJB5 Plus section brochures and manuals� Video guide available on www�linak�com...
  • Page 97 Accessories | 97 Locking of cable locking mechanism Video guide available on www�linak�com 1� Align the locking mechanism with the MJB5 Plus� 2� Press the cable locking mechanism down until you hear a click sound� CLICK 3� Slide the mechanism forward until you hear another click sound�...
  • Page 98 Modular plug with wide alignment groove. Modular plug with narrow alignment groove. To be used with LINAK products� Can be connected to all ports in the MJB5 Plus, both ports To be used with 3rd party products� with narrow and wide alignment grooves�...
  • Page 99 Accessories | 99 Multi-flexible mounting bracket for MJB5 Plus - article no. 1015W1010-A Drawing no�: 0835012 Mount the bracket on the side or the back of the MJB5 Plus� If it is necessary to dismount the MJB5 Plus from the application, we recommend to use the bracket for mounting�...
  • Page 100 Accessories | 100 The MJB5 Plus bracket is for mounting on the CO and CB OpenBus control boxes� Mounting examples MJB5 Plus with bracket mounted on the back� MJB5 Plus mounted on the side of the control box�...
  • Page 101 • There can be a risk of conflict with other OpenBus accessories, such as HB, etc� it is therefore recommended to make a system/bit overview� • When connecting 3rd party products to LINAK systems, the customer must take necessary precautions against Electrostatic Discharge (ESD)�...
  • Page 102 Accessories | 102 MJB5 Plus UBL (ext.) Special Recommendations • The LED end of the UBL cable (0964135) must be mounted on the bed with metal screws, in order to maintain ESD protection� • When the MJB5 Plus with UBL, switch input is being used on a system with battery, the functionality will follow the power-down mode of the control box, see table: OpenBus control box MJB5 Plus with...

  • Page 103: Modular Junction Box - Mjb5 Plus Aoc

    Accessories | 103 Modular Junction Box - MJB5 Plus AOC The modular junction box MJB5 Plus is designed for use together with OpenBus™ control boxes� The MJB5 Plus makes it possible to connect multiple hand controls and attendant controls� It can even be used for charging or to connect the Under Bed Light and 3rd party products�...
  • Page 104 Accessories | 104 The product label is added for correct connection to the ports The MJB5 AOC has 4 ports� Port 1 is for OpenBus connection� Port 2 has 4 common ground switch inputs or an OpenBus hand control� Port 4 has 8 common positive switch inputs or an analogue hand control� Port 5 has 8 common positive switch inputs or an analogue hand control�...
  • Page 105 Accessories | 105 PORT 1 PORT 2 PORT 3 PORT4 PORT 5 Hardware OpenBus NO PWR* NO PWR NO PWR version 0 Hardware OpenBus version 1 Hardware OpenBus NO PWR NO PWR version 2 Hardware OpenBus NO PWR version 3 *PWR = Power Request Note - To be able to activate an actuator, it is necessary to use a signal with Power Request�...
  • Page 106 Accessories | 106 Standard configuration Table 1: Overview of pin activation and OpenBus codes When a pin is activated, different OpenBus codes from port 4 and port 5 will be sent� Table 1 is the standard configuration� Example: If Pin 3 is activated, it will send OpenBus code H1 from port 4 and H11 from port 5� Table 2 Table 1 Wire colour...
  • Page 107 Accessories | 107 MJB5 Plus AOC Special Recommendations When the MJB5 Plus AOC with or without power request is being used on a system with battery, the functionality will follow the power-down mode of the control box� If there is no power request on the inputs, it is not possible to wake-up the control box via the MJB5 AOC inputs when the control box is in power down�...
  • Page 108 Unlocking of cable locking mechanism If a cable needs to be replaced or added, we recommend to open the cable locking mechanism as described below and demonstrated in our video on LINAK�com - MJB5 Plus section brochures and manuals� Video guide available on www�linak�com...
  • Page 109 Accessories | 109 Locking of cable locking mechanism Video guide available on www�linak�com 1� Align the locking mechanism with the MJB5 Plus� 2� Press the cable locking mechanism down until you hear a click sound� CLICK 3� Slide the mechanism forward until you hear another click sound�...
  • Page 110 Accessories | 110 Modular plug with wide alignment groove To be used with LINAK products� Can be connected to all ports in the MJB5 Plus, both ports with narrow and wide alignment grooves� with narrow and wide alignment grooves� Modular plug with narrow alignment groove.
  • Page 111 Accessories | 111 Snap function for mounting and release of the bracket from the control box Used for fixation of the bracket to MJB5 Plus back Used for fixation of the bracket to MJB5 Plus side The bracket is very flexible for mounting but we recommend one of the following fixations� Bracket fixation to the MJB5 Plus back: Bracket fixation to the MJB5 Plus side:...
  • Page 112 Accessories | 112 The MJB5 Plus bracket is for mounting on the CO and CB OpenBus control boxes� Mounting examples MJB5 Plus with bracket mounted on the back� MJB5 Plus mounted on the side of the control box�...

  • Page 113: Modular Data Interface - Mdi

    Modular Data Interface - MDI With the Modular Data Interface, it is possible to connect to third party devices� The MDI establishes the access to the LINAK Communication Interface and prepares the system for the use of future features� Usage Operation temperature: +5 °C to +40 °C...
  • Page 114 Accessories | 114 Multi-flexible mounting bracket for MDI - article no. 1015W1010-A Drawing no�: 0835012 Mount the bracket on the side or the back of the MDI� If it is necessary to dismount the MDI from the application, we recommend to use the bracket for mounting� Use special screws type WN1423 K60x16, ordering no�...
  • Page 115 Accessories | 115 The MDI bracket is for mounting on the CO and CB OpenBus control boxes� Mounting examples MDI with bracket mounted on the side� MDI mounted on the side of the control box� MDI with bracket mounted on the back� MDI mounted on the side of the control box�...
  • Page 116 ® Please pay attention to the ‘Patient Environment’ Clause 3�79 - IEC60601-1� • When connecting third-party products to LINAK systems, the customer must take necessary precautions against Electrostatic Discharge (ESD)� Exposure to harmful ESD must be avoided� • Third-party products must be designed with the following isolation: Minimum 1 MOPP (creepage distance/clearance according to IEC 60601-1)�...

  • Page 117: Simulator Tool

    Accessories | 117 Simulator Tool The Simulator Tool is a software that can be used to simulate hand control functions on OpenBus™ and analogue actuator systems� With the Simulator Tool, sequences of actuator movements can be programmed and repeated in order to test actuator systems�...
  • Page 118 Accessories | 118 Warnings • The LINAK Simulator Tool is to be used as a test tool or demo tool only� It is not allowed to use the software and accessories as a control in any commercial application� • Potentially dangerous situations resulting from automated movement generated by the Simulator Tool Software must be considered and assessed before starting any action�...

  • Page 119: Safety/Signal Limit Switch (Sls)

    Accessories | 119 Safety/Signal Limit Switch (SLS) There are 2 types of SLS switches, an analogue and an OpenBus™ type� The analogue SLS can be used as safety feature to cut off the current to the actuator� The SLS is available with 1 or 2 switches (activated by the same button)� It can be placed to prevent an unintentional positioning of the various frame segments in relation to each other or simply as an external limit switch to protect the frame against the full thrust of the actuator in end position�...
  • Page 120 Accessories | 120 Cable length - Safety Limit Switch Cable length - Signal Limit Switch...

  • Page 121: Under Bed Light (Ubl)

    Accessories | 121 Under Bed Light (UBL) The Under Bed Light (UBL) can be mounted under the bed to provide a discrete guiding light when the patient leaves the bed during night� With an Under Bed Light it is easy to switch the light on and off by means of a handset or controlling it automatically with the Out of Bed functionality of the MJB5 Plus with Under Bed Light (Ext�)�...

  • Page 122: Under Bed Light (Ubl) 2

    Accessories | 122 Under Bed Light (UBL) 2 The Under Bed Light (UBL2) provides a powerful light with a good distribution� The UBL2 is to be used for beds within hospitals, nursing homes and in homecare� The Under Bed Light makes it easier for patients and other people in need of care to find their way at night in the dark to prevent falling accidents and to make them feel safe�...

  • Page 123: Qlci2

    ® customisation� LINAK A/S delivers the OpenBus system only and is not responsible for any products (i�e� products from 3rd party suppliers) other than LINAK products or the compatibility of such products with the LINAK OpenBus system�...
  • Page 124 An OEM application approval according to EN45501 Typically the LINAK Weighing Solution will be classified as a “non-automatic weight” system�If a LINAK Weighing Solution is applied to a bed AND classified as such, the system MUST be “first-time” verified and sealed�...
  • Page 125 Accessories | 125 Mounted on frame Service lid Integrated hinge Removable if needed Release hook 3-way cable exit Very small built-in dimension: Easy-mount bracket Height: Min� 90 mm (lid can be removed) Length: +20 mm (locking system) Mounting bracket (frame flat) Mounting bracket (frame flat) w/M4 nuts Article No.
  • Page 126 • Load cell cables should not exceed a length of 2700 mm� • In Europe weight systems are subject to important legal restrictions� The LINAK Weighing System will be approved in accordance with EN45501� The used load cells must be OIML approved as well (this is not included in the LINAK approval)�...
  • Page 127 Accessories | 127 Mounting of cables and cable lock The QLCI2 have a uniquely designed cable lid� The lid also works as an integrated cable lock when closed� 1� Mount load cell cable plugs in QLCI2 2� Calibrate the system (See Calibration - page 14) 3�...

  • Page 128: Usb-A Power Adapter

    Accessories | 128 USB-A Power Adapter The USB-A power adapter can be used for charging devices, such as smart phones, tablets and other products which require a USB-A connection� It can deliver up to 7�5 W constant power and is applicable for beds and other healthcare applications within hospitals, nursing homes and homecare�...
  • Page 129 Accessories | 129 Mounting • It is imperative to mount the female USB-A connector opening facing down to prevent any water ingress (IPX4 requirement) • Screw holes in application are needed for mounting • When mounting, a screw torque 0�8-0�9 Nm is recommended� •...
  • Page 130 Non-observance of this procedure may lead to damaged product driver circuits in COXX control boxes� • Clean and wipe with a clean cloth� The cloth may be dampened with an all-purpose cleaner� • LINAK recommends annual inspection of its products when used in typical medical, hospital, healthcare or assisted living environments�...

  • Page 131: Contacts

    LINAK, LINAK subsidiaries, or LINAK affiliates. the same reason, LINAK cannot guarantee the correctness and actual status of imprinted information on All sales are subject to the ‘Standard Terms of Sale and Delivery for LINAK A/S’ available on LINAK websites. its products.

This manual is also suitable for:

Medline careline ca30Medline careline ca40Medline careline ca63Medline careline cal40Medline careline cb6Medline careline cb6s mk2 ... Show all

Table of Contents
