- Page 1 Intensifier Series Camera HT - INTB8/9/10 Please read this manual throughly before operation and keep it handy for further reference.
- Page 3 Package Contents Precautions O S D Menu Operating Your Camera MENU SET UP LENS SET UP SHUTTER SPEED WHITE BAL. INTENSIFIER NEXT CAMERA TITLE C O L O R S Y N C MOTION DET. PRIVACY REVERSE DETAIL Troubleshooting Specification Camera Set Up How to Install Warranty...
-
Page 4: Package Contents
PACKAGE CONTENTS Please make up sure that the following items are included in the package: HT - INTB CAMERA HT - INTB8 CAMERA SUNSHIELD MOUNTING SCREW MOUNTING BASE L - WRENCH USER'S MANUAL VIDEO TEST CABLE POWER PIGTAIL... - Page 5 PRECAUTIONS TO PREVENT A FIRE OR ELECTRONICAL HAZARD PLEASE USE PROPER POWER CABLE INSTALLATION SHOULD BE PERFORMED BY QUALIFIED PERSONNEL PLEASE USE A UL APPROVED REGULATED 24 VOLT AC OR 12 VOLT DC POWER SUPPLY PLEASE USE APPROPRIATE LOW VOLTAGE POWER CABLE TO PREVENT FIRE OR ELECTRICAL SHOCK.
-
Page 6: Osd Menu
◈ Function SET UP MENU OSD MENU LENS OPTION ● DC ● MANUAL SHUTTER ● OFF ● F/L ● MANUAL WHITE BALANCE ● ATW ● AWC ● MANUAL SLC - ( Speco Light Compensation ) ● OFF ● LOW ● MIDDLE ● HIGH AUTO GAIN ●... -
Page 7: Menu Set Up
Menu is adjusted by the OSD button on the camera 1. Press the SET button to access the SETUP mode. ● SETUP menu should be displayed on the monitor screen. LENS TYPE SHUTTER SPEED WHITE BAL AUTO GAIN REDUCE NOISE INTENSIFIER NEXT PAGE EXIT... - Page 8 3. MENU SETUP change by using button ● Available value or status should be displayed by pressing the Left or Right button. ● Please press the button until desired features appears. 4. When adjustment is completed, move the arrow indicator to " EXIT " and press the "SET"...
- Page 9 LENS SETUP 2. Select the desired lens type by LEFT or RIGHT button. LENS TYPE SHUTTER SPEED WHITE BAL AUTO GAIN REDUCE NOISE INTENSIFIER NEXT PAGE EXIT CAUTION You can control the brightness when DC is selected, Brightness control range will be 1~70 BRIGHTNESS Press Set to Return CAUTION...
- Page 10 SHUTTER SPEED CONTROL You can control brightness of screen by the shutter speed. ① Press the SET button to display the setup menu and move the arrow indicator to " SHUTTER " by the UP or DOWN button. ② Set " SHUTTER " to the desired mode by the LEFT or RIGHT button OFF : Deactivation LENS TYPE SHUTTER SPEED...
- Page 11 MANUAL When setting the shutter speed manually, You can select from " 1/60 " to " 1/200,000" sec LENS TYPE SHUTTER SPEED WHITE BAL AUTO GAIN REDUCE NOISE INTENSIFIER NEXT PAGE EXIT MANUAL Press SET to Return SPECO TECH MANUAL MANUAL HIGH -----...
- Page 12 You can control the BRIGHTNESS. LENS TYPE SHUTTER SPEED WHITE BAL AUTO GAIN REDUCE NOISE INTENSIFIER NEXT PAGE EXIT BRIGHTNESS Press SET to Return ③ When completed, press " SET " CAUTION CAUTION Avoid pointing the camera directly at a fluorescent lamp. When the SUTTER menu is set to FLK mode, the INTENSIFIER will not work.
- Page 13 BLC( Back Light ) 3) SLC ( Speco Light Compensation ) A built - in SR chip provides intelligent light level control to overcome severe Backlight conditions. ① Press the SET button to display the SETUP menu and move the arrow indicator to "...
- Page 14 AGC(Auto Gain 4) AGC ( Auto Gain Control ) AGC allows a brighter picture in low light conditions. Higher GAIN level will yield a brighter screen, but you might notice an increase in noise. ① Press the SET button to display the SETUP menu and move the arrow indicator to "...
- Page 15 WHITE BAL. 5) WHITE BALANCE ① Press the SET button to display the SETUP menu and move the arrow indicator to " WHITE BALANCE " by the UP or DOWN button. ② SET " WHITE BAL " to desired mode by the LEFT or RIGHT button. LENS TYPE SHUTTER SPEED WHITE BAL...
- Page 16 WHITE BAL. MANUAL : To fine adjust, select the manual mode. You can increase the red or blue factor while monitoring the difference on the screen. Set the "MANUAL" mode and press the SET button. Increase or decrease the value for RED(R-Gain) and BLUE(B-Gain), watching the color of the picture and press the SET button when you obtain the best color.
- Page 17 D N R 6) REDUCE NOISE ( Digital Noise Redution ) DNR reduce the video noise on the screen. ① Press the SET button to display the SETUP menu and move the arrow indicator to " REDUCE NOISE " by the UP or DOWN button. ②...
- Page 18 INTENSIFIER 7) INTENSIFIER Allows you to get clear images with this function under night or low light conditions. ① Press the SET button to display the SETUP menu and move the arrow indicator to " INTENSIFIER " by the UP or DOWN button. ②...
- Page 19 NEXT PAGE 8) NEXT PAGE ① Press the SET button to display the SETUP menu and move the arrow indicator to " NEXT PAGE " by the UP or DOWN button. ② SET " NEXT PAGE " to desired mode by the LEFT or RIGHT button. SPECO TECH LENS TYPE SHUTTER TYPE...
- Page 20 CAMERA TITLE CAMERA TITLE DAY / NIGHT SYNC MOTION PRIVACY REVERSE DETAIL DEFAULT PAGE 1 ③ Press SET button to access the SETUP mode. ④ You can enter up to 15 characters. Ⓐ Move the cursor to character-enter location by using LEFT or RIGHT button.
- Page 21 CAMERA TITLE ⓓ Repeat above steps until you creat the full name you want. ⓔ Select the position at which the CAMERA TITLE will be located on the screen. - Move the cursor to "POS" and press SET button. - Select the position by using the 4-directional buttons, then press the SET button to confirm the position.
- Page 22 C O L O R 2) COLOR ① Press the SET button to display the SETUP menu and move the arrow indicator to " COLOR " by the UP or DOWN button. ② SET " COLOR " to desired mode by the LEFT or RIGHT button. CAMERA TITLE DAY / NIGHT SYNC...
- Page 23 S Y N C 3) SYNC ① Press the SET button to display the SETUP menu and move the arrow indicator to " SYNC " by the UP or DOWN button. ② SET to desired mode by the LEFT or RIGHT button. CAMERA TITLE DAY / NIGHT SYNC...
- Page 24 MOTION DETECTION 4) Whenever your camera detects motion, The words "motion detected" will appear on the screen. ① Press the SET button to display the SETUP menu and move the arrow indicator to " MOTION " by the UP or DOWN button. ②...
- Page 25 MOTION DETECTION OFF : Deactivation ON : Activated - Press the SET button. - Move the arrow indicator to " AREA SET " using UP and DOWN button. And then press the SET button. - Set the areas you want to observe. AREA SEL AREA STATE DOWN...
- Page 26 PRIVACY 5) PRIVACY: To make an area that you want to be private. ① Press the SET button to display the SETUP menu and move the arrow indicator to " PRIVACY " by the UP or DOWN button. ② SET " PRIVACY " to desired mode by the LEFT or RIGHT button. CAMERA TITLE DAY / NIGHT SYNC...
- Page 27 PRIVACY NEXT PAGE CAMERA TITLE DAY / NIGHT SYNC MOTION PRIVACY REVERSE DETAIL DEFAULT PAGE 1 OFF : Deactivation ON : Activated - Press the SET button. - Move the arrow to the area you want to mask. - Set "ON" using LEFT or RIGHT button. - Press the SET button and then set the area's bounds as for MOTION detection.
- Page 28 REVERSE 6) REVERSE: ① Press the SET button to display the SETUP menu and move the arrow indicator to " REVERSE " by the UP or DOWN button. ② SET " REVERSE " to desired mode by the LEFT or RIGHT button. CAMERA TITLE DAY / NIGHT SYNC...
- Page 29 DETAIL 7) DETAIL: ① Press the SET button to display the SETUP menu and move the arrow indicator to " DETAIL " by the UP or DOWN button. ② SET " DETAIL " to desired mode by the LEFT or RIGHT button. CAMERA TITLE DAY / NIGHT SYNC...
- Page 30 DETAIL OFF : Deactivation ON : DETAIL control mode ( level 0 ~ 31 ) When the level is up, the sharpness will increase. Control this level to get your best picture quality. If the level is to high, you can get an unnatural image. RESET / RETURN 8) DEFAULT : Use to reset your camera to FACTORY DEFAULT setting.
-
Page 31: Trouble Shooting
TROUBLE SHOOTING If you have trouble when operating your camera, please check the following PROBLEM Nothing appears on the screen The image on the screen is dim. The image on the screen is dark. The camera is not working properly and the surface of the camera is hot. - Page 32 TROUBLE SHOOTING If you have trouble when operating your camera, please check the following PROBLEM The color of the picture is not matched. The image on the screen flickers. L/L mode isn't able to be selected. SOLUTION ● Check that you have properly set the "WHITE- BAL"...
- Page 33 LOW LIGHT INTENSIFIER / BUILT IN - SELECTABLE TO 128 X MODEL Image Pick-Up Device TV System Total Pixels Effective Pixels Scanning Frequency Scanning System Synchronization Resolution Minimum Illumination S / N Ratio White Balance Video Output Electronic Shutter Speed SLC( Speco Light Compensation ) Auto Gain Reduce Noise...
- Page 34 * Settings can be made using the 5 buttons on the front of the camera. * Unscrew the front of the camera to gain access to these controls and the video test connector...
-
Page 35: How To Install
HOW TO INSTALL Dimension & Installation How to install Camera adjustment... -
Page 36: Limited Warranty
VIDEO CAMERA MONITOR IR LEDs Time Labse VCR Drum Assembly & Heads DVRs TN, TT,TS, PC Series We warranty all products to be free from any manufacturing or material defects. This warranty will not extend to any products which have been subjected to misuse, neglect, accident, or improper installation, used in violation of instructions furnished by us;... - Page 37 M E M O...
