INSTRUCTION
MANUAL
Intense-IR Series 1000TVL
Speco Technologies is constantly developing product improvements.
We reserve the right to modify product design and specifications without notice and without incurring any obligation.
HT7040K
(IR Bullet Camera)
HT6040K
(IR Turret Camera)
HT5940K
(IR Dome Camera)
Rev. 02/01/2014

Advertisement

Table of Contents
loading

Related Manuals for Speco HT7040K

Summary of Contents for Speco HT7040K

  • Page 1 Intense-IR Series 1000TVL HT7040K (IR Bullet Camera) HT6040K (IR Turret Camera) HT5940K (IR Dome Camera) Speco Technologies is constantly developing product improvements. We reserve the right to modify product design and specifications without notice and without incurring any obligation. Rev. 02/01/2014...

  • Page 2: Table Of Contents

    Contents Contents ............1 ◑ Precautions ..........2, 3 ◑ Safety Instructions ........4 ◑ Package Contents ........5 ◑ Camera Installation ........6-11 ◑ Specifications ..........12-14 ◑ Camera Dimension ........15-16 ◑ Features ............17 ◑ OSD Menu Details ........18- 41 ◑...

  • Page 3: Precautions

    Precautions Do not install the camera in Do not install the camera under Do not touch the front lens of the extreme temperature conditions. unstable lighting conditions. camera. Only use the camera under conditions Severe lighting change or flicker can This is one of the most important parts of where temperatures are between cause the camera to work improperly.
  • Page 4 CAUTION CAUTION CAUTION RISK OF ELECTRIC SHOCK RISK OF ELECTRIC SHOCK RISK OF ELECTRIC SHOCK DO NOT OPEN DO NOT OPEN DO NOT OPEN CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER(OR BACK).

  • Page 5: Safety Instructions

    Safety Instructions Precautions for use ◑ This camera should be installed by qualified personnel only ◑ There are no user serviceable parts inside ◑ Do not disassemble this camera other than to make initial adjustments ◑ Use a UL approved regulated 24 volt AC or 12 volt DC power supply ◑...

  • Page 6: Package Contents

    Package Contents Please make sure that the following items are included in the Package: 1) HT7040K • 1 Video Test Connector, Power Jack • 1 Focus Adjustment • 1 Bracket Base • 1 Wrench • Set Screw - 4 Tapping Screws 4x25...

  • Page 7: Camera Installation

    CAMERA INSTALLATION...
  • Page 8 CAMERA INSTALLATION Compatibility 1) HT7040K CVCJBB INTJBS INTCM 2) HT6040K CVCJBD → Adaptor plate(60PLATE) with rubber...
  • Page 9 CAMERA INSTALLATION Compatibility 3) HT5940K CVCJBD → Adaptor plate(59PLATE) with rubber...
  • Page 10 CAMERA INSTALLATION 1. HT7040K WALL SCREW TS T1, 4X25, TH, SUS, 4EA 3AXIS BRACKET SCREW M5X10, HEXAGON SOCKET, SUS, BK, 4EA...
  • Page 11 CAMERA INSTALLATION 2. HT6040K BALL DOME BASE SCREW TS T1, 4X25, TH, SUS, 3EA BALL DOME BALL DOME BODY...
  • Page 12 CAMERA INSTALLATION 3. HT5940K VANDAL DOME BASE SCREW TS T1, 3.5X20, PH, SUS, 3EA VANDAL DOME BODY BODY OUTER COVER SPECO...

  • Page 13: Specifications

    Intense-IR Series 1000TVL DC Auto Iris Varifocal Lens 2.8-12mm ■ HT7040K SPECIFICATIONS HT7040K Image Sensor 1/3" 1.3MP SONY Sensor Resolution 1000TV Lines Effective Pixels 1305(H) X 1049(V), 1.37M Pixels Total Pixels 1312(H) X 1069(V), 1.40M Pixels Scanning System Progressive Scan...
  • Page 14 Intense-IR Series 1000TVL DC Auto Iris Varifocal Lens 2.8-12mm ■ HT6040K SPECIFICATIONS HT6040K Image Sensor 1/3" 1.3MP SONY Sensor Resolution 1000TV Lines Effective Pixels 1305(H) X 1049(V), 1.37M Pixels Total Pixels 1312(H) X 1069(V), 1.40M Pixels Scanning System Progressive Scan S/N Ratio More than 50dB Frame rate...

  • Page 15: Specifications

    Intense-IR Series 1000TVL DC Auto Iris Varifocal Lens 2.8-12mm ■ HT5940K SPECIFICATIONS HT5940K Image Sensor 1/3" 1.3MP SONY Sensor Resolution 1000TV Lines Effective Pixels 1305(H) X 1049(V), 1.37M Pixels Total Pixels 1312(H) X 1069(V), 1.40M Pixels Scanning System Progressive Scan S/N Ratio More than 50dB Frame rate...

  • Page 16: Camera Dimension

    CAMERA DIMENSION 1) HT7040K 8.27” 3.94” dia 4.80” 3.38” 2.95” 2) HT6040K 4.65” dia...
  • Page 17 CAMERA DIMENSION 3) HT5940K 3.23” dia...

  • Page 18: Features

    General Features 1000 TV Lines ● 1.3 MEGA HD ANALOG 1000 TVL combined with SONY EXMOR SENSOR (IMX 138) WDR (Wide Dynamic Range) ● A powerful and ultra-advanced technology that captures cleaner and superior high resolution picture even where images appear dark because there is a strong back light present. PRESET ●...

  • Page 19: Osd Menu Details

    How to Set Up the camera menu ● Setup Menu PRESET MODE MENU MAIN SETUP PRESET INDOOR OUTDOOR LOW LIGHT HALL WAY LOBBY ELEVATOR MAIN SETUP EXIT MODE INDOOR / OUTDOOR/ DEBLUR RETURN LENS MODE NORMAL / DEBLUR MANUAL RETURN 0 ~ 20 BRIGHTNESS AUTO...
  • Page 20 How to Set Up the camera menu ● Setup Menu MIDDLE HIGH SMART IR 0 ~ 20 AGC THRES 0 ~ 20 AUTO AGC MARGIN 0~ 20 DELAY LOW / MIDDLE / HIGH RETURN COLOR DAY&NIGHT 0 ~ 20 SMART IR RETURN SMART IR 0 ~ 20...
  • Page 21 How to Set Up the camera menu ● Setup Menu D-ZOOM 1.0X ~ 8.0X D-WDR OFF / LOW / MIDDLE / HIGH AUTO MODE MANUAL DEFOG LEVEL MIDDLE HIGH RETURN 0 ~ 100% WEIGHT SHADING RETURN 0 ~ 15 ZONE NUM ON / OFF ZONE DISP H-POS...
  • Page 22 * MENU will be displayed on the monitor. ◆ MENU → PRESET : Preset is provided to maximize user convenience. ( PRESET : Indoor // Outdoor // Low light // Hallway // Lobby // Elevator ) SPECO TECH 1. PRESET INDOOR 2. MAIN SETUP 3.

  • Page 23: Menu Setup

    1. Press the set button. * The Set Up menu will be displayed on the monitor. MENU 1. LENS 2. EXPOSURE 3. WHITE BAL 4. BACKLIGHT 5. SPECO DNR MIDDLE 6. DAY&NIGHT AUTO 7. IMAGE 8. SYSTEM 9. SPECIAL 10. EXIT 2.
  • Page 24 1. Move the triangular indicator to LENS using the Up and Down buttons on the Set Up menu screen. 2. Select the desired lens type by pressing the Left of Right button. MENU 1. LENS 2. EXPOSURE 3. WHITE BAL 4. BACKLIGHT 5. SPECO DNR MIDDLE 6. DAY&NIGHT AUTO 7. IMAGE 8. SYSTEM 9. SPECIAL...
  • Page 25 1. Move the triangular indicator to EXPOSURE on the SETUP menu screen using the Up and Down button 2. Select the desired mode using the Left or Right buttons. MENU 1. LENS 2. EXPOSURE 3. WHITE BAL 4. BACKLIGHT 5. SPECO DNR MIDDLE 6. DAY&NIGHT AUTO 7. IMAGE 8. SYSTEM 9. SPECIAL 10.
  • Page 26 → SHUTTER : Users adjust electronic shutter speed by selecting one of modes(AUTO, MANUAL, FLICKER). 2. EXPOSURE BRIGHTNESS IIIIIIIIII IIIIIIIIII SHUTTER MANUAL SENSE-UP IIIIIIIIII IIIIIIIIII RETURN Manaul mode : shutter speed is adjustable from 1/60 up to 1/60,000. SHUTTER SPEED 1/60 RETURN →...

  • Page 27: White Balance

    1. Move the triangular indicator to WHITE BAL on the SETUP menu screen using the Up and Down button. 2. Select the desired mode by using the left or Right button. MENU 1. LENS 2. EXPOSURE 3. WHITE BAL 4. BACKLIGHT 5. SPECO DNR MIDDLE 6. DAY&NIGHT AUTO 7. IMAGE 8. SYSTEM 9. SPECIAL 10.

  • Page 28: Back Light

    1. Move the triangular indicator to BACKLIGHT on the SETUP menu screen using the Up and Down button 2. Select the desired mode using the Left or Right buttons. MENU 1. LENS 2. EXPOSURE 3. WHITE BAL 4. BACKLIGHT 5. SPECO DNR MIDDLE 6. DAY&NIGHT AUTO 7. IMAGE 8. SYSTEM 9. SPECIAL...
  • Page 29 At the area is set up specifically, you can recognize the car plate numbers by blocking the strong light signal. MENU 1. LENS 2. EXPOSURE 3. WHITE BAL 4. BACKLIGHT 5. SPECO DNR MIDDLE 6. DAY&NIGHT AUTO 7. IMAGE 8. SYSTEM 9. SPECIAL 10.
  • Page 30 → BLC : The set up area can be seen vividly by the user who set up the desired area to compensate the back light directly according to the installation environment. MENU 1. LENS 2. EXPOSURE 3. WHITE BAL 4. BACKLIGHT 5. SPECO DNR MIDDLE 6. DAY&NIGHT AUTO 7. IMAGE 8. SYSTEM 9. SPECIAL 10.
  • Page 31 ( To adjust WDR level, select the LOW, MIDDLE, HIGH by pressing the left or the right button ) MENU 1. LENS 2. EXPOSURE 3. WHITE BAL 4. BACKLIGHT 5. SPECO DNR MIDDLE 6. DAY&NIGHT AUTO 7. IMAGE 8. SYSTEM 9.
  • Page 32 2. Select one of modes(OFF, LOW, MIDDLE, HIGH) to use DNR by pressing the Right or Left button. MENU 1. LENS 2. EXPOSURE 3. WHITE BAL 4. BACKLIGHT 5. SPECO DNR MIDDLE 6. DAY&NIGHT AUTO 7. IMAGE 8. SYSTEM 9. SPECIAL 10.
  • Page 33 1. Select DAY&NIGHT using the Up or Down button on the Set Up menu screen. 2. Select one of modes (EXTERN, AUTO, COLOR, B/W) using the Left or Right buttons. MENU 1. LENS 2. EXPOSURE 3. WHITE BAL 4. BACKLIGHT 5. SPECO DNR MIDDLE 6. DAY&NIGHT AUTO 7. IMAGE 8. SYSTEM 9. SPECIAL 10.
  • Page 34 1.When the SETUP menu is displayed, select IMAGE using the Up and Down button. 2. Select one of the mode using the Left or Right buttons. MENU 1. LENS 2. EXPOSURE 3. WHITE BAL 4. BACKLIGHT 5. SPECO DNR MIDDLE 6. DAY&NIGHT AUTO 7. IMAGE 8. SYSTEM 9. SPECIAL 10.
  • Page 35 1.When the SETUP menu is displayed, select SYSTEM using the Up and Down button. 2. Select one of the mode using the Left or Right buttons. MENU 1. LENS 2. EXPOSURE 3. WHITE BAL 4. BACKLIGHT 5. SPECO DNR MIDDLE 6. DAY&NIGHT AUTO 7. IMAGE 8. SYSTEM 9. SPECIAL...
  • Page 36 8. SYSTEM COM. VIEW ANGLE WIDE 4 : 3 CVBS NTSC LANGUAGE RETURN ◆ SYSTEM → COM : this menu is used for RS-485 communication. Users are able to select 'CAM ID (0 ~ 255)' and 'BAUDRATE (2400 / 4800 / 9600 / 57600 / 115200)'. COM.
  • Page 37 SYSTEM SYSTEM COM. COM. VIEW ANGLE WIDE 16 : 9 VIEW ANGLE NORMAL XY ADJUST XY ADJUST LANGUAGE LANGUAGE RETURN RETURN For further adjustment, please enter into 'XY ADJUST' on 'WIDE 16:9' or 'NORMAL'. XY ADJUST XY ADJUST (+0 /±0) (+0 /±160) LEFT / RIGHT LEFT / RIGHT...
  • Page 38 2. Select one of the mode using the Left or Right buttons. SPECIAL MENU 1. LENS D-ZOOM 1. 0X 2. EXPOSURE D-WDR 3. WHITE BAL DEFOG 4. BACKLIGHT SHADING 5. SPECO DNR MIDDLE PRIVACY 6. DAY&NIGHT AUTO INTELLIGENT 7. IMAGE RETURN 8. SYSTEM 9. SPECIAL 10. EXIT ◆ SPECIAL →...
  • Page 39 → D-WDR : This camera which is using 3D-DNR DSP provides intelligent light level control to overcome even strong backlight conditions. (OFF / LOW / MIDDLE / HIGH) → DEFOG : This function helps to recognize the object in a foggy or dusty weather condition. DEFOG MODE AUTO...
  • Page 40 PRIVACY ZONE NUM ZONE DISP H-POS V-POS H-SIZE V-SIZE Y LEVEL IIIIIIIIII IIIIIIIIII CR LEVEL IIIIIIIIII IIIIIIIIII VB LEVEL IIIIIIIIII IIIIIIIIII RETURN → INTELLIGENT : It is used for crime prevention & detection by providing intelligent functions based on motion tracking. INTELLIGENT MTN TRACKER ALARM...
  • Page 41 2) ALARM : it is used to set 'ANTI-SHIFT' or 'ANTI-BLOCK' based on motion tracking. scale level of these functions are adjustable. ALARM ANTI-SHIFT SHIFT SCALE IIIIIIIIII IIIIIIIIII IIIIIIIIII ANTI-BLOCK BLOCK SCALE IIIIIIIIIIIIIIIIIIII RETURN * ANTI-SHIFT : If someone intends to change or shift camera direction by their hands or objects, it will be automatically detected by a warning message(SHIFTING DETECTED !!!) on monitor.
  • Page 42 RETURN MOTION DETECTED !!! 10. EXIT MENU 1. LENS 2. EXPOSURE 3. WHITE BAL 4. BACKLIGHT 5. SPECO DNR MIDDLE 6. DAY&NIGHT AUTO 7. IMAGE 8. SYSTEM 9. SPECIAL 10. EXIT Press 'EXIT' button to save the current settings and exit the setup menu.

  • Page 43: Trouble Shooting

    Trouble Shooting ● PROBLEM POSSIBLE CAUSE FCheck the power cable, power supply output and video Northing appears on connection between the camera and monitor. the screen. FAre the camera lens or the lens glass dirty? Clean the lens / glass with a soft clean cloth. The image on the FAdjust the monitor controls, as required.
  • Page 45 uMEMO...
  • Page 46 uMEMO...
  • Page 47 uMEMO...
  • Page 48 200 New Highway Amityville, NY 11701 631-957-8700 1 800 645 5516 www.specotech.com...
