- Page 1 INSTRUCTION MANUAL 700TVL Miniature Camera HT770PH (Miniature Board Camera) CVC130H (Miniature Weather Resistant Bullet Camera)
-
Page 2: Table Of Contents
Contents Contents ............1 Precautions ..........2, 3 Safety Instructions ........4 Package Contents ........5 Camera Installation ........6-12 6SHFL¿FDWLRQV ..........13-16 Camera Dimension ........17-18 Features ............19 OSD Menu Details ........20- 34 Trouble Shooting ......... 35 - 1 -... -
Page 3: Precautions
Precautions Do not install the camera in Do not install the camera under Do not touch the front lens of the extreme temperature conditions. unstable lighting conditions. camera. Only use the camera under conditions Severe lighting change or flicker can This is one of the most important parts of where temperatures are between cause the camera to work improperly. - Page 4 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER(OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. ISO14001 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
-
Page 5: Safety Instructions
Safety Instructions 7KLV FDPHUD VKRXOG EH LQVWDOOHG E\ TXDOL¿HG SHUVRQQHO RQO\ There are no user serviceable parts inside Do not disassemble this camera other than to make initial adjustments Use a UL approved regulated 24 volt AC or 12 volt DC power supply 8VH DSSURSULDWH ORZ YROWDJH SRZHU FDEOH WR SUHYHQW ¿UH RU HOHFWULFDO VKRFN Please insure that your installation area can support the weight of the camera Do not use a strong or abrasive detergent when cleaning the camera... -
Page 6: Package Contents
Package Contents Please make sure that the following items are included in the Package: 1) HT770PH q 8KFGQ 6GUV %QPPGEVQT 2QYGT ,CEM q 5GV 5ETGY - 2 Tapping Screws M3x10 - 2 Machine Screws M2x3 q $TCEMGV 2) CVC130H... -
Page 7: Specifications
Speco Technologies (Miniature Board Camera) 3.7mm Fixed Board Lens +73+ SPECIFICATIONS 02'(/ HT770PH 1/3” Inch Color 960H CCD Sensor type 976 (H) X 494 (V) approx. 480K pixels (NTSC) Effective pixels 976 (H) X 582 (V) approx. 570K pixels (PAL) 1020 (H) X 508 (V) approx. - Page 8 Speco Technologies (Miniature Weather Resistant Bullet Camera) 3.6mm Fixed Board Lens &9&+ SPECIFICATIONS 02'(/ CVC130H 1/3” Inch Color 960H CCD Sensor type 976 (H) X 494 (V) approx. 480K pixels (NTSC) Effective pixels 976 (H) X 582 (V) approx. 570K pixels (PAL) 1020 (H) X 508 (V) approx.
-
Page 9: Camera Dimension
CAMERA DIMENSION 1. HT770PH 1.34” 0.75” 2. CVC130H 2.87” 0.83”Dia - 8 -... - Page 10 700TV Lines The combination of a 960H CCD image sensor and SPECO DSP provides an excellent resolution of 700TV Lines. 3D-DNR Smart 3DNR prevents the image blurring of moving object and activates only if moving objects are appearing on the scene.
- Page 11 Menu setting can be selected by the button inside the camera. 1. Press and hold the set button. * The Set Up menu will be displayed on the monitor. SPECO LENS DCAUTO EXPOSURE WHITE BAL DAY&NIGHT COLOR 3DNR SPECIAL ADJUST...
- Page 12 This function is to adjust the brightness of the monitor. 1. Move the triangular indicator to LENS using the Up and Down buttons on the Set Up menu screen. 2. Select the desired lens type by pressing the Left of Right button. SPECO LENS DCAUTO...
- Page 13 1. On the Set Up menu, Select EXPOSURE by using the Up or Down button. SPECO LENS EXPOSURE WHITE BAL DAY&NIGHT COLOR 3DNR SPECIAL ADJUST RESET EXIT 2. Select the desired shutter mode by pressing the Left or Right button.
- Page 14 NOTE *Sense Up mode does not work while the Electronic shutter is set to Manual or DIS. Sense-Up : The bright screen can be displayed by sensing the degree of the darkness automatically under the circumstance of low light condition or at night. Off : Deactivated status.
- Page 15 HSBLC (Highlight Suppression Back Light Compensation) : When there is a car head light turned on at the entrance of the gas station or in some place in the parking lot, the numbers of the car plate can be recognized by blocking only the light from the car headlight. The area is set up specifically so you can recognize the car plate numbers by blocking out the strong light.
- Page 16 Use this function when the color adjustment of a screen is needed. 1. Move the triangular indicator to WHITE BAL on the SETUP menu screen using the Up and Down button. 2. Select the desired mode by using the left or Right button. SPECO LENS EXPOSURE WHITE BAL DAY&NIGHT...
- Page 17 You can change the color mode of color or black / white by setting up the mode. 1. Select Day&Night using the Up or Down button on the Set Up menu screen. 2. Select the desired mode using the Left or Right buttons. SPECO LENS EXPOSURE WHITE BAL DAY&NIGHT...
- Page 18 This function decreases the noise in the low light background. 1. Move the triangular indicator to 3DNR by using the Up or Down button. 2. Select the mode to use by pressing the Right or Left button. SPECO LENS EXPOSURE WHITE BAL DAY&NIGHT...
- Page 19 This can be used when you want to select the additional function control. 1.When the SETUP menu is displayed, select SPECIAL using the Up and Down button. 2. Select one of the mode using the Up and Down button. SPECO LENS EXPOSURE WHITE BAL DAY&NIGHT...
- Page 20 CAM (Camera) TITLE : It can be adjusted when you get into the Cam Title menu. This function is to display the letters of the camera on the monitor. The 15 characters can be displayed and the location of the camera title on the screen can be adjusted. Move the triangular indicator to CAMERA ID using the Up and Down button on the Setup menu and then Set to On using the Left or Right button.
- Page 21 D-Zoom : You can use the digital zoom with x1 ~ x32 magnification. The higher the digital zoom magnification is, the lower the resolution is. D-ZOOM RANGE x2.0 IIIIIIIIII IIIIIIIIII TILT IIIIIIIIII IIIIIIIIII RETURN NOTE * When you use the digital zoom, SMART DZOOM and DIS cannot be used. SMART DZOOM : This function is interlocked with Digital-Zoom to distinguish a specific object in more detail when there is a movement detected in a certain area.
- Page 22 DIS (Digital Image Stabilizer) : DIS offers to compensate for the ghost effect and gives a clear image in a low light condition. DIS OFF DIS ON NEG. IMAGE - On : Activate a negative image just like a film. - Off : Normal image.
- Page 23 PRIVACY : This is used to hide certain areas on the monitor. You can designate up to 8 different areas. The size of a designated area can be adjusted. The color of a privacy area can be changed to 15 different colors.
- Page 24 This function is needed to control the brightness of the monitor. 9JGP VJG 5GV 72 OGPW KU FKURNC[GF UGNGEV #&,756 WUKPI VJG 7R CPF &QYP DWVVQP 2. Select the desired mode by using Up or Down button. SPECO LENS EXPOSURE WHITE BAL DAY&NIGHT...
- Page 25 The camera is set to the Factory Default value. Press the Set button in the exit menu to save the current settings and exit the Set Up menu. - 24 -...
- Page 26 Check the power cable, power supply output and video Nothing appears on connection between the camera and monitor. the screen. Is the camera lens or the lens glass dirty? Clean the lens / glass with a soft clean cloth. The image on the Adjust the monitor controls, as required.
- Page 27 - 26 -...
- Page 28 - MEMO - - 27 -...
- Page 29 - MEMO - - 28 -...
- Page 30 - MEMO - - 29 -...
- Page 31 - MEMO - - 30 -...
- Page 32 200 New Highway Amityville, NY 11701 631-957-8700 1 800 645 5516 www.specotech.com...
