Speco HTB11FFi User Manual

580 line color bullet camera/intensifier 2 series/focus free wall & ceiling mountable
Hide thumbs Also See for HTB11FFi:

Advertisement

HTB11FFi
HTB11FFi
580 Line Color Bullet Camera
Intensifier 2 Series, Focus Free
Wall & Ceiling Mountable
Please read this manual thoroughly before operation and keep
it handy for further reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HTB11FFi and is the answer not in the manual?

Questions and answers

Summary of Contents for Speco HTB11FFi

  • Page 1 HTB11FFi HTB11FFi 580 Line Color Bullet Camera Intensifier 2 Series, Focus Free Wall & Ceiling Mountable Please read this manual thoroughly before operation and keep it handy for further reference.
  • Page 2 WARNING & CAUTION CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK D O N O T R E M O V E C O V E R ( O R B A C K ) . N O U S E R S E R V I C E A B L E P A R T S I N S I D E R E F E R S E R V I C I N G T O...
  • Page 3: Table Of Contents

    CONTENTS Package Contents Precautions Camera Installation 6-10 Features 11-12 OSD Menu Tree OSD Menu Details 14-17 18-19 Troubleshooting Specifications Dimensions Warranty...
  • Page 4: Package Contents

    PACKAGE CONTENTS Please make sure that the following items are included in the package: 1 HTB11FFI Camera 1 HTB11FFI Camera 4 Mounting Screws 1 Video test Connector 1 Extra Mount Plate 1 Wrench Please leave this manual with the end-user for future reference reference.
  • Page 5: Precautions

    PRECAUTIONS • THIS CAMERA SHOULD BE ONLY INSTALLED BY QUALIFIED PERSONNEL • TO PREVENT A FIRE OR ELECTRICAL HAZARD PLEASE USE PROPER POWER CABLE • DO NOT CLEAN THE FRONT COVER WITH AN ABRAISIVE CLEANING MATERIAL - PLEASE USE A SOFT CLOTH OR TISSUE TO CLEAN THE FRONT COVER •...
  • Page 6: Camera Installation

    CAMERA INSTALLATION CONNECT POWER CABLE 1. WHEN USING 12 VOLTS DC (constant voltage 500 mA) Power Input :RED Center : (+) DC 12V Power Supply 2. WHEN USING 24 VOLTS AC (40 Volt Amps) RED(+) AC 24V BLACK:(-) Power Supply 3.
  • Page 7: Control Board

    CAMERA INSTALLATION CONTROL BOARD 1) Video Test Terminal : For second video output 2) OSD (On Screen Display) Joy stick p y) : Press the Joy stick for one second until the OSD menu tree appears on the screen. Move the Joy Stick up, down, left & right to control the OSD functions.
  • Page 8 CAMERA INSTALLATION DIP Switch Setting for RS-485 (Pelco-D) Address Baud Rate 1) Address Setting to set Camera Address, place switches based on below chart. 2) Baud rate Setting to set Baud rate, please refer the chart below.
  • Page 9 CAMERA INSTALLATION COMPATIBILITY “A” type Box “B” type Box CVCTPEXT CVCTPLATE ★Original Base part Should be taken away to use CVCTPLATE [CVCTPLATE Hole Description] Hole 1 : CVCTPEXT Hole 2 : Electrical Box “B” type Hole 2 : Electrical Box B type Hole 3 : Electrical Box “A”...
  • Page 10: Camera Installation

    CAMERA INSTALLATION COMPATIBILITY ( USING 7246WMT CVCTPEXT CVCTPLATE BCP (Direct connection )
  • Page 11: Features

    INTENSIFIER 1/3 inch density CCD and digital processor permit high quality Pictures to be captured in very low light condition. SPECO DNR SPECO DNR The Intensifier camera has a DSP chip that can remove image noise efficiently showing clean images in low light conditions.
  • Page 12 FEATURES All camera functions are menu driven for easy use. When the image is in front of strong background lighting, th i i i f t f t d li hti your camera allows you to get the clear image. HLC (High Light Compensation) This function reverses bright spots in the picture (such as headlights).
  • Page 13: Osd Menu Tree

    DC IRIS INTENSIFIER E SHUTTER AUTO GAIN INTENSIFY RETURN COLOR TEMP COLOR TEMP INDOOR OUTDOOR AWC SET MANUAL WDR SET SPECO DNR DAY & NIGHT COLOR AUTO TWEAK VIDEO STILL PIX V-REVERSE H-REVERSE RETURN DIGI-ZOOM CLARITY PAGE 2 V MOTION...
  • Page 14: Osd Menu Details

    OSD MENU DETAILS 1 INTENSIFIER 1. INTENSIFIER [OPTION : E SHUTTER / AUTO GAIN / INTENSIFY / RETURN] - E SHUTTER * FLK - Flicker-less mode (FLK) reduces on-screen flickering. * ESC - Electronic Shutter Control (AUTO) adjusts brightness level on screen. - AUTO GAIN AUTO GAIN Adjusts value of AGC gain and increases the GAIN level to...
  • Page 15 3 WDR SET 3. WDR SET [OPTION : SLC / HLC / OFF] - SLC (Speco Light Compensation) Provides light level control to overcome severe back light condition. - HLC (High Light Compensation) High Light Compensation removes the high light and makes possible to view the image clearly view the image clearly.
  • Page 16 OSD MENU DETAILS 7 CAM TITLE 7. CAM TITLE [OPTION : ON / OFF] - Display a name and/or number on the monitor you prefer. 8. SYNC TYPE [OPTION : INT / LL] - INTERNAL : When line lock is not required. - LINELOCK : Adjust the vertical phase (VPH) from 000~ 359 (factory default is 0).
  • Page 17: Osd Menu Details

    OSD MENU DETAILS 10 PRIVACY 10. PRIVACY [OPTION : ON / OFF] - Mask up to 8 areas of the screen from video monitoring. - AREA SEL : Select up to 8 motion detection area. - AREA mode : Activate or deactivate the selected area. - MASK COLOR : Select area color.
  • Page 18: Troubleshooting

    TROUBLESHOOTING If you have trouble operating your camera refer to the following If you have trouble operating your camera, refer to the following Problem Solution ● Check that the power cord and line connection Nothing appears on between the camera and monitor are proper the screen.
  • Page 19: Troubleshooting

    TROUBLESHOOTING Problem Solution ● Check that you have properly set the The color of the picture is not ‘ WHITE BALANCE ’ menu matched. ● Is the camera facing to direct sunlight or fluorescent The image on the screen flickers. lighting? Change the camera position.
  • Page 20: Specifications

    SPECIFICATIONS ITEM HTB11FFI Power Source 12VDC & 24VAC ( Dual Voltage ) Power Consumption 500mA (DC) / 6.6W (AC) Image Sensor 1/3”, SONY SUPER HAD CCD, 410,000 pixels Total Pixels 811(H) x 508(V) , 1/3” CCD Effective Pixels 768(H) x 494(V) , 1/3” CCD Focus Free Lens 2.8~10mm...
  • Page 21: Dimensions

    DIMENSIONS * FRONT VIEW * SIDE VIEW * SIDE VIEW...
  • Page 22: Warranty

    WARRANTY...
  • Page 23 MEMO...
  • Page 24 200 New Highway Amityville, NY 11701 631-957-8700 www.specotech.com Rev. 100120 Speco Technologies is constantly developing product improvements. We reserve the right to modify product design and specifications without notice and without incurring any obligation.
