Speco HTD10XH Instruction Manual

960h 10x zoom series htd10xh (outdoor ir dome camera) htb10xh (weatherproof bullet camera with mount plate)
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTRUCTION
MANUAL
SPECO 960H 10x Zoom Series
Speco Technologies is constantly developing product improvements.
We reserve the right to modify product design and specifications without notice and without incurring any obligation.
HTD10XH
(Outdoor IR Dome Camera)
HTB10XH
(Weatherproof Bullet Camera with mount plate)
Rev. 12/01/2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HTD10XH and is the answer not in the manual?

Questions and answers

Related Manuals for Speco HTD10XH

Summary of Contents for Speco HTD10XH

  • Page 1 SPECO 960H 10x Zoom Series HTD10XH (Outdoor IR Dome Camera) HTB10XH (Weatherproof Bullet Camera with mount plate) Speco Technologies is constantly developing product improvements. We reserve the right to modify product design and specifications without notice and without incurring any obligation. Rev. 12/01/2013...

  • Page 2: Table Of Contents

    Precautions Contents ............1 ◑ Precautions ..........2, 3 ◑ Safety Instructions ........4 ◑ Package Contents ........5 ◑ Camera Installation ........6-9 ◑ Specifications ..........10-11 ◑ Camera Dimension ........12 ◑ Features ............13 ◑ OSD Menu Details ........14- 33 ◑...

  • Page 3: Precautions

    Precautions Do not install the camera in Do not install the camera under Do not touch the front lens of the extreme temperature conditions. unstable lighting conditions. camera. Only use the camera under conditions Severe lighting change or flicker can This is one of the most important parts of where temperatures are between cause the camera to work improperly.
  • Page 4 CAUTION CAUTION CAUTION RISK OF ELECTRIC SHOCK RISK OF ELECTRIC SHOCK RISK OF ELECTRIC SHOCK DO NOT OPEN DO NOT OPEN DO NOT OPEN CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER(OR BACK).

  • Page 5: Safety Instructions

    Safety Instructions Precautions for use ◑ This camera should be installed by qualified personnel only ◑ There are no user serviceable parts inside ◑ Do not disassemble this camera other than to make initial adjustments ◑ Use a UL approved regulated 24 volt AC or 12 volt DC power supply ◑...

  • Page 6: Package Contents

    Package Contents Please make sure that the following items are included in the Package: 1) HTD10XH • 1 Video Test Connector, Power Jack • 1 Chameleon Cover • 1 Wrench • Set Screw - 3 Tapping Screws 4x40 - 1 Hexagon Socket Screw M4x8 2) HTB10XH •...

  • Page 7: Camera Installation

    CAMERA INSTALLATION - 6 -...

  • Page 8: Camera Installation

    CAMERA INSTALLATION Compatibility 1) HTD10XH INTWM CVCJBD INTCM INTPM 2) HTB10XH CVCJBB INTJBS INTCM - 7 -...
  • Page 9 CAMERA INSTALLATION 1. HTD10XH BASE ASSEMBLY TAPPING SCREW 4X25, 3EA DOME COVER ASSEMBLY - 8 -...

  • Page 10: Camera Installation

    CAMERA INSTALLATION 2. HTB10XH CAMERA ASSEMBLY BASE ADAPTOR BRACKET TAPPING SCREW 4X25, 4EA HEXAGON SOCKET SCREW M5X10, 4EA - 9 -...

  • Page 11: Specifications

    Speco Technologies (Outdoor IR Dome Camera) 10x Zoom Lens (3.8mm~38mm) ■ HTD10XH SPECIFICATIONS HTD10XH MODEL Image Pick-Up Device 1/3'' SONY EXVIEW 960H CCD TV System NTSC Total Pixels 1,028(H) x 508(V) Effective Pixels 976(H) x 494(V) Scanning System 2:1 Interlace...

  • Page 12: Specifications

    Speco Technologies (Weatherproof Bullet Camera with mount plate) 10x Zoom Lens (3.8mm~38mm) ■ HTB10XH SPECIFICATIONS HTB10XH MODEL Image Pick-Up Device 1/3'' SONY EXVIEW 960H CCD TV System NTSC Total Pixels 1,028(H) x 508(V) Effective Pixels 976(H) x 494(V) Scanning System...

  • Page 13: Camera Dimension

    CAMERA DIMENSION 1) HTD10XH 3.94”dia 5.12”dia 2) HTB10XH 11.02” 3.46” 5.90” 5.03” 10.51” - 12 -...

  • Page 14: Features

    FEATURES High Resolution By adopting a diagonal 6MM(1/4’’) 480,000(NTSC) pixels, 520,000(PAL) Pixels SONY CCD, the camera produces clear picture quality with a horizontal resolution of 700 TV lines for color. Low light Sensitivity By adopting unique digital processing technology, it can clearly distinguish the outline and color of a subject in 0.15Lux low luminance environment.

  • Page 15: Osd Menu Details

    SETUP 1. FOCUS 2. EXPOSURE 3. WHITE BAL 4. DAY&NIGHT 5. BACKLIGHT 6. SPECO DNR 7. IMAGE ADJ 8. SPECIAL 9. RESET 10. RETURN 2. Move and select the required function using the Up and Down button. * Move the triangular indicator Up or Down to select the desired feature by pressing the Up or Down button.
  • Page 16 SETUP 1. FOCUS 2. EXPOSURE 3. WHITE BAL 4. DAY&NIGHT 5. BACKLIGHT 6. SPECO DNR 7. IMAGE ADJ 8. SPECIAL 9. RESET 10. RETURN 2. Press the SET button. >> FOCUS MODE : You can select the most suitable zoom mode. Move the arrow indicator to 'MODE' using UP and DOWN button.
  • Page 17 FOCUS 1. FOCUS MODE ONE-PUSH 2. D-ZOOM 3. ZOOM START IIIIIIIIIIIIIIIIIIIII 4. ZOOM STOP IIIIIIIIIIIIIIIIIIIII 5. ZOOM SPEED FAST 6. MIN.DISP 7. AF.INTERVAL - - - 8. ZOOM POS INIT 9. RETURN - AUTO : Select AUTO and press the SET button to confirm. Increase or decrease optical zoom (ZOOM) or digital zoom (D-ZOOM) positions using the UP or DOWN button while verifying the changes on screen.
  • Page 18 1. Press the SET button to access the main setup menu and then position the indicator over 'EXPOSURE' using the UP or DOWN button. SETUP 1. FOCUS 2. EXPOSURE 3. WHITE BAL 4. DAY&NIGHT 5. BACKLIGHT 6. SPECO DNR 7. IMAGE ADJ 8. SPECIAL 9. RESET 10. RETURN EXPOSURE 1. BRIGHTNESS IIIIIIIIIIIIIIIIIIIII 2.
  • Page 19 - HIGH : Wide range gain value adjustment. - MANUAL : Selecting gain value range.(5dB~41dB) - OFF : Disabled - LOW : Narrow range gain value adjustment. - MEDIUM : MEDIUM range gain value adjustment. - HIGH : Wide range gain value adjustment. - MANUAL : Selecting gain value range.(5dB~41dB) - OFF : Disabled - LOW : Narrow range gain value adjustment.

  • Page 20: White Balance

    2. Select a desired mode using the Up and Down buttons. SETUP 1. FOCUS 2. EXPOSURE 3. WHITE BAL 4. DAY&NIGHT 5. BACKLIGHT 6. SPECO DNR 7. IMAGE ADJ 8. SPECIAL 9. RESET 10. RETURN WHITE BAL 1. MODE 2. PUSH - - - 3.
  • Page 21 1. Select Day&Night using the Up or Down button on the Set Up menu screen. 2. Select the desired mode using the Left or Right buttons. SETUP 1. FOCUS 2. EXPOSURE 3. WHITE BAL 4. DAY&NIGHT 5. BACKLIGHT 6. SPECO DNR 7. IMAGE ADJ 8. SPECIAL 9. RESET 10. RETURN - 20 -...
  • Page 22 DAY&NIGHT 1. MODE EXTERNAL 2. DWELL TIME ----- 3. D → N LEVEL ----- 4. N → D LEVEL ----- 5. BURST 6. SMART-IR 7. RETURN >> MODE : - Auto : The mode is switched to ‘Color’ in a normal environment, but switches to ‘B/W’ mode when ambient illumination is low.
  • Page 23 1. When the SETUP menu screen is displayed, select ‘BACKLIGHT’ by using the Up and Down buttons so that the arrow indicates ‘BACKLIGHT’. SETUP 1. FOCUS 2. EXPOSURE 3. WHITE BAL 4. DAY&NIGHT 5. BACKLIGHT 6. SPECO DNR 7. IMAGE ADJ 8. SPECIAL 9. RESET 10. RETURN BACKLIGHT 1. MODE 2. LEVEL ----- 3.
  • Page 24 2. Select a desired mode using the Left and Right buttons depending on the camera purpose. >> MODE : - OFF : Not being used. - WDR : This camera provides intelligent light level control to overcome even strong backlight conditions. BACKLIGHT 1.
  • Page 25 SETUP 1. FOCUS 2. EXPOSURE 3. WHITE BAL 4. DAY&NIGHT 5. BACKLIGHT 6. SPECO DNR 7. IMAGE ADJ 8. SPECIAL 9. RESET 10. RETURN 3. Adjust the most available proportion of compensation with the ambient environment by changing the DNR mode into On and pressing the Set button.

  • Page 26: Image Adj

    2. Select the desired mode by using Up or Down button. SETUP 1. FOCUS 2. EXPOSURE 3. WHITE BAL 4. DAY&NIGHT 5. BACKLIGHT 6. SPECO DNR 7. IMAGE ADJ 8. SPECIAL 9. RESET 10. RETURN IMAGE ADJ 1. FREEZE 2. REVERSE 3.
  • Page 27 1.When the SETUP menu is displayed, select SPECIAL using the Up and Down button. 2. Select one of the mode using the Up and Down button. SETUP 1. FOCUS 2. EXPOSURE 3. WHITE BAL 4. DAY&NIGHT 5. BACKLIGHT 6. SPECO DNR 7. IMAGE ADJ 8. SPECIAL 9. RESET 10. RETURN - 26 -...
  • Page 28 SPECIAL 1. CAM TITLE 2. COMM ADJ 3. LANGUAGE 4. MOTION 5. PRIVACY 6. OSD DISPLAY 7. LSC 8. RETURN >> CAM TITLE : If you enter a title, the title will appear on the monitor. 1) If the SPECIAL menu screen is displayed, use the Up and Down buttons so that the arrow indicates ‘CAM TITLE’.
  • Page 29 >> COMM ADJ : This function sets up the camera communication status when controlling the camera through an external controlled device. CAMM ADJ 1. CAM IDGAMMA 2. PROTOCOL PELCO-D 3. BAUDRATE 9600 4. UTC DELAY IIIIIIIIIIIIIIIIIIIII 5. RETURN - CAM ID : Determines the camera's identification number(between 0 and 256). - PROTOCOL : Select the communication PROTOCOL.(SAMSUNG-T/PELCO-D/PELCO-P/BOSCH/HONEYWELL/ VICON/AD/SAMSUNG-E/PANASONIC) - BAUDRATE : You can select 2400/4800/9600/19200/38400/57600 bps.
  • Page 30 >> PRIVACY : This is used to hide certain areas on the monitor. You can designate each different 8 area. The size of a designated area can be adjusted. The color of a privacy area can be selected 15colors. When you select the return, the setting values in this function menu are saved, then get out of this menu. PRIVACY 1.
  • Page 31 Reset The camera is set to the Factory Default value. Exit Press the Set button in the exit menu to save the current settings and exit the Set Up menu. - 30 -...

  • Page 32: Trouble Shooting

    Trouble Shooting PROBLEM POSSIBLE CAUSE ☞ Check the power cable, power supply output and video Nothing appears on connection between the camera and monitor. the screen. ☞ Are the camera lens or the lens glass dirty? Clean the lens / glass with a soft clean cloth. The image on the ☞...
  • Page 33 - 32 -...
  • Page 34 - MEMO - - 33 -...
  • Page 35 - MEMO - - 34 -...
  • Page 36 200 New Highway Amityville, NY 11701 631-957-8700 1 800 645 5516 www.specotech.com...
