7.3.1 Examples for determining proper dip switch settings to achieve optimal
lubrication
In the "normal mode" (per 100 operating hours)
Example 1:
A roller bearing is to be provided with 14 cm
operation: 14 cm
The discharge table in chapt. 7.3 on page 14 shows that 3 different settings are
possible for each LC unit size
Variation I:
2.78 cm 3 /100 h for a 60 cm
Variation II:
3
2.78 cm /100 h for a 120 cm
Variation III:
3
2.89 cm /100 h for a 250 cm
At this point, you can calculate the total discharge life of the LC unit (and the ex
change date). Proceed as following:
The roller bearing to be lubricated is installed in a machine which runs 5 days per
week 8 hours per working day.
To Variation I:
The lubricant is sufficent for more than 1 year, not including additional operational
breaks or any other machine standstills.
- 15 -
3
÷ 500 h = 0.028 cm
1 2 3 4
Time Vol.
3 LC unit (S60)
1 2 3 4
Time Vol.
3
LC unit (M120)
1 2 3 4
Time Vol.
3
LC unit (L250)
3
60 cm LC unit (S60)
2.78 cm 3 /100 h = 0.0278 cm
3
60 cm : 0.0278 cm
2158.3 h : 40 h/week = 54 weeks
perma STAR CONTROL TIME
3 of lubricant every 500 hours of
3 3
per h = 2.8 cm per 100 h
3 /h
3
/h = 2158.3 h
