Page 1: User Manual
A WILSON ELECTRONICS BRAND Home Complete Cellular Signal Booster User Manual support.weboost.com 866.294.1660 NEED HELP? -
Page 2: Table Of Contents
______ Index Package Contents Preparation Connect Inside Antenna To Booster STEP 1-A & B: Point Outside Antenna Toward Nearest Cell Tower STEP 2-A: Mount Bracket To Outside Antenna STEP 2-B: Route & Connect Cable To System STEP 3: Power Up The Booster & Optimize The System STEP 4: Measuring Booster Performance Light Patterns... -
Page 3: Package Contents
______ Package Contents Inside Outside Home 75’ & 60’ Power Antenna Antenna Complete Cables Supply Booster Booster & Outside Antenna Cable Clips Inside Antenna Bracket & 2 Adhesive Mounts Mount Strips HOME COMPLETE CELL PHONE SIGNAL BOOSTER... -
Page 4: Preparation
______ Preparation You Will Need (tools not included) Make sure the following materials are prepared and ready for your installation. 3 to 4 hours 2 people (a person to help with antenna calibration) Ladder Phillips-head screwdriver ... -
Page 5: Step 1-A & B: Connect Inside Antenna To Booster
______ Step 1-A & B: Connect Inside Antenna To Booster Place the Inside Antenna where you need the greatest signal boost. Connect Inside Antenna cable to the supplied coax cable then to the bottom port on Home Complete Booster labeled ‘INSIDE’ and place Inside Antenna in weak signal area at least 18 inches away from booster. -
Page 6: Step 2-A: Point Outside Antenna Toward Nearest Cell Tower
______ Step 2-A: Point Outside Antenna Toward Nearest Cell Tower Point the Outside Antenna toward the nearest cell phone tower. To fi nd the nearest tower, use an app such as ‘Open Signal’. This is the most critical step of the installation process because it will determine the overall performance of the booster system. -
Page 7: Step 2-B: Mount Bracket To Outside Antenna
______ Step 2-B: Mount Bracket To Outside Antenna Attach the Mount to the Outside Antenna and use the Bolts/Pole Bracket to attach to a pole. Pole Outside Antenna (1.25”-2.0”dia.) Antenna Mount Pole Bracket Drip holes face down NOTE: Mounting on existing roof exhaust pipe would be a good time-saver option. -
Page 8: Step 3: Route & Connect Cable To System
______ Step 3: Route & Connect Cable To System Connect the white RG-11 Cable to Outside Antenna and route cable into the home. All connections should be hand tightened only. Inside Outside Antenna Antenna Booster RG-11 Cable Route cable to the Home Complete Booster and connect to port labeled ‘OUTSIDE’. -
Page 9: Step 4: Power Up The Booster & Optimize The System
______ Step 4: Power Up The Booster & Optimize The System Plug the Power Supply into wall outlet then connect to the Booster. Outside Inside Antenna Antenna Booster RG-11 Cable to power 50 FEET HORIZONTAL OR 20 FEET VERTICAL DISTANCE Outside Antenna Cell... - Page 10 ______ (STEP 4 cont.) After powering up your system, you are now ready to optimize your system. Rotate the Outside Antenna in 1/4 turn increments, after each turn, unplug and reconnect the booster to power while observing the signal level on your cell phone from the Inside Antenna’s projected area.
-
Page 11: Measuring Booster Performance
Test Mode’. Tip: Using the bar indicator on your cell phone can assist you in fi nding the strongest signal direction as well as placing calls in diff erent locations. For changes/updates on this issue, periodically go to weboost.com/signalstrength. Android™ Settings > About Phone > Status or Network > Signal Strength or Network Type and Strength (exact options/wording depends on phone model). - Page 12 ______ (MEASURING BOOSTER PERFORMANCE cont.) Signal Strength without Booster Note here: Signal Strength with Booster Note here: Compare Results Having an accurate measurement of signal strength in decibels (dBm) is crucial when installing your system. Decibels accurately measure the signal strength you are receiving. EXCELLENT GOOD FAIR...
-
Page 13: Light Patterns
______ Light Patterns Solid Green This indicates that your booster is functioning properly and there are no issues with installation. Blinking Green, Then Red Band has reduced gain. This indicates that one or more of the booster bands has reduced power due to a feedback loop condition called oscillation. -
Page 14: Troubleshooting
Outside Antenna must be adjusted. Wait 10 seconds between adjustments for the lights to reset. Rotate the Outside Antenna away from the strongest cellular signal in small increments (45°) until the light turns green. Unplug and re-plug in power supply. support.weboost.com 866.294.1660 NEED HELP? CELL PHONE SIGNAL BOOSTER... - Page 15 ______ Antenna Kit Options The following accessories are certifi ed by the FCC to be used with the Home Complete Booster. INSIDE FIXED Yagi Antenna 301111 With 75’ RG-6 301111-5850 311135-40060 Yagi Antenna 301111 With 50’ RG-58 Panel w/60’ Wilson 400 311203-40020 311155-40060 Omni Directional Antenna (311203) With 20’...
-
Page 16: Safety Guidelines
To uphold compliance with network protection standards, all active cellular devices must maintain at least six feet of separation distance from Inside Panel and Dome antennas. Use only the power supply provided in this package. Use of a non-weBoost product may damage your equipment. - Page 17 Notes support.weboost.com 866.294.1660 NEED HELP? HOME COMPLETE CELL PHONE SIGNAL BOOSTER...
-
Page 18: Specifi Cations
This device complies with Part 15 of FCC rules. Operation is subject to two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by weBoost could void the authority to operate this equipment. -
Page 19: Warranty
2 YEAR WARRANTY weBoost Signal Boosters are warranted for two (2) years against defects in workmanship and/or materials. Warranty cases may be resolved by returning the product directly to the reseller with a dated proof of purchase. Signal Boosters may also be returned directly to the manufacturer at the consumer’s expense, with a dated proof of purchase and a Returned Material... - Page 20 3301 East Deseret Drive, St. George, UT 866.294.1660 www.weboost.com support.weboost.com Copyright © 2016 weBoost. All rights reserved. weBoost products covered by U.S. patent(s) and pending application(s) For patents go to: weboost.com/us/patents NOT AFFILIATED WITH WILSON ANTENNA GDE000_RevFCC_01.21.19...
