Page 1 User Manual Model T300/T300M Carbon Monoxide Analyzer with NumaView™ software © Teledyne API (TAPI) 9970 Carroll Canyon Road San Diego, CA 92131-1106 Toll-free Phone: +1 800-324-5190 Phone: +1 858-657-9800 Fax: +1 858-657-9816 Email: api- @teledyne.com sales Website: http:// .teledyne-api.com/ 2019...
Page 3 NOTICE OF COPYRIGHT © 2019 Teledyne API (TAPI). All rights reserved. TRADEMARKS All trademarks, registered trademarks, brand names or product names appearing in this document are the property of their respective owners and are used herein for identification purposes only.
Page 4 NEVER use any gas analyzer to sample combustible gas(es)! For Technical Assistance regarding the use and maintenance of this instrument or any other Teledyne API product, contact Teledyne API’s Technical Support Department: Telephone: +1 800-324-5190 (toll free) or +1 858-657-9800 Email: api-techsupport@teledyne.com...
Page 5 CONSIGNES DE SÉCURITÉ Des consignes de sécurité importantes sont fournies tout au long du présent manuel dans le but d’éviter des blessures corporelles ou d’endommager les instruments. Veuillez lire attentivement ces consignes. Chaque consigne de sécurité est représentée par un pictogramme d’alerte de sécurité;...
Page 6 PRODUCT RETURN All units or components returned to Teledyne API should be properly packed for handling and returned freight prepaid to the nearest designated Service Center. After the repair, the equipment will be returned, freight prepaid.
Page 7 T300 CO Analyzer User Manual with NumaView™ Software (this manual) MODBUS Registers, Appendix A 069120000 T300/T300M Interconnect Diagram, Appendix B Support that manuals are also available on the CD of Instrument User Manuals and on the TAPI website http://www.teledyne-api.com include: NumaView™...
Page 8: Table Of Contents
TABLE OF CONTENTS 1. Introduction, Specifications, Approvals, & Compliance..............14 1.1 Specifications...............................15 1.2 EPA Designation ............................17 1.3 Approvals and Certifications ........................17 1.3.1 Safety ...............................17 1.3.2 EMC ..............................17 1.3.3 Other Type Certifications .........................17 2. Getting Started ..........................18 2.1 Unpacking ..............................18 2.1.1 2.1.1 Ventilation Clearance ......................19 2.2 Instrument Layout ............................20 2.2.1 Front Panel ............................20...
Page 9 4.2.2 Calibration and Check Procedures with Valve Options Installed .............95 4.2.2.1 Use of Zero/Span Valve with Remote Contact Closure ............96 4.3 Automatic Zero/Span Cal/Check (Auto Cal) ....................96 4.4 CO Calibration Quality ..........................99 4.5 Calibration of the T300/T300M’s Electronic Subsystems ................99 083730300A DCN8101...
Page 10 5.6.4 Performing a Sample Flow Check ....................112 5.6.5 Cleaning the Optical Bench......................112 5.7 Service and Troubleshooting ........................112 5.7.1 Cleaning Exterior Surfaces of the T300/T300M ................113 5.7.2 Fault Diagnosis with Alerts ......................114 5.7.3 Fault Diagnosis with Dashboard Functions ..................115 5.7.4 The Diagnostic Signal I/O Function ....................117 5.7.5 Status LEDs ...........................117...
Page 11 5.7.14 Subsystem Checkout ........................128 5.7.14.1 AC Mains Configuration....................128 5.7.14.2 DC Power Supply ......................128 5.7.14.3 I C Bus ..........................129 5.7.14.4 Touchscreen Interface .....................129 5.7.14.5 LCD Display Module ......................129 5.7.14.6 Relay Board ........................130 5.7.14.7 Sync/Demodulator Assembly ..................130 5.7.14.8 Opto Pickup Assembly ....................131 5.7.14.9 GFC Wheel Drive ......................131 5.7.14.10 IR Source ........................131...
Page 12 6.4.2.4 IR Photo-Detector ......................156 6.4.3 Synchronous Demodulator (Sync/Demod) Assembly ..............156 6.4.3.1 Signal Synchronization and Demodulation..............157 6.4.3.2 Sync/Demod Status LEDs ....................158 6.4.3.3 Photo-Detector Temperature Control ................159 6.4.3.4 Dark Calibration Switch ....................159 6.4.4 Relay Board ...........................159 6.4.4.1 Heater Control .........................159 6.4.4.2 GFC Wheel Motor Control ....................159 6.4.4.3 Zero/Span Valve Options ....................159 6.4.4.4 IR Source .........................160 6.4.4.5 I2C Watch Dog Circuitry ....................161...
Page 13 Figure 2-22. T300/T300M Internal Pneumatic Flow Option 50A – Zero/Span Valves ..........49 Figure 2-23. T300/T300M Internal Pneumatic Flow Option 50B – Zero/Span/Shutoff Valves.........50 Figure 2-24. T300/T300M Internal Pneumatic Flow Option 50E – Zero Scrubber/Pressurized Span with IZS ..51 Figure 2-25. T300 Internal Pneumatic Flow Option 50H – Zero Scrubber/Ambient Span ........52 Figure 2-26.
Page 14 Figure 6-10. CPU Board ............................153 Figure 6-11. GFC Light Mask ..........................155 Figure 6-12. Segment Sensor and M/R Sensor Output ..................156 Figure 6-13. T300/T300M Sync/Demod Block Diagram..................157 Figure 6-14. Sample & Hold Timing ........................158 Figure 6-15. Location of relay board Status LEDs ....................160 Figure 6-16.
Page 15 Table 2-18. COM1/COM2 Configuration ........................80 Table 2-19. LAN/Ethernet Configuration Properties ....................81 Table 3-1. Ethernet Status Indicators ........................84 Table 3-2. Teledyne API's Hessen Protocol Response Modes ................88 Table 3-3. Default Hessen Status Flag Assignments ....................89 Table 4-1. AUTO CAL States ...........................97 Table 4-2.
Page 16: Introduction, Specifications, Approvals, & Compliance
1. INTRODUCTION, SPECIFICATIONS, APPROVALS, & COMPLIANCE Teledyne API’s Model T300 and Model T300M are Gas Filter Correlation Carbon Monoxide Analyzers. These microprocessor-controlled analyzers are used to determine the concentration of carbon monoxide (CO) in a sample gas drawn through the instrument.
Page 17: Specifications
1.1 SPECIFICATIONS Table 1-1. T300/T300M Basic Unit Specifications PARAMETER SPECIFICATION T300 T300M Ranges Min: 0-1 ppm Full scale Min: 0-5 ppm Full scale Max: 0-1,000 ppm Full scale Max: 0-5,000 ppm Full scale (user selectable, dual-range supported) Measurement Units ppb, ppm, µg/m...
Page 18: Table 1-2. O Sensor Option Specifications
Table 1-2. O Sensor Option Specifications PARAMETER DESCRIPTION Ranges 0-1% to 0-100% user selectable. Dual ranges and auto-ranging supported. Zero Noise <0.02% O Lower Detectable Limit <0.04% O Zero Drift (24 hours) <± 0.02% O ± Span Noise < 0.05% O Accuracy (intrinsic error) <±...
Page 19: Epa Designation
EPA designation does not apply to the T300M model. Note 1.3 APPROVALS AND CERTIFICATIONS The Teledyne API Model T300/T300M analyzer was tested and certified for Safety and Electromagnetic Compatibility (EMC). This Section presents the compliance statements for those requirements and directives.
Page 20: Getting Started
Do not operate this instrument without first removing dust plugs from SAMPLE and EXHAUST ports on the rear panel. Note Teledyne API recommends that you store shipping containers and materials for future use if/when the instrument should be returned to the factory for repair and/or calibration service. See Warranty statement in this manual and Return Merchandise Authorization (RMA) on our Website at http://www.teledyne-api.com.
Page 21: Ventilation Clearance
With no power to the unit, carefully remove the top cover of the instrument and check for internal shipping damage by carrying out the following steps: 1. Carefully remove the top cover and check for internal shipping damage. a. Remove the screws located on the instrument’s sides. b.
Page 22: Instrument Layout
2.2 INSTRUMENT LAYOUT Instrument layout includes front panel, rear panel connectors, and internal chassis layout. 2.2.1 FRONT PANEL The front panel (Figure 2-1) includes two USB ports for peripheral device connections, which can be used with mouse and keyboard as alternatives to the touchscreen interface, or with flash drive for uploads/downloads (devices not included).
Page 23: Rear Panel
2.2.2 REAR PANEL Figure 2-2 shows the layout of the rear panel. Figure 2-2. Rear Panel Layout Table 2-2 provides a description of each component on the rear panel. Table 2-2. Rear Panel Description 083730300A DCN8101 Getting Started...
Page 24 COMPONENT FUNCTION cooling fan Pulls ambient air into chassis through side vents and exhausts through rear. Connector for three-prong cord to apply AC power to the analyzer. AC power CAUTION! The cord’s power specifications (specs) MUST comply with the power connector specs on the analyzer’s rear panel Model number label Model/specs label...
Page 25: Internal Chassis
2.2.3 INTERNAL CHASSIS Figure 2-3 shows the T300 internal layout. Figure 2-4 shows the T300M internal layout. Figure 2-3. Internal Layout – T300 083730300A DCN8101 Getting Started...
Page 26: Figure 2-4. Internal Layout - T300M
Figure 2-4. Internal Layout – T300M Getting Started 083730300A DCN8101...
Page 27: Figure 2-5. Optical Bench Layout (Shorter Bench, T300M, Shown)
Figure 2-5. Optical Bench Layout (shorter bench, T300M, shown) 083730300A DCN8101 Getting Started...
Page 28: Connections And Startup
2.3 CONNECTIONS AND STARTUP This Section presents the electrical (Section 2.3.1) and pneumatic (Section 2.3.2) connections for setup and preparing for instrument operation. 2.3.1 ELECTRICAL CONNECTIONS Note To maintain compliance with EMC standards, cable must be no longer than 3 meters for all I/O connections. WARNING –...
Page 29: Connecting Analog Outputs
2.3.1.2 CONNECTING ANALOG OUTPUTS The rear panel Analog Output channels A1 through A4 can be mapped to reflect various operating values in the analyzer, including concentration values, temperatures, pressures, etc. These mappings are not configured by default and must be set by the user. An optional Current Loop output (Section 2.3.1.3) is available for A1, A2 and A3 only.
Page 30: Figure 2-7. Current Loop Option Installed On Motherboard
CAUTION – Avoid Invalidating Warranty Servicing or handling of circuit components requires electrostatic discharge protection, i.e. ESD grounding straps, mats and containers. Failure to use ESD protection when working with electronic assemblies will void the instrument warranty. For information on preventing ESD damage, refer to the manual, Fundamentals of ESD, PN 04786, which can be downloaded from our website at http://www.teledyne-api.com.
Page 31: Connecting The Status Outputs (Digital Outputs)
6. Each connector, J19 and J23, requires two shunts. Place one shunt on the two left- most pins and the second shunt on the two pins next to it (see Figure 2-7). 7. Reattach the top case to the analyzer. •...
Page 32: Connecting The Control Inputs (Digital Inputs)
Table 2-4. Status Output Pin Assignments STATUS CONDITION DEFINITION Configurable through the Collector side of individual status output opto-isolators. Setup>Digital Outputs menu The emitters of the transistors on pins 1 to 8 are bussed Emitter BUS together. Blank NO CONNECTION DC Power + 5 VDC, 300 mA source maximum The ground level from the analyzer’s internal DC power...
Page 33: Connecting The Concentration Alarm Relay (Option 61)
Table 2-5. Control Input Signals INPUT # STATUS DEFINITION ON CONDITION REMOTE ZERO CAL The analyzer is placed in Zero Calibration mode. The analyzer is placed in span calibration mode as part of performing a low REMOTE SPAN CAL span (midpoint) calibration. The analyzer is forced into high range for zero or span calibrations.
Page 34: Figure 2-11. Rear Panel Connector Pin-Outs For Rs-232 Mode
For RS-232 communications with data terminal equipment (DTE) or with data communication equipment (DCE) connect either a DB9-female-to-DB9-female cable (Teledyne API part number WR000077) or a DB9-female-to-DB25-male cable (Option 60A), as applicable, from the analyzer’s rear panel RS-232 port to the device. Adjust the rear panel DCE-DTE switch (Figure 2-2) to select DTE or DCE as appropriate.
Page 35: Figure 2-12. Default Pin Assignments For Cpu Com Port Connector (Rs-232)
The signals from these two connectors are routed from the motherboard via a wiring harness to two 10-pin connectors on the CPU card, J11 (COM1) and J12 (COM2) (Figure 2-12). Figure 2-12. Default Pin Assignments for CPU COM Port connector (RS-232) RS-232 C EFAULT ETTINGS...
Page 36 RS-232 M ULTIDROP PTION ONNECTION When the RS-232 Multidrop option is installed, connection adjustments and configuration through the menu system are required. This Section provides instructions for adjusting the internal connections, then for making the external connections, and ends with instructions for menu-driven configuration. Note Because the RS-232 Multidrop option uses both the RS232 and COM2 DB9 connectors on the analyzer’s rear panel to...
Page 37: Figure 2-13. Jumper And Cables For Multidrop Mode
Figure 2-13. Jumper and Cables for Multidrop Mode Note If you are adding an instrument to the end of a previously configured chain, remove the shunt between Pins 21 ↔ 22 of JP2 on the Multidrop/LVDS PCA in the instrument that was previously the last instrument in the chain.
Page 38: Figure 2-14. Rs-232-Multidrop Pca Host/Analyzer Interconnect Diagram
The (communication) Host instrument can only • address one instrument at a time. Teledyne API recommends setting up the first link, • between the Host and the first analyzer, and testing it before setting up the rest of the chain.
Page 39: Pneumatic Connections
2.3.2 PNEUMATIC CONNECTIONS This Section provides not only pneumatic connection information, but also important information about the gases required for accurate calibration; Section 2.3.3 shows the pneumatic flow diagrams for the analyzer in its basic configuration and with options. Before making the pneumatic connections, carefully note the following cautionary and special messages: CAUTION –...
Page 40 ATTENTION COULD DAMAGE INSTRUMENT AND VOID WARRANTY Maximum Pressure: Ideally the maximum pressure of any gas at the sample inlet should equal ambient atmospheric pressure and should NEVER exceed 1.5 in-hg above ambient pressure. Venting Pressurized Gas: In applications where any gas (span gas, zero air supply, sample gas is) received from a pressurized manifold, a vent must be provided to equalize the gas with ambient atmospheric pressure before it enters the...
Page 41: Important Information About Calibration Gases
In the case of CO measurements made with the T300 or T300M Analyzer, it is recommended that you use a span gas with a CO concentration equal to 80-90% of the measurement range for your application.
Page 42: Pneumatic Connections: Basic Configuration
MODEL 701 Instrument SAMPLE Zero Gas Chassis Generator VENT EXHAUST Exhaust must be vented outside of shelter or immediate area surrounding the instrument. Figure 2-15. T300/T300M Pneumatic Connections – Basic Configuration Using Bottled Span Gas Getting Started 083730300A DCN8101...
Page 43: Figure 2-16. T300/T300M Pneumatic Connections - Basic Configuration Using Gas Dilution Calibrator
Exhaust must be vented outside of shelter or immediate area surrounding the instrument. Figure 2-16. T300/T300M Pneumatic Connections – Basic Configuration Using Gas Dilution Calibrator AMPLE OURCE Attach a sample inlet line to the SAMPLE inlet port. The sample input line should not be more than 2 meters long.
Page 44: Pneumatic Connections: Ambient Zero/Ambient Span Option
2.3.2.3 PNEUMATIC CONNECTIONS: AMBIENT ZERO/AMBIENT SPAN OPTION This valve option is intended for applications where: Zero air is supplied by a zero air generator like the Teledyne API’s T701 and; • Span gas is supplied by a gas dilution calibrator like the Teledyne API’s T700.
Page 45 A vent may or may not be required when a T700-series is used with this option, depending on how the T700-series model output manifold is configured. Attach a gas line from the source of calibration gas (e.g. a Teledyne API’s T700 Dynamic •...
Page 46: Pneumatic Connections: Ambient Zero/Pressurized Span Option
Attach a gas line from the pressurized source of calibration gas (e.g. a bottle of NIST-SRM • gas) to the SPAN inlet at 30 psig. Zero air is supplied via a zero air generator such as a Teledyne API’s T701. • •...
Page 47: Pneumatic Connections: Zero Scrubber/Pressurized Span Option
EXHAUST outside of shelter or immediate area surrounding the instrument. Figure 2-19. T300/T300M Pneumatic Connections – Option 50E: Zero Scrubber/Pressurized Span AMPLE OURCE Attach a sample inlet line to SAMPLE inlet port. The sample input line should not be more than 2 meters long.
Page 48: Pneumatic Connections: Zero Scrubber/Ambient Span Option
• 2.3.2.6 PNEUMATIC CONNECTIONS: ZERO SCRUBBER/AMBIENT SPAN OPTION Not available in the T300M, Option 50H is operationally and pneumatically similar to Option 50A described earlier, except that the zero air is generated by an internal zero air scrubber. This means that the IZS inlet can simply be left open to ambient air.
Page 49: Figure 2-20. T300 Pneumatic Connections - Option 50H: Zero/Span
ALIBRATION OURCES SPAN GAS Attach a gas line from the source of calibration gas (e.g. a Teledyne API’s T700E Dynamic • Dilution Calibrator) to the SPAN inlet. Zero air is supplied internally via a zero air scrubber that draws ambient air through the IZS •...
Page 50: Pneumatic Flow Diagrams
INLET GFC Motor Heat Sync GFC Wheel Housing EXHAUST GAS OUTLET SAMPLE CHAMBER PUMP Flow / Pressure SAMPLE PRESSURE Sensor PCA SENSOR FLOW SENSOR Sample Gas Flow Control Figure 2-21. T300/T300M Internal Gas Flow (Basic Configuration) Getting Started 083730300A DCN8101...
Page 51: Pneumatic Flow: Ambient Zero/Ambient Span Valve Option
EXHAUST SENSOR GAS OUTLET PUMP FLOW SENSOR Sample Gas Flow Control Figure 2-22. T300/T300M Internal Pneumatic Flow Option 50A – Zero/Span Valves Table 2-7. Zero/Span Valve Operating States for Option 50A MODE VALVE CONDITION Sample/Cal Open to SAMPLE inlet SAMPLE...
Page 52: Pneumatic Flow: Ambient Zero/Pressurized Span Option
EXHAUST SENSOR GAS OUTLET PUMP FLOW SENSOR Sample Gas Flow Control Figure 2-23. T300/T300M Internal Pneumatic Flow Option 50B – Zero/Span/Shutoff Valves Table 2-8. Zero/Span Valve Operating States for Option 50B MODE VALVE CONDITION Sample/Cal Open to SAMPLE inlet SAMPLE...
Page 53: Pneumatic Flow: Zero Scrubber/Pressurized Span Option
GAS OUTLET PUMP FLOW SENSO R Sample Gas Flow Control Figure 2-24. T300/T300M Internal Pneumatic Flow Option 50E – Zero Scrubber/Pressurized Span with IZS Table 2-9. Zero/Span Valve Operating States for Option 50E MODE VALVE CONDITION Sample/Cal Open to SAMPLE inlet...
Page 54: Pneumatic Flow: Zero Scrubber/ Ambient Span Option (T300 0Nly)
2.3.3.5 PNEUMATIC FLOW: ZERO SCRUBBER/ AMBIENT SPAN OPTION (T300 0NLY) INSTRUMENT CHASSIS Sample SAMPLE GAS INLET Sample / Cal Valve Span Particulate SPAN1 INLET Filter GFC Motor Heat Sync VENT SPAN OUTLET Zero / Span GFC Wheel Valve Housing ZERO Air Zero ZERO AIR SAMPLE CHAMBER...
Page 55: Pneumatic Flow: Second Sensor Options
Flow / Pressure SAMPLE PRESSURE PUMP Sensor PCA SENSOR FLOW SENSOR Sample Gas Flow Control Figure 2-26. T300/T300M Internal Pneumatics with O Sensor Option INSTRUMENT CHASSIS SAMPLE GAS Particulate Filter INLET GFC Motor Heat Sync GFC Wheel Housing EXHAUST GAS OUTLET...
Page 56: Startup, Functional Checks, And Initial Calibration
2.3.4 STARTUP, FUNCTIONAL CHECKS, AND INITIAL CALIBRATION IMPORTANT Impact on Readings or Data The analyzer’s cover must be installed to ensure that the temperatures of the GFC Wheel and absorption cell assemblies are properly controlled. We recommend reading Section 6 to become familiar with the principles of operation. When the instrument is first started (Section 2.3.4.1, check its functionality (Section 2.3.4.3) and run an initial calibration (Section 4).
Page 57: Alerts: Warnings And Other Messages
Figure 2-29. Home Page Example 2.3.4.2 ALERTS: WARNINGS AND OTHER MESSAGES Because internal temperatures and other conditions may be outside the specified limits during the analyzer’s warm-up period, the software will suppress most Alerts for 30 minutes after power up. The Alerts page (Figure 2-30) shows the status of any active warning conditions or user-configured Events.
Page 58: Functional Checks
2.3.4.3 FUNCTIONAL CHECKS After warm-up, verify that the software properly supports any hardware options that are installed (Setup>Instrument menu), and that the instrument is functioning within allowable operating parameters. Check the Dashboard page against the instrument’s Final Test and Validation Data sheet, which lists these values as they appeared before the instrument left the factory.
Page 59: Menu Overview
2.4 MENU OVERVIEW Table 2-11 describes the main menus and provides cross-references to the respective sections with configuration details. Table 2-11. Menu Overview MENU DESCRIPTION LOCATION View and plot concentration readings and other selectable parameter Section 2.4.1 values (Figure 2-33). Home View user-selected parameters and their values, some of which can be Section 2.4.2...
Page 60: Home Page
2.4.1 HOME PAGE Figure 2-32 presents an orientation to the main display screen; Figure 2-33 shows that pressing the gas name or its concentration value or a meter below displays a live plot of their respective readings. Section 2.5.6 provides configuration instructions. Figure 2-32.
Page 61 Figure 2-33. Concentration and Stability Graph (top) and Meter Graph (bottom) 083730300A DCN8101 Getting Started...
Page 62: Dashboard
2.4.2 DASHBOARD The Dashboard displays an array of user-selectable parameters and their values (Section 2.5.3 provides configuration instructions). If there is a graphing icon in the upper right corner of a parameter, pressing that parameter displays a live plot of its readings as in Figure 2-34.
Page 63: Alerts
2.4.3 ALERTS Alerts are notifications triggered by specific criteria having been met by either factory- defined conditions (standard and not editable) or user-defined Events (Section 2.5.2). The Active Alerts page shows the status of any active warning conditions or Events that have been triggered.
Page 64: Calibration
When all Alerts are cleared, the Alerts menu tab no longer shows the caution symbol, and a green LED replaces the caution symbol in the bottom right corner of the interface (Figure 2-36). However, Alerts can reappear if the conditions causing them are not resolved.
Page 65: Utilities
2.4.5 UTILITIES The Utilities menu has a variety of functions as described next in Table 2-12. Table 2-12. Utilities Submenu Descriptions UTILITIES DESCRIPTION MENU Datalog View Displays the data logs that were configured via the Setup>Data Logging menu. From this list a log can be selected and filters applied to view the desired data.
Page 66: Setup Menu: Features/Functions Configuration
2.5 SETUP MENU: FEATURES/FUNCTIONS CONFIGURATION Use the Setup menu to conFigure the instrument’s software features, to gather information on the instrument’s performance, and to conFigure and access data from the Datalogger, the instrument’s internal data acquisition system (DAS). Once the setups are complete, the saved configurations can be downloaded to a USB drive through the Utilities>USB Utilities menu and uploaded to other instruments of the same model (Section 2.6).
Page 67 Figure 2-40. Creating a New Data Log The parameters available in the list of Log Tags include the names of Events configured in the Events page (Section 2.5.2). 083730300A DCN8101 Getting Started...
Page 68: Configuring Trigger Types: Periodic
2.5.1.1 CONFIGURING TRIGGER TYPES: PERIODIC The Periodic trigger is a timer-based trigger that is used to log data at a specific time interval. Periodic Trigger requires an interval that is set to number of minutes and a start time that is set to date and clock time. Figure 2-41.
Page 69: Configuring Trigger Types: Conditional
2.5.1.2 CONFIGURING TRIGGER TYPES: CONDITIONAL Conditional Trigger tracks/records data for user-selected parameters that meet specified conditions. Figure 2-42. Datalog - Conditional Trigger Configuration 2.5.1.3 DOWNLOADING DAS (DATA ACQUISITION SYSTEM) DATA To download DAS data collected by the Datalogger from the instrument to a flash drive, navigate to the Utilities>USB Utilities>DAS Download menu.
Page 70: Setup>Events
2.5.2 SETUP>EVENTS Events are occurrences that relate to any operating function, and are used to define the conditions that can be set to trigger Alerts (Section 2.4.3). Events can provide diagnostic information about the instrument, typically referred to as “Warnings”, or they can provide other information on instrument functionality, such as concentration alarms.
Page 71 Figure 2-45. Event Configuration allows the choice of whether to track and record the Event (uncheck this box to • “turn off” or deactivate the Event without deleting it). An Event must be enabled in order to use the Visible and the Latching options. allows the choice of whether or not to display the Event in the Alerts page when •...
Page 72: Editing Or Deleting Events
2.5.2.1 EDITING OR DELETING EVENTS Select an Event from the list (Figure 2-44) and press the Edit button to view or edit the details (Figure 2-46), or press the Delete button to delete the Event. Figure 2-47. Edit or Delete an Event 2.5.2.2 USING EVENTS AS TRIGGERS FOR DATA LOGGING Events can also be used to create customized triggers for data logging functions.
Page 73: Setup>Dashboard
2.5.3 SETUP>DASHBOARD Figure 2-48. Dashboard Display and Configuration 083730300A DCN8101 Getting Started...
Page 74: Setup>Autocal (With Valve Option)
2.5.4 SETUP>AUTOCAL (WITH VALVE OPTION) Auto Cal, automatic zero/span calibration or calibration check, is available with installed valve options (see Sections 2.3.2 and 4.3). 2.5.5 SETUP>VARS Vars are software variables that define operational parameters automatically set by the instrument’s firmware, and are user-adjustable through this menu. Access the menu to see the list of variables;...
Page 75: Setup>Homescreen
2.5.6 SETUP>HOMESCREEN To select a parameter (“tag”) for display in each of the three meters at the bottom of the Home page, navigate to the Homescreen configuration page through either the Setup>Homescreen menu or from Home page using the configuration icon (Figure 2-49). Figure 2-49.
Page 76: Setup>Digital Outputs
2.5.7 SETUP>DIGITAL OUTPUTS Specify the function of each digital output (connected through the rear panel STATUS connector) by mapping the output to a selection of “Signals” present in the instrument. Create custom “Signals” in the Setup>Events menu (Section 2.5.2). (If the Motherboard Relay Option was installed, the four additional relays can also be mapped).
Page 77: Setup>Analog Outputs
2.5.8 SETUP>ANALOG OUTPUTS Map the four user-configurable Analog Outputs to any of a wide variety of “Signals” present in the instrument and customize their respective configurations. Figure 2-51. Analog Output Configuration Example Refer to Figure 2-51 for the following: • Signal Out: select a Signal for the output.
Page 78: Figure 2-52. Analog Outputs Group Calibration Screen
Figure 2-52. Analog Outputs Group Calibration Screen Figure 2-53. Analog Outputs Manual Calibration Screen (AOUT2 Example) Table 2-14. Analog Output Voltage/Current Range RANGE RANGE SPAN MINIMUM OUTPUT MAXIMUM OUTPUT 100mV 0-100 mVDC -5 mVDC 105 mVDC 0-1 VDC -0.05 VDC 1.05 VDC 0-5 VDC -0.25 VDC...
Page 79: Manual Calibration Of Voltage Range Analog Outputs
2.5.8.1 MANUAL CALIBRATION OF VOLTAGE RANGE ANALOG OUTPUTS It is possible to manually calibrate the voltages by using a voltmeter connected across the output terminals (Figure 2-54) and changing the output signal level in the Manual Adjust field of the Analog Outputs Calibration screen (Figure 2-53). Refer to Table 2-15 for voltage tolerances.
Page 80: Manual Adjustment Of Current Range Analog Outputs
2.5.8.2 MANUAL ADJUSTMENT OF CURRENT RANGE ANALOG OUTPUTS These instructions assume that the Current Loop Option is installed (Section 2.3.1.3). This option places circuitry in series with the output of the D-to-A converter on the motherboard that changes the normal DC voltage output to a 0-20 milliamp signal. Adjusting the signal zero and span levels of the current loop output is done by raising or lowering the voltage output of the D-to-A converter circuitry on the analyzer’s motherboard.
Page 81: Setup>Instrument
+ D C G n d Volt Meter V OUT + V IN + 250 Ω V OUT - V IN - Recording ANALYZER Device Figure 2-56. Alternative Setup Using 250Ω Resistor for Checking Current Output Signal Levels In this case, follow the procedure above but adjust the output for the following values: Table 2-16.
Page 82: Setup>Comm (Communications)
2.5.10 SETUP>COMM (COMMUNICATIONS) This menu is for specifying the various communications configurations. 2.5.10.1 COM1/COM2 ConFigure the instrument’s COM1 or COM2 ports to operate in modes listed in Table 2-18. Table 2-18. COM1/COM2 Configuration MODE DESCRIPTION Baud Rate Set the baud rate for the COM1 or COM2 port being configured. Command Prompt Enable/disable a command prompt to be displayed when in terminal mode.
Page 83: Tcp Port1
2.5.10.2 TCP PORT1 TCP Port1 allows choosing whether or not to display the command prompt, editing the Port 1 number for defining the terminal control port by which terminal emulation software addresses the instrument, such as Internet or NumaView™ Remote software, and enabling or disabling security on this port.
Page 84: Transferring Configuration To Other Instruments
2.6 TRANSFERRING CONFIGURATION TO OTHER INSTRUMENTS Once an instrument is configured, the same configuration can be copied to other instruments of the same Model. This encompasses essentially anything the user can conFigure and does not apply to instrument-specific settings such as those that are configured at the factory for calibration.
Page 85: Communications And Remote Operation
3 COMMUNICATIONS AND REMOTE OPERATION This instrument’s rear panel connections can include an Ethernet port, a USB port (option) and two serial communications ports labeled RS232, which is the COM1 port in the software menu, and COM2 (refer to Figure 2-2). These ports allow the ability to communicate with, issue commands to, and receive data from the analyzer through an external computer system or terminal.
Page 86: Serial Communication: Rs-232
3.2.1 SERIAL COMMUNICATION: RS-232 The RS232 and COM2 communications ports operate on the RS-232 protocol (default configuration). Configurations possible for these two ports are: • RS232 port can also be configured to operate in single or RS-232 Multidrop mode (Option 62);...
Page 87: Communications Protocols
3.4.1 MODBUS These instructions assume that the user is familiar with MODBUS communications, and provide minimal information to get started. Please refer to the Teledyne API MODBUS manual, PN 06276, and to www.modbus.org for MODBUS communication protocols. Minimum Requirements: •...
Page 88: Figure 3-2. Modbus Via Serial Communication (Example)
When using MODBUS RTU, ensure that the Important COM1[COM2] Handshaking Mode is set to either Hardware or OFF. Do NOT set it to Software. Press the Accept button to apply the settings. (Figure 3-2 shows an example for MODBUS RTU). Figure 3-2.
Page 89: Hessen
Important instrument in the multidrop chain via the Setup>Vars>Instrument ID menu. The Hessen protocol is not strictly defined; therefore, while Teledyne API’s application is completely compatible with the protocol itself, it may be different from implementations by other companies. 3.4.2.1 HESSEN COM PORT CONFIGURATION...
Page 90: Hessen Settings Configuration
TYPE 2 has more flexibility when operating with instruments that can measure more than • one type of gas. For more specific information about the difference between the two versions, download the Manual Addendum for Hessen Protocol from the Teledyne API's web site: http://www.teledyne-api.com/manuals/. ESSEN...
Page 91: Table 3-3. Default Hessen Status Flag Assignments
Table 3-3. Default Hessen Status Flag Assignments STATUS FLAG NAME DEFAULT BIT ASSIGNMENT WARNING FLAGS SAMPLE FLOW WARNING 0001 BENCH TEMP WARNING 0002 SOURCE WARNING 0004 BOX TEMP WARNING 0008 WHEEL TEMP WARNING 0010 SAMPLE TEMP WARN 0020 SAMPLE PRESS WARN 0040 INVALID CONC 0080...
Page 92: Calibration
A start-up period of 4-5 hours is recommended prior to Note calibrating the analyzer. 4.1.1 CALIBRATION REQUIREMENTS Calibration of the T300/T300M Analyzer requires specific equipment and supplies. These include, but are not limited to, the following: • Zero-air source •...
Page 93: Zero Air
For the T300/T300M zero air should contain less than 25 ppb of CO and other major interfering gases such as CO and Water Vapor. It should have a dew point of -5°C or less.
Page 94: Second Gas Sensor Options Calibration
A strip chart recorder, data acquisition system or digital data acquisition system should be used to record data from the serial or analog outputs of the T300/T300M. If analog readings are used, the response of the recording system should be checked •...
Page 95: Calibration And Check Procedures For Basic Configuration
Tips for Setting the Expected Span Gas Concentration: Note • When setting expected concentration values, consider impurities in your span gas source. • The expected CO span gas concentration should be 80% to 90% of the reporting range of the instrument. To calibrate or to perform a calibration check for basic configuration instruments, see Section 4.2.1.
Page 96: Zero Calibration Check And Actual Calibration
4.2.1.1 ZERO CALIBRATION CHECK AND ACTUAL CALIBRATION 1. Go to the Calibration>M-P menu. 2. Input Zero air through the Sample port and press the Start button. 3. Either check or calibrate as follows: CHECK ONLY: ACTUAL CALIBRATION: a. Wait for reading to stabilize. a.
Page 97: Calibration And Check Procedures With Valve Options Installed
4.2.2 CALIBRATION AND CHECK PROCEDURES WITH VALVE OPTIONS INSTALLED Figure 4-2. Zero and Span Calibration Screens Follow the instructions in Section 4.2.1, except instead of the M-P menu, go to the Calibration>Zero menu for Zero cal and to the Calibration>Span menu for CO Span cal. 083730300A DCN8101 Calibration...
Page 98: Use Of Zero/Span Valve With Remote Contact Closure
4.2.2.1 USE OF ZERO/SPAN VALVE WITH REMOTE CONTACT CLOSURE Contact closures for controlling calibration and calibration checks are located on the rear panel CONTROL IN connector. Instructions for setup and use of these contacts are in Section 2.3.1.5. When the contacts are closed for at least 5 seconds, the instrument switches into zero, low span or high span mode and the internal zero/span valves will be automatically switched to the appropriate configuration.
Page 99: Figure 4-3. Auto Cal Page
Figure 4-3. Auto Cal Page Table 4-1. AUTO CAL States MODE NAME ACTION enables the sequence; Enabled disables the sequence. enables an actual calibration when the Enabled box is also Calibrate allows a calibration check when the Enabled box is also causes the sequence to perform a Zero calibration when both the Calibrate and Enabled boxes are also Zero...
Page 100: Table 4-2. Auto Cal Setup Combinations
Table 4-2. Auto Cal Setup Combinations MODE ACTION STATE Enabled Calibrate Zero High Check Zero Calibrate Check Calibrate Check High Calibrate Check Zero Low High Calibrate For each sequence, there are four parameters that control operational details: Date, Time (both in the Start field), Interval, and Duration, as presented in Table 4-3. Table 4-3.
Page 101: Co Calibration Quality
1.300 OFFSET -0.500 0.000 0.500 4.5 CALIBRATION OF THE T300/T300M’S ELECTRONIC SUBSYSTEMS These calibrations include Dark Cal, Pressure Cal and Flow Cal, all located under the Utilities>Diagnostics menu. 4.5.1 DARK CALIBRATION TEST The dark calibration test interrupts the signal path between the IR photo-detector and the remainder of the sync/demod board circuitry.
Page 102: Flow Calibration
Manual Control Valve PUMP Figure 4-4. O Sensor Calibration Set Up SENSOR ZERO GAS: Teledyne API recommends using pure N when calibration the zero point of your O sensor option. SENSOR SPAN GAS: Teledyne API recommends using 20.8% O in N...
Page 103: Epa Protocol Calibration
(default factory setting = 12%). 4.7 EPA PROTOCOL CALIBRATION When running the T300 for U.S. EPA compliance (the T300M does not have an EPA designation), always calibrate prior to use, adhering to the EPA designation requirements for this instrument.
Page 104: Maintenance And Service
5. MAINTENANCE AND SERVICE Predictive diagnostic functions, including data acquisition records, failure warnings and test functions built into the analyzer, allow the user to determine when repairs are necessary. A minimal number of simple, regularly performed maintenance procedures (Section 5.1) will ensure that the analyzer continues to operate accurately and reliably over its lifetime.
Page 105: Table 5-1. T300/T300M Maintenance Schedule
Table 5-1. T300/T300M Maintenance Schedule DATE PERFORMED ITEM ACTION FREQ CHECK MANUAL REQ’D Particulate Weekly or As Replace Filter Needed Weekly or after Verify Test Record and Functions Analyze Maintenance or Repair Pump Replace Annually Diaphragm Perform Flow Check Flow...
Page 106: Table 5-2. T300/T300M Functions Record
Table 5-2. T300/T300M Functions Record DATE RECORDED OPERATING FUNCTION MODE* STABILITY ZERO CAL CO MEAS ZERO CAL ZERO CAL MR RATIO SPAN CAL PRES SAMPLE SAMPLE PHT DRIVE AFTER WARM- SLOPE SPAN CAL OFFSET ZERO CAL Maintenance and Service 083730300A DCN8101...
Page 107: Predicting Diagnostics
5.2 PREDICTING DIAGNOSTICS These Functions can be used to predict failures by looking at how their values change over time. Initially it may be useful to compare the state of these functions to the values recorded on the printed record of the Final Test and Validation Data Sheet for your instrument.
Page 108: Operational Health Checks
Figure 5-1: Report Generation Page The report can also be set to generate periodically and sent to a Web services “cloud” where it is available for viewing by Teledyne API technical support personnel. Set this function with two Vars: Setup>Vars>Upload Report to Cloud: set to True.
Page 109: Software/Firmware Updates
5.4 SOFTWARE/FIRMWARE UPDATES There are two ways to check for and acquire updates: either remotely or manually. 5.4.1 REMOTE UPDATES The instrument must be connected to a network that is connected to the Internet. In the Setup>Instrument menu, select the Remote Update menu and press the Check for Updates button.
Page 110: Instrument Display Calibration (For Earlier Instruments)
currently installed. Once it’s been determined that the firmware is new, the Install button will be enabled; if the firmware version on the flash drive is the same as or older than the current firmware of the instrument, the Install button will not be enabled.
Page 111: Time Zone Changes
5.5 TIME ZONE CHANGES There is an option to change between 12-hour and 24-hour format in the Setup>Vars menu (System Time Format). Effectively changing the Time Zone requires a specific procedure as follows: 1. In Setup>Instrument>Date/Time Settings select the applicable Time Zone. 2.
Page 112: Maintenance Procedures
5.6 MAINTENANCE PROCEDURES The following procedures are to be performed periodically as part of the standard maintenance of the T300. 5.6.1 REPLACING THE SAMPLE PARTICULATE FILTER The particulate filter should be inspected often for signs of plugging or contamination. We recommend that the filter and the wetted surfaces of the filter housing are handled as little as possible when you change the filter.
Page 113: Rebuilding The Sample Pump
If you can’t locate the leak by the above procedure, use the following procedure. Obtain a leak checker similar to the Teledyne API P/N 01960, which contains a small pump, shut-off valve and pressure gauge. Alternatively, a convenient source of low-pressure gas is a tank of span gas, with the two-stage regulator adjusted to less than 15 psi with a shutoff valve and pressure gauge.
Page 114: Performing A Sample Flow Check
High flows indicate leaks downstream of the Flow Control Assembly. 5.6.5 CLEANING THE OPTICAL BENCH The T300/T300M sensor assembly and optical bench are complex and delicate. Disassembly and cleaning is not recommended. Please check with the factory before disassembling the optical bench.
Page 115: Cleaning Exterior Surfaces Of The T300/T300M
See the wiring interconnect diagram and interconnect list in Appendix B. 5.7.1 CLEANING EXTERIOR SURFACES OF THE T300/T300M If necessary, the exterior surfaces of the T300/T300M can be cleaned with a clean damp cloth. Do NOT submerge any part of the instrument and do NOT use any cleaning solution.
Page 116: Fault Diagnosis With Alerts
5.7.2 FAULT DIAGNOSIS WITH ALERTS The most common and/or serious instrument failures will result in a warning message, called an Alert. Table 5-4 lists some of the more common Alert messages, along with their meaning and recommended corrective action. It should be noted that if more than two or three warning Alerts occur at the same time, it is often an indication that some fundamental analyzer sub-system (power supply, relay board, motherboard) has failed, rather than being an indication of the specific failures referenced by the warning Alerts.
Page 117: Fault Diagnosis With Dashboard Functions
The acceptable ranges for these test functions are listed in the “Nominal Range” column of the analyzer Final Test and Validation Data Sheet (T300, P/N 04307 and T300M, P/N 04311) shipped with the instrument. Values outside these acceptable ranges indicate a failure of one or more of the analyzer’s subsystems.
Page 118: Table 5-5. Dashboard Functions - Indicated Failures
Table 5-5. Dashboard Functions - Indicated Failures TEST INDICATED FAILURE(S) FUNCTIONS AS DISPLAYED) Incorrectly configured measurement range(s) could cause response problems with a Data logger or chart recorder attached to one of the analog output. RANGE If the Range selected is too small, the recording device will over range. If the Range is too big, the device will show minimal or no apparent change in readings.
Page 119: The Diagnostic Signal I/O Function
TEST INDICATED FAILURE(S) FUNCTIONS AS DISPLAYED) Values outside range indicate Contamination of the zero air or span gas supply Instrument is miscalibrated Blocked gas flow SLOPE Contaminated or leaking GFC Wheel (either chamber) Faulty IR photo-detector Faulty sample faulty IR photo-detector pressure sensor (P1) or circuitry Invalid M/R ratio (see above) Bad/incorrect span gas concentration due.
Page 120: Sync Demodulator Status Leds
Motherboard CPU Status LED Figure 5-7. CPU Status Indicator 5.7.7 SYNC DEMODULATOR STATUS LEDS Two LEDs located on the Sync/Demod Board are there to make it obvious that the GFC Wheel is spinning and the synchronization signals are present: Table 5-6. Sync/Demod Board Status Failure Indications FUNCTION FAULT STATUS INDICATED FAILURE(S)
Page 121: Relay Board Status Leds
Figure 5-8. Sync/Demod Board Status LED Locations 5.7.8 RELAY BOARD STATUS LEDS There are eight LEDs located on the Relay Board. The most important of which is D1, which indicates the health of the I C bus. If D1 is blinking the other faults following LEDs can be used in conjunction with DIAG menu signal I/O to identify hardware failures of the relays and switches on the relay (see Section 5.7.4 and Appendix D).
Page 122: Table 5-8. Relay Board Status Led Failure Indications
Figure 5-9. Relay Board Status LEDs Table 5-8. Relay Board Status LED Failure Indications SIGNAL I/O PARAMETER FUNCTION DIAGNOSTIC TECHNIQUE ACTIVATED BY VIEW RESULT Voltage displayed should change. If not: Failed Heater WHEEL_HEATER WHEEL_TEMP Wheel Heater Faulty Temperature Sensor Yellow Failed AC Relay Faulty Connectors/Wiring Voltage displayed should change.
Page 123: Flow Problems
Section 5.6.4. If this test shows the flow to be correct, check the pressure sensors as described in Section 5.7.14.11. The T300/T300M has one main gas flow path. With the IZS or zero/span valve option installed, there are several subsidiary paths but none of those are displayed on the front panel or stored by the DAS.
Page 124: Flow Is Zero
5.7.9.1 FLOW IS ZERO The unit displays a SAMPLE FLOW warning message on the front panel display or the SAMPLE FLOW test function reports a zero or very low flow rate. Confirm that the sample pump is operating (turning). If not, use an AC voltmeter to make sure that power is being supplied to the pump if no power is present at the electrical leads of the pump.
Page 125: Displayed Flow = "Warnings
5.7.9.4 DISPLAYED FLOW = “WARNINGS” This warning means that there is inadequate gas flow. There are four conditions that might cause this: 1. A leak upstream or downstream of the flow sensor 2. A flow obstruction upstream or downstream of the flow sensor 3.
Page 126: Non-Repeatable Zero And Span
5.7.10.2 NON-REPEATABLE ZERO AND SPAN As stated earlier, leaks both in the T300/T300M and in the external system are a common source of unstable and non-repeatable readings. 1. Check for leaks in the pneumatic systems as described in Section 5.6.3. Don’t...
Page 127: Other Performance Problems
Individual control loops are used to maintain the set point of the absorption bench, filter wheel and IR photo-detector temperatures. If any of these temperatures are out of range or are poorly controlled, the T300/T300M will perform poorly. 5.7.12.1 BOX TEMPERATURE The box temperature sensor is mounted to the motherboard and cannot be disconnected to check its resistance.
Page 128: Gfc Wheel Temperature
3. If the relay has failed there should be no change in the voltage across pins 2 and 4 or 3 and 4. Note: K2 is in a socket for easy replacement. 4. If K2 checks out OK, the thermistor temperature sensor located on the optical bench near the front of the instrument could be at fault.
Page 129: Ir Photo-Detector Tec Temperature
If PHT DRIVE is > 4800 mV there is a malfunction. • 6. The +5 and ±15 VDC voltages in the T300/T300M are provided by switching power supplies. Switch mode supplies create DC outputs by switching the input AC •...
Page 130: Subsystem Checkout
5.7.14 SUBSYSTEM CHECKOUT The preceding subsections discussed a variety of methods for identifying possible sources of failures or performance problems within the analyzer. In most cases this included a list of possible causes. If the problem is not resolved at this point, the next step is to check the subsystems.
Page 131: I 2 C Bus
A voltmeter should be used to verify that the DC voltages are correct per the values in the table below, and an oscilloscope, in AC mode, with band limiting turned on, can be used to evaluate if the supplies are producing excessive noise (> 100 mV p-p). Table 5-10.
Page 132: Relay Board
5.7.14.6 RELAY BOARD The relay board PCA (P/N 04135) can be most easily checked by observing the condition of the its status LEDs on the relay board, as described in Section 5.7.8, and the associated output when toggled on and off through signal I/O function in the diagnostic menu, see Section 5.7.4.
Page 133: Opto Pickup Assembly
5.7.14.8 OPTO PICKUP ASSEMBLY Operation of the opto pickup PCA (P/N 04088) can be verified with a voltmeter. Measure the AC and DC voltage between digital ground on the relay board, or touchscreen and TP2 and TP4 on the sync pickup PCA. For a working board, with the GFC motor spinning, they should read 2.4 ±0.1 VAC and 2.5 ±0.15 VDC.
Page 134: Motherboard
5.7.14.11 PRESSURE/FLOW SENSOR ASSEMBLY The pressure/flow sensor PCA, located on the top of the absorption bench, can be checked with a voltmeter using the following procedure which, assumes that the wiring is intact, and that the motherboard and the power supplies are operating properly: OR PRESSURE RELATED PROBLEMS 1.
Page 135: Status Outputs
Status connector to the B pin on the Control In connector. The instrument should switch from Sample Mode to SPAN CAL R mode. 4. In each case, the T300/T300M should return to Sample Mode when the jumper is removed. 5.7.16 CPU There are two major types of CPU board failures, a complete failure and a failure associated with the Disk On Module (DOM).
Page 136: Communications
5.7.17.1 GENERAL RS-232 TROUBLESHOOTING Teledyne API analyzers use the RS-232 communications protocol to allow the instrument to be connected to a variety of computer-based equipment. RS-232 has been used for many years and as equipment has become more advanced, connections between various types of hardware have become increasingly difficult.
Page 137: Repair Procedures
5.8.1 REPAIRING SAMPLE FLOW CONTROL ASSEMBLY The critical flow orifice is housed in the flow control assembly (Teledyne API P/N 001760400) located on the top of the optical bench. A sintered filter protects the jewel...
Page 138: Removing/Replacing The Gfc Wheel
5.8.2 REMOVING/REPLACING THE GFC WHEEL When removing or replacing the GFC Wheel it is important to perform the disassembly in the following order to avoid damaging the components: 1. Turn off the analyzer. 2. Remove the top cover. 3. Open the instrument’s hinged front panel. 4.
Page 139: Figure 5-14. Removing The Opto-Pickup Assembly
Opto-Pickup Figure 5-14. Removing the Opto-Pickup Assembly 8. Remove the three (3) screws holding the GFC Wheel motor/heat sink assembly to the GFC Wheel housing. 9. Carefully remove the GFC Wheel motor/heat sink assembly from the GFC Wheel housing. GFC WHEEL HOUSING Figure 5-15.
Page 140: Checking And Adjusting The Sync/Demodulator, Circuit Gain (Co Meas)
5.8.3.1 CHECKING THE SYNC/DEMODULATOR CIRCUIT GAIN The T300/T300M Analyzers will operate accurately as long as the sync/demodulator circuit gain is properly adjusted. To determine if this gain factor is correct: 1. Make sure that the analyzer is turned on and warmed up.
Page 141: Adjusting The Sync/Demodulator, Circuit Gain
5.8.3.2 ADJUSTING THE SYNC/DEMODULATOR, CIRCUIT GAIN To adjust the sync/demodulator circuit gain: 1. Make sure that the analyzer is turned on and warmed up. 2. View the STABIL or CO STB function in the Dashboard. 3. Apply Zero Air to Sample Inlet of the analyzer. 4.
Page 142: Disk-On-Module Replacement
5.8.4 DISK-ON-MODULE REPLACEMENT COULD DAMAGE INSTRUMENT AND VOID WARRANTY ATTENTION Servicing of circuit components requires electrostatic discharge protection, i.e. ESD grounding straps, mats and containers. Failure to use ESD protection when working with electronic assemblies will void the instrument warranty. For information on preventing ESD damage, refer to the manual, Fundamentals of ESD, PN 04786, which downloaded...
Page 143: Frequently Asked Questions
5.9 FREQUENTLY ASKED QUESTIONS The following is a list from the Teledyne API’s Technical Support Department of the most commonly asked questions relating to the T300/T300M CO Analyzer. QUESTION ANSWER Why does the ENTR button During certain types of adjustments or configuration operations, the...
Page 144: Technical Assistance
San Diego, California 92131-1106 USA Toll-free Phone: +1 800-324-5190 Phone: +1 858-657-9800 Fax: +1 858-657-9816 Email: api-techsupport@teledyne.com Website: http://www.teledyne-api.com/ Before contacting Teledyne API Tech Support, please fill out the problem report form, available online for electronic submission at http://www.teledyne-api.com. Maintenance and Service 083730300A DCN8101...
Page 145: Theory Of Operation
6. THEORY OF OPERATION The T300/T300M Gas Filter Correlation Carbon monoxide Analyzer is a microprocessor- controlled analyzer that determines the concentration of carbon monoxide (CO) in a sample gas drawn through the instrument. It requires that the sample and calibration...
Page 146: Beer's Law
(Euler’s number) is the absorption path, or the distance the light travels as it is being absorbed. is the concentration of the absorbing gas (in the case of the T300/T300M, Carbon Monoxide (CO)). α...
Page 147: Gas Filter Correlation
6.1.2 GAS FILTER CORRELATION Unfortunately, water vapor absorbs light at 4.7 µm too. To overcome the interfering effects of water vapor the T300/T300M adds another component to the IR light path called a Gas Filter Correlation (GFC) Wheel. Measurement Cell...
Page 148: The Measure Reference Ratio
6.1.2.2 THE MEASURE REFERENCE RATIO The T300/T300M determines the amount of CO in the sample chamber by computing the ratio between the peak of the measurement pulse (CO MEAS) and the peak of the reference pulse (CO REF).
Page 149: Interference And Signal To Noise Rejection
Sample Chamber, but to a lesser extent Figure 6-4. Effect of CO in the Sample on CO MEAS & CO REF Once the T300/T300M has computed this ratio, a look-up table is used, with interpolation, to linearize the response of the instrument. This linearized concentration value is combined with calibration SLOPE and OFFSET values to produce the CO concentration which is then normalized for changes in sample pressure.
Page 150: Summary Interference Rejection
6.1.2.4 SUMMARY INTERFERENCE REJECTION The basic design of the T300/T300M rejects most of this interference at a 300:1 ratio. The two primary methods used to accomplish this are: The 4.7μm band pass filter just before the IR sensor which allows the instrument to only •...
Page 151: Flow Rate Control
6.3.1 FLOW RATE CONTROL To maintain a constant flow rate of the sample gas through the instrument, the T300/T300M uses a special flow control assembly located in the exhaust gas line just before the pump. In instruments with the O...
Page 152: Particulate Filter
The critical flow orifice used in the T300/T300M is designed to provide a flow rate of 800 cc/min. 6.3.2 PARTICULATE FILTER The T300/T300M Analyzer comes equipped with a 47 mm diameter, Teflon, particulate filter with a 5 micron pore size.
Page 153: Sample Pressure Sensor
The core of the analyzer is a microcomputer/central processing unit (CPU) that controls various internal processes, interprets data, makes calculations, and reports results using specialized firmware developed by Teledyne API. It communicates with the user as well as receives data from and issues commands to a variety of peripheral devices via a separate printed circuit assembly called the motherboard.
Page 154: Figure 6-9. Electronic Block Diagram
RS232 COM2 Ethernet Male Female option Analog Outputs Optional 4- 20 mA Touchscreen Control Inputs: 1 – 8 Display Status Outputs: 1 – 6 LVDS transmitter board Analog External Outputs Digital I/O) PC 104 (D/A) CPU Card Converter( V/F) Power- Up Disk On Circuit Module...
Page 155: Cpu
The DOM is a 44-pin IDE flash drive with a storage capacity up to 128 MB. It is used to store the computer’s operating system, the Teledyne API firmware, and most of the operational data generated by the analyzer’s internal data acquisition system (DAS).
Page 156: Optical Bench & Gfc Wheel
6.4.2 OPTICAL BENCH & GFC WHEEL Electronically, in the case of the optical bench for the T300 Analyzer, GFC Wheel and associated components do more than simply measure the amount of CO present in the sample chamber. A variety of other critical functions are performed here as well. 6.4.2.1 TEMPERATURE CONTROL Because the temperature of a gas affects its density resulting in the amount of light...
Page 157: Gfc Wheel
6.4.2.3 GFC WHEEL A synchronous AC motor turns the GFC Wheel motor. For analyzers operating on 60Hz line power this motor turns at 1800 rpm. For those operating on 50Hz line power the spin rate is 1500 rpm. The actual spin rate is unimportant within a large range since a phase lock loop circuit is used to generate timing pulses for signal processing.
Page 158: Ir Photo-Detector
EGMENT ENSOR Light from this emitter/detector pair shines through a portion of the mask that is divided into the same number of segments as the IR detector ring. It is used by the synchronous/demodulation circuitry of the analyzer to latch onto the most stable part of each measurement and reference IR pulse.
Page 159: Signal Synchronization And Demodulation
Segment Phase Lock Status LED Status LED Figure 6-13. T300/T300M Sync/Demod Block Diagram 6.4.3.1 SIGNAL SYNCHRONIZATION AND DEMODULATION The signal emitted by the IR photo-detector goes through several stages of amplification before it can be accurately demodulated. The first is a pre-amplification stage that raises the signal to levels readable by the rest of the sync/demod board circuitry.
Page 160: Sync/Demod Status Leds
Table 6-14. Sync DEMOD Sample and Hold Circuits ACTIVE WHEN: IR BEAM PASSING THROUGH SEGMENT DESIGNATION SENSOR PULSE IS: Measure Gate MEASUREMENT cell of GFC Wheel HIGH Measure Dark Gate MEASUREMENT Cell of GFC Wheel Reference Gate REFERENCE cell of GFC Wheel HIGH Reference Dark Gate REFERENCE cell of GFC Wheel...
Page 161: Photo-Detector Temperature Control
6.4.3.3 PHOTO-DETECTOR TEMPERATURE CONTROL The sync/demod board also contains circuitry that controls the IR photo-detector’s Thermal Electric Coolers (TEC). A drive voltage, PHT DRIVE, is supplied to the coolers by the sync/demod board which is adjusted by the sync/demod board based on a return signal called TEC control which alerts the sync/demod board of the detector’s temperature.
Page 162: Ir Source
6.4.4.4 IR SOURCE The relay board supplies a constant 11.5VDC to the IR Source. Under normal operation the IR source is always on. Status LEDs Eight LEDs are located on the analyzer’s relay board to show the current status on the various control functions performed by the relay board.
Page 163: I2C Watch Dog Circuitry
The A/D can be configured for several different input modes and ranges but in the T300/T300M is used in uni-polar mode with a +5 V full scale. The converter includes a 1% over and under-range. This allows signals from –0.05 V to +5.05 V to be fully converted.
Page 164: Thermistor Interface
AMPLE RESSURE These are analog signals from two sensors that measure the pressure and flow rate of the gas stream at the outlet of the sample chamber. This information is used in two ways. First, the sample pressure is used by the CPU to calculate CO concentration. Second, the pressure and flow rate are monitored as a test function to assist the user in predicting and troubleshooting failures.
Page 165: External Digital I/O
6.4.5.6 EXTERNAL DIGITAL I/O This External Digital I/O performs two functions: status outputs and control inputs. TATUS UTPUTS Logic-Level voltages are output through an optically isolated 8-pin connector located on the rear panel of the analyzer. These outputs convey good/bad and on/off information about certain analyzer conditions.
Page 166: Figure 6-16. Power Distribution Block Diagram
SENSOR SUITES Sensor Control LOGIC DEVICES ANALOG & I/O Logic AC POWER SENSORS (e.g. CPU and its (e.g. Temp peripheral devices, I DC POWER Sensors, Flow bus, MotherBoard, etc.) Pre-Amplifiers Sensors, & Amplifiers IR, Sensors, PMT HVPS, etc.) OPTIONAL O SENSOR PS 1 +5 VDC...
Page 167: Front Panel Touchscreen/Display Interface
6.4.8 FRONT PANEL TOUCHSCREEN/DISPLAY INTERFACE Users can input data and receive information directly through the front panel touchscreen display. The LCD display is controlled directly by the CPU board. The touchscreen is interfaced to the CPU by means of a touchscreen controller that connects to the CPU via the internal USB bus and emulates a computer mouse.
Page 168: Software Operation
Figure 6-18. Basic Software Operation 6.5.1 ADAPTIVE FILTER The T300/T300M software processes the CO MEAS and CO REF signals, after they are digitized by the motherboard, through an adaptive filter built into the software. Unlike other analyzers that average the output signal over a fixed time period, the T300/T300M averages over a set number of samples, where each sample is 0.2 seconds.
Page 169: Calibration - Slope And Offset
6.5.4 TEMPERATURE AND PRESSURE COMPENSATION Changes in pressure can have a noticeable, effect on the CO concentration calculation. To account for this, the T300/T300M software includes a feature which allows the instrument to compensate for the CO calculations based on changes in ambient pressure.
Page 170 GLOSSARY Note: Some terms in this glossary may not occur elsewhere in this manual. TERM DESCRIPTION/DEFINITION 10Base-T an Ethernet standard that uses twisted (“T”) pairs of copper wires to transmit at 10 megabits per second (Mbps) 100Base-T same as 10BaseT except ten times faster (100 Mbps) APICOM name of a remote control program offered by Teledyne-API to its customers ASSY...
Page 171 TERM DESCRIPTION/DEFINITION DRAM Dynamic Random Access Memory Data Terminal Equipment EEPROM Electrically Erasable Programmable Read-Only Memory also referred to as a FLASH chip or drive Electro-Static Discharge Ethernet a standardized (IEEE 802.3) computer networking technology for local area networks (LANs), facilitating communication and sharing resources Fluorinated Ethylene Propylene polymer, one of the polymers that Du Pont markets as Teflon ®...
Page 172 TERM DESCRIPTION/DEFINITION PTFE Polytetrafluoroethylene, a very inert polymer material used to handle gases that may react on other surfaces; one polymer that Du Pont markets as Teflon ® Poly Vinyl Chloride, a polymer used for downstream tubing Reading RS-232 specification and standard describing a serial communication method between DTE (Data Terminal Equipment) and DCE (Data Circuit-terminating Equipment) devices, using a maximum cable-length of 50 feet RS-485...
Page 173 Control Inputs, 30, 96, 133, 163 Pin Assignments, 31 Control InputS Analog Outputs, 27, 28 Electrical Connections, 30 Electrical Connections, 27 CPU, 33, 99, 113, 114, 117, 118, 119, 133, Output Loop Back, 162 134, 151, 153, 156, 159, 160, 161, 162, 163 Pin Assignments, 27 Critical Flow Orifice, 111, 112, 114, 121, 122, Test Channel, 27...
Page 174 Internal Zero Air (IZS), 39, 46, 50, 122, 130 Gas Flow Problems, 121 Gas Filter Correlation, 14, 115, 137, 138, 143, 145, 146, 154, 155, 159, 163, 166 GFC Wheel, 54, 105, 115, 116, 117, 118, 130, 131, Machine ID, 36 136, 137, 138, 145, 146, 154, 155, 158, 159 Heater, 159, 163 Measure Reference Ratio, 146...
Page 175 Zero/Span/Shutoff Valves, 44 Multidrop, 34, 36 PRES, 104, 105, 111, 116 Shutoff Valve PRESSURE SPAN inlet, 49 Span Gas, 44 SLOPE, 104, 105, 117 PTFE, 37, 42, 43, 45, 46, 48, 90, 110 SOURCE WARNING, 89 SPAN CAL, 49, 50, 51, 52, 104, 133 Remote, 31 Span Gas, 39, 40, 41, 42, 43, 44, 46, 47, 89, RANGE, 116...
Page 176 TIME, 98 CANNOT DYN SPAN, 89, 114 CANNOT DYN ZERO, 89, 114 Touch screen Interface Electronics CONC ALRM1 WARNING, 89 Troubleshooting, 129 CONC ALRM2 WARNING, 89 CONFIG INITIALIZED, 114 DATA INITIALIZED, 114 DCPS, 89 Units of Measurement, 92 PHOTO TEMP WARNING, 114 REAR BOARD NOT DET, 89, 114 RELAY BOARD WARN, 114 SAMPLE FLOW WARN, 89, 114...
Page 177 Appendix A. T300/T300M MODBUS Register Map MODBUS Description Units Register Address (dec., 0-based) MODBUS Floating Point Input Registers (32-bit IEEE 754 format; read in high-word, low-word order; read-only) Detector measure reading Detector reference reading M/R ratio. none Slope for range #1...
Page 178 MODBUS Description Units Register Address (dec., 0-based) Internal box temperature #2/oven °C Internal box temperature #2/oven control duty cycle Fraction (0.0 = off, 1.0 = on full) Auto-zero reading concentration concentration during zero/span calibration, just before computing new slope and offset slope —...
Page 179 MODBUS Description Units Register Address (dec., 0-based) System is OK (same meaning as SYSTEM_OK I/O signal) Purge pressure warning Sample flow warning Internal box temperature #2/oven warning Concentration limit 1 exceeded Concentration limit 2 exceeded Auto-zero warning Sync warning In Hessen manual mode In O calibration mode cell temperature warning...
Page 180 Appendix B 083730300A DCN8101...
