Speco HTFB4TM Instruction Manual

4mp flexible intensifier technology tvi motorized zoom focus camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTRUCTION
MANUAL
4MP Flexible Intensifier Technology
TVI Motorized Zoom Focus Camera
Speco Technologies is constantly developing product improvements.
We reserve the right to modify product design and specifications without notice and without incurring any obligation.
HTFB4TM
(Bullet Camera)
HTFD4TM
(Dome Camera)
Rev. 08/01/2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HTFB4TM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Speco HTFB4TM

Summary of Contents for Speco HTFB4TM

  • Page 1 4MP Flexible Intensifier Technology TVI Motorized Zoom Focus Camera HTFB4TM (Bullet Camera) HTFD4TM (Dome Camera) Speco Technologies is constantly developing product improvements. We reserve the right to modify product design and specifications without notice and without incurring any obligation. Rev. 08/01/2017...

  • Page 2: Table Of Contents

    Contents Contents ............2 ◑ Precautions ..........3, 4 ◑ Safety Instructions ........5 ◑ Package Contents ........6 ◑ Camera Installation ........7-10 ◑ Lens Adjustment ......... 11 ◑ Specifications ..........12,13 ◑ Camera Dimension ........14 ◑ Features ............15 ◑...

  • Page 3: Precautions

    Precautions Do not install the camera in Do not install the camera under Do not touch the front lens of the extreme temperature conditions. unstable lighting conditions. camera. Only use the camera under conditions Severe lighting change or flicker can This is one of the most important parts of where temperatures are between cause the camera to work improperly.
  • Page 4 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER(OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. ISO14001 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

  • Page 5: Safety Instructions

    Safety Instructions Precautions for use ◑ This camera should be installed by qualified personnel only ◑ There are no user serviceable parts inside ◑ Do not disassemble this camera other than to make initial adjustments ◑ Use a UL approved regulated 24 volt AC or 12 volt DC power supply ◑...

  • Page 6: Package Contents

    Package Contents Please make sure that the following items are included in the Package: 1) HTFB4TM Included Junction Box (CVCJBB) • 1 Video Test Connector, Power Jack • 1 Bracket Base • 1 Wrench • Set Screw - 4 Tapping Screws 4x25...

  • Page 7: Camera Installation

    CAMERA INSTALLATION CAMERA INSTALLATION CONNECT POWER CABLE 1. WHEN USING 12 VOLTS DC (constant voltage 500mA) P o w e r In p u t :R E D C e n te r : (+) D C 12V P owe r S upply 2.
  • Page 8 CAMERA INSTALLATION Compatibility 1) HTFB4TM INTCM 2) HTFD4TM INTWM INTCM - 8 -...
  • Page 9 CAMERA INSTALLATION 1. HTFB4TM WALL JUNCTION BOX SCREW-TAP,WHT, TP1, M4X25, TH, 4EA BRACKET ASSYEMBLY SCREW M5x10, HEXAGON SOCKET , SUS, BK, 4EA - 9 -...

  • Page 10: Camera Installation

    CAMERA INSTALLATION 2. HTFD4TM CEILING JUNCTION BASE SPONGE JUNCTION BOX ASSEMBLY TAPPING SCREW 4X25, 4EA CAMERA ASSEMBLY MACHINE SCREW 4X15, 3EA DOME COVER - 10 -...

  • Page 11: Lens Adjustment

    LENS ADJUSTMENT 1. HTFB4TM Open the cap VIDEO TEST SET UP LED LEVEL - 11 -...

  • Page 12: Specifications

    4MP FIT TVI Motorized Zoom Focus Camera 2.8-12mm MFZ Lens ■ HTFB4TM (2.8-12mm) SPECIFICATIONS IUGC5UN Sensor type 1/2.9" SONY STARVIS CMOS Sensor Effective pixels 2184(H) X 2202(V), 4.81M Pixels Total pixels 3096(H) X 2218(V), 6.87M Pixels Resolution 2560X1440 (1440p@15F) Scanning system Progressive Scan Min.

  • Page 13: Specifications

    4MP FIT TVI Motorized Zoom Focus Camera 2.8-12mm MFZ Lens ■ HTFD4TM (2.8-12mm) SPECIFICATIONS IUGE5UN Sensor type 1/2.9" SONY STARVIS CMOS Sensor Effective pixels 2184(H) X 2202(V), 4.81M Pixels Total pixels 3096(H) X 2218(V), 6.87M Pixels Resolution 2560X1440 (1440p@15F) Scanning system Progressive Scan Min.

  • Page 14: Camera Dimension

    CAMERA DIMENSION 1) HTFB4TM 9.16” 3.90” 2) HTFD4TM 5.12” 3.94” 5.12” PHOTO SENSOR HEATER HI-POWER LED - 14 - LENS CASE...

  • Page 15: Features

    TV system is switchable 'NTSC' or 'PAL' with built-in OSD. Intelligent Function ● An extraordinary technology that enables Speco Technologies TVI to become the ultimate solution by providing intelligent features based on motion detection. It also strengthens crime prevention and detection.

  • Page 16: Osd Menu Details

    COLOR BLK/WHT/YEL/CYN/GRN/MAG/RED/BLU RETURN H-POS 0~26 V-POS 0~26 H-SIZE 0~26 V-SIZE 0~26 RETURN WDR MODE LINE/FRAME ROI MODE WINDOW ZONE WINDOW USE ON/OFF H-POS 0~2560 V-POS 0~1440 H-SIZE 0~2560 V-SIZE 0~1440 WEIGHT LOW/MIDDLE/HIGH RETURN 6. SPECO DNR OFF/LOW/MIDDLE/HIGH - 16 -...
  • Page 17 How to Set Up the camera menu ● Setup Menu MENU 7. DAY&NIGHT AUTO ON/OFF SMART IR 0~20 AGC THRES 0~20 AGC MARGIN 0~20 RETURN COLOR SMART IR 0~20 RETURN EXTERN ON/OFF SMART IR 0~20 EXTERN SW LOW/HIGH D>N THRES 0~20 N>D THRES 0~20...
  • Page 18 How to Set Up the camera menu ● Setup Menu MENU POS3-Y Y LEVEL 0~20 CB LEVEL 0~20 CR LEVEL 0~20 TRANS RETURN RETURN 9. MOTION DET WINDOW WINDOW USE 0~3 WINDOW ZONE ON/OFF DET H-POS 1~80 DET V-POS 1~45 DET H-SIZE 1~80 DET V-SIZE...

  • Page 19: Menu Set Up

    * Move the triangular indicator Up or Down to select the desired feature by pressing the Up or Down button. MENU 1. LENS 2. 2-MOTOR 3. EXPOSURE 4. WHITE BAL 5. BACKLIGHT 6. SPECO DNR MIDDLE 7. DAY&NIGHT AUTO 8. IMAGE 9. MOTION 10. SYSTEM 11. EXIT...
  • Page 20 2. Select the desired lens type by pressing the Left of Right button. MENU 1. LENS 2. 2-MOTOR 3. EXPOSURE 4. WHITE BAL 5. BACKLIGHT 6. SPECO DNR MIDDLE 7. DAY&NIGHT AUTO 8. IMAGE 9. MOTION 10. SYSTEM 11. EXIT...
  • Page 21 2. Select the desired lens type by pressing the Left of Right button. MENU 1. LENS 2. 2-MOTOR 3. EXPOSURE 4. WHITE BAL 5. BACKLIGHT 6. SPECO DNR MIDDLE 7. DAY&NIGHT AUTO 8. IMAGE 9. MOTION 10. SYSTEM 11. EXIT 2.
  • Page 22 1. On the Set Up menu, Select EXPOSURE by using the Up or Down button. MENU 1. LENS 2. 2-MOTOR 3. EXPOSURE 4. WHITE BAL 5. BACKLIGHT 6. SPECO DNR MIDDLE 7. DAY&NIGHT AUTO 8. IMAGE 9. MOTION 10. SYSTEM 11.

  • Page 23: White Balance

    1. Move the triangular indicator to WHITE BAL on the SETUP menu screen using the Up and Down button. 2. Select the desired mode by using the left or Right button. MENU 1. LENS 2. 2-MOTOR 3. EXPOSURE 4. WHITE BAL 5. BACKLIGHT 6. SPECO DNR MIDDLE 7. DAY&NIGHT AUTO 8. IMAGE 9. MOTION 10. SYSTEM 11. EXIT 4.
  • Page 24 1. Move the triangular indicator to BACKLIGHT on the SETUP menu screen using the Up and Down button. 2. Select the desired mode by using the left or Right button. MENU 1. LENS 2. 2-MOTOR 3. EXPOSURE 4. WHITE BAL 5. BACKLIGHT 6. SPECO DNR MIDDLE 7. DAY&NIGHT AUTO 8. IMAGE 9. MOTION 10. SYSTEM 11. EXIT...
  • Page 25 ◆ Off : Deactivated status. ◆ HLC : This function is used to surpress or strong light source (for example, headlights of cars during nighttime) so that other subjects can be seen in more detail. If you select HCL, a submenu appears where you can make finer adjustments.
  • Page 26 You can set different levels here. 1. Move the triangular indicator to SPECO DNR by useing the Up and Down button. 2. Select the mode to use by pressing the left or Right button and OFF/LOW/MIDDLE/HIGH level selectable.
  • Page 27 1. Select Day&Night using the Up or Down button on the Set Up menu screen. 2. Select the desired mode using the Left or Right buttons. MENU 1. LENS 2. 2-MOTOR 3. EXPOSURE 4. WHITE BAL 5. BACKLIGHT 6. SPECO DNR MIDDLE 7. DAY&NIGHT AUTO 8. IMAGE 9. MOTION 10. SYSTEM 11. EXIT ◆...
  • Page 28 ◆ B/W : : 0~20 AGC MARGIN level adjustable. 7. DAY&NIGHT SMART IR. 10 IIIIIIIIIIIIIIIIIII| RETURN - SMART IR. : 0~20 smart IR level adjustable. ◆ EXTERN : It can change the color or B/W mode automatically through the connection with the ground terminal.(Option for box camera and IR camera) 7.
  • Page 29 8. IMAGE When selecting, the following submenu will appear. MENU 1. LENS 2. 2-MOTOR 3. EXPOSURE 4. WHITE BAL 5. BACKLIGHT 6. SPECO DNR MIDDLE 7. DAY&NIGHT AUTO 8. IMAGE 9. MOTION 10. SYSTEM 11. EXIT Here you can optimise the image quality by adjusting different options.
  • Page 30 MOTION function. MENU 1. LENS 2. 2-MOTOR 3. EXPOSURE 4. WHITE BAL 5. BACKLIGHT 6. SPECO DNR MIDDLE 7. DAY&NIGHT AUTO 8. IMAGE 9. MOTION 10. SYSTEM 11. EXIT...
  • Page 31 1.When the SETUP menu is displayed, select SYSTEM using the Up and Down button. 2. Select one of the mode using the Up and Down button. MENU 1. LENS 2. 2-MOTOR 3. EXPOSURE 4. WHITE BAL 5. BACKLIGHT 6. SPECO DNR MIDDLE 7. DAY&NIGHT AUTO 8. IMAGE 9. MOTION 10. SYSTEM 11. EXIT...
  • Page 32 10. SYSTEM COMM OUTPUT IMAGE RANGE FULL COLOR SPACE HD-cbcr AUDIO MIC NOT USED COLOR BAR LANGUAGE CAM TITLE RESET RETURN ◆ COMM : This menu id used for RS-485 communication. Users are able to select 'CAM ID(0~255)' and 'BAUDRATE(2400/4800/9600/57600/115200). - CAM ID : 1 - BAUDRATE : 9600 ◆...

  • Page 33: Trouble Shooting

    Trouble Shooting PROBLEM POSSIBLE CAUSE Nothing appears on ☞ Check the power cable, power supply output and video the screen. connection between the camera and monitor. ☞ Are the camera lens or the lens glass dirty? Clean the lens / glass with a soft clean cloth. The image on the ☞...
  • Page 37 200 New Highway Amityville, NY 11701 631-957-8700 1 800 645 5516 www.specotech.com...
