Speco HTBIR1M Instruction Manual

2mp tvi 940nm black ir led motorized zoom focus camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTRUCTION
MANUAL
2MP TVI 940nm Black IR LED
Motorized Zoom Focus Camera
Speco Technologies is constantly developing product improvements.
We reserve the right to modify product design and specifications without notice and without incurring any obligation.
123624.indd 1
HTBIR1M
(Bullet Camera)
Rev. 08/01/2018
2018-08-21 오전 11:39:19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HTBIR1M and is the answer not in the manual?

Questions and answers

Related Manuals for Speco HTBIR1M

Summary of Contents for Speco HTBIR1M

  • Page 1 2MP TVI 940nm Black IR LED Motorized Zoom Focus Camera HTBIR1M (Bullet Camera) Speco Technologies is constantly developing product improvements. We reserve the right to modify product design and specifications without notice and without incurring any obligation. Rev. 08/01/2018 123624.indd 1...

  • Page 2: Table Of Contents

    Contents Contents ............2 ◑ Precautions ..........3, 4 ◑ Safety Instructions ........5 ◑ Package Contents ........6 ◑ Camera Installation ........7-8 ◑ Lens Adjustment ......... 9 ◑ Specifications ..........10 ◑ Camera Dimension ........11 ◑ Features ............12 ◑...

  • Page 3: Precautions

    Precautions Do not install the camera in Do not install the camera under Do not touch the front lens of the extreme temperature conditions. unstable lighting conditions. camera. Only use the camera under conditions Severe lighting change or flicker can This is one of the most important parts of where temperatures are between cause the camera to work improperly.
  • Page 4 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER(OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. ISO14001 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

  • Page 5: Safety Instructions

    Safety Instructions Precautions for use ◑ This camera should be installed by qualified personnel only ◑ There are no user serviceable parts inside ◑ Do not disassemble this camera other than to make initial adjustments ◑ Use a UL approved regulated 24 volt AC or 12 volt DC power supply ◑...

  • Page 6: Package Contents

    Package Contents Please make sure that the following items are included in the Package: 1) HTBIR1M • 1 Video Test Connector, Power Jack • 1 Bracket Base • 1 Wrench • Set Screw - 4 Tapping Screws 4x25 - 4 Hexagon Socket Screws M5x10...

  • Page 7: Camera Installation

    CAMERA INSTALLATION CAMERA INSTALLATION CONNECT POWER CABLE 1. WHEN USING 12 VOLTS DC (constant voltage 500mA) P o w e r In p u t :R E D C e n te r : (+) D C 12V P owe r S upply 2.
  • Page 8 CAMERA INSTALLATION Compatibility 1) HTBIR1M INTCM WALL JUNCTION BOX SCREW-TAP,WHT,-,TH_M4X25,TP1, 4EA SCREW-MS HEX,BLK,SUS,M5X10, 4EA - 8 - 123624.indd 8 2018-08-21 오전 11:39:28...

  • Page 9: Lens Adjustment

    LENS ADJUSTMENT 1) HTBIR1M Open the cap VIDEO TEST SET UP LED LEVEL - 9 - 123624.indd 9 2018-08-21 오전 11:39:28...

  • Page 10: Specifications

    2MP TVI 940nm Black IR LED Motorized Zoom Focus Camera with included Junction Box 2.8-12mm MFZ Lens ■ HTBIR1M (2.8-12mm) SPECIFICATIONS IUCJS2N Image Sensor 1/2.9 Inch SONY 2Mega CMOS Sensor Pixels - total 2001 (H) X 1121 (V) Pixels - Effective...

  • Page 11: Camera Dimension

    CAMERA DIMENSION 1) HTBIR1M 8.56” 3.90” 4.80” 2.95” - 11 - 123624.indd 11 2018-08-21 오전 11:39:30...

  • Page 12: Features

    TV system is switchable 'NTSC' or 'PAL' with built-in OSD. Intelligent Function ● An extraordinary technology that enables Speco Technologies TVI to become the ultimate solution by providing intelligent features based on motion detection. It also strengthens crime prevention and detection.

  • Page 13: Osd Menu Details

    V-POS 0~19 H-SIZE 0~20 V-SIZE 0~19 RETURN WEIGHT LOW / MIDDLE / HIGH RETURN 5. SPECO DNR OFF / LOW / MIDDLE / HIGH 6. DAY&NIGHT AUTO SMART IR 0~20 AGC THRES 0~20 AGC MARGIN 0~20 DELAY LOW / MIDDLE / HIGH...
  • Page 14 How to Set Up the camera menu ● Setup Menu MENU 7. IMAGE SHARPNESS 0~20 GAMMA 0.45 ~ 0.65 COLOR GAIN 0~20 MIRROR ON / OFF FLIP ON / OFF OFF / LOW / MIDDLE / HIGH DEFOG MODE AUTO / MANUL LEVEL LOW / MIDDLE / HIGH RETURN...
  • Page 15 Menu Set Up Menu items can be selected by using the OSD buttons of the camera. 1. PRESET SPECO TECH 1. PRESET INDOOR 2.MAIN SETUP 3.EXIT 1-1. Preset : INDOOR / OUTDOOR / LOW LIGHT / HALLWAY / LOBBY(WDR) / ELEVATOR.
  • Page 16 1. Move the triangular indicator to 2MOTOR using the Up and Down buttons on the Set Up menu screen. 2. Select the desired lens type by pressing the Left of Right button. MENU 1.2MOTOR AUTO 2.EXPOSURE 3.WHITE BAL AUTO 4.BACKLIGHT 5.SPECO DNR MIDDLE 6.DAY&NIGHT AUTO 7.IMAGE 8.MOTION 9.SYSTEM 10.RETURN - 16 - 123624.indd 16...
  • Page 17 ◆ INITIAL : If you press OSD button 3~4 seconds, Lens Initializing start. EXPOSURE 1. On the Set Up menu, Select EXPOSURE by using the Up or Down button. MENU 1.2MOTOR 2.EXPOSURE 3.WHITE BAL AUTO 4.BACKLIGHT 5.SPECO DNR MIDDLE 6.DAY&NIGHT AUTO 7.IMAGE 8.MOTION 9.SYSTEM 10.RETURN - 17 - 123624.indd 17...
  • Page 18 2. Select the desired shutter mode by pressing the Left or Right button. 2. EXPOSURE BRIGHTNESS IIIIIIIIIIIIIIIIIII| SHUTTER AUTO INTENSIFY 20 IIIIIIIIIIIIIIIIIII| RETURN ◆ BRIGHTNESS : The brightness can be adjusted. The brightness control range is 1~20. ◆ SHUTTER : DC lens is launched with the setting of 1/30 and the manual lens is launched with the setting of Auto shutter, but the shutter speed can be adjusted from 1/30 to 1/30,000.
  • Page 19 1. Move the triangular indicator to WHITE BAL on the SETUP menu screen using the Up and Down button. 2. Select the desired mode by using the left or Right button. MENU 1.2MOTOR 2.EXPOSURE 3.WHITE BAL AUTO 4.BACKLIGHT 5.SPECO DNR MIDDLE 6.DAY&NIGHT AUTO 7.IMAGE 8.MOTION 9.SYSTEM 10.RETURN ◆...
  • Page 20 1. Move the triangular indicator to BACKLIGHT on the SETUP menu screen using the Up and Down button. 2. Select the desired mode by using the left or Right button. MENU 1.2MOTOR 2.EXPOSURE 3.WHITE BAL AUTO 4.BACKLIGHT 5.SPECO DNR MIDDLE 6.DAY&NIGHT AUTO 7.IMAGE 8.MOTION 9.SYSTEM 10.RETURN ◆...
  • Page 21 LEVEL 10 IIIIIIIIIIIIIIIIIII| MODE ALL DAY RETURN ◆ BLC : This function is used to counterbalance the screen image by increasing the brightness so that a subject which appears dark due to a strong backlight can be displayed in more detail. If you select BLC, a submenu appears where you can make finer adjustments.
  • Page 22 You can set different levels here. 1. Move the triangular indicator to SPECO DNR by useing the Up and Down button. 2. Select the mode to use by pressing the left or Right button and OFF/LOW/MIDDLE/HIGH level selectable.
  • Page 23 - DELAY [LOW/MIDDLE/HIGH] : Set the delay time for switching between COLOR and B/W IMAGE When selecting, the following submenu will appear. MENU 1.2MOTOR 2.EXPOSURE 3.WHITE BAL AUTO 4.BACKLIGHT 5.SPECO DNR MIDDLE 6.DAY&NIGHT AUTO 7.IMAGE 8.MOTION 9.SYSTEM 10.RETURN - 23 - 123624.indd 23...
  • Page 24 Here you can optimise the image quality by adjusting different options. 7. IMAGE SHARPNESS 11 IIIIIIIIIIIIIIIIIII| GAMMA COLOR GAIN 13 IIIIIIIIIIIIIIIIIII| MIRROR FLIP DEFOG PRIVACY RETURN ◆ SHARPNESS [1 ~ 20] : Adjusts the image sharpness. If the level goes up excessively, it may affect the video image and generate a noise.
  • Page 25 This function is used to detect moving objects in the monitored area. When choosing ON, the following submenu will appear where you can adjust the settings for the MOTION function. MENU 1.2MOTOR 2.EXPOSURE 3.WHITE BAL AUTO 4.BACKLIGHT 5.SPECO DNR MIDDLE 6.DAY&NIGHT AUTO 7.IMAGE 8.MOTION 9.SYSTEM 10.RETURN - 25 - 123624.indd 25...
  • Page 26 1.When the SETUP menu is displayed, select SYSTEM using the Up and Down button. 2. Select one of the mode using the Up and Down button. MENU 1.2MOTOR 2.EXPOSURE 3.WHITE BAL AUTO 4.BACKLIGHT 5.SPECO DNR MIDDLE 6.DAY&NIGHT AUTO 7.IMAGE 8.MOTION 9.SYSTEM 10.RETURN - 26 - 123624.indd 26...
  • Page 27 9.SYSTEM COM. IMAGE RANGE USER FRAME RATE 1080_30P COLOR SPACE HD-Cbcr CVBS NTSC LANGUAGE COLOR BAR RESET RETURN ◆ COM. : This menu id used for RS-485 communication. Users are able to select 'CAM ID(0~255)' and 'BAU DRATE(2400/4800/9600/57600/115200). - CAM ID : 1 - BAUDRATE : 9600 ◆...

  • Page 28: Trouble Shooting

    Trouble Shooting PROBLEM POSSIBLE CAUSE Nothing appears on ☞ Check the power cable, power supply output and video the screen. connection between the camera and monitor. ☞ Are the camera lens or the lens glass dirty? Clean the lens / glass with a soft clean cloth. The image on the ☞...
  • Page 29 123624.indd 29 2018-08-21 오전 11:39:36...
  • Page 30 123624.indd 30 2018-08-21 오전 11:39:37...
  • Page 31 123624.indd 31 2018-08-21 오전 11:39:37...
  • Page 32 200 New Highway Amityville, NY 11701 631-957-8700 1 800 645 5516 www.specotech.com 123624.indd 32 2018-08-21 오전 11:39:37...
