3.6.11 Audio Output Connector (J16)

Part Description
RCA 4x2 female
Mating Connector
Standard audio cable with RCA connectors

3.6.12 S/PDIF Digital Connector (J17)

Part Description
RCA 1x2 female
Mating Cable
Standard S/PDIF cable with RCA connectors

3.6.13 SD Connector (J18)

Part Description Manufacturer Part Number
SD 8-bit, 2 GB SANDISK
Mating Connector
2 GB SANDISK

3.6.14 ADC Connector (J19)

This is not populated.
Part Description
40-pin high speed socket
Mating Connector
ADSP-SC589 EZ-Board® Evaluation System Manual
Manufacturer Part Number
Switchcraft
Manufacturer Part Number
Switchcraft
MHC-W21-601
SDSDB-2048-A11
Manufacturer Part Number
SAMTEC QSH-020-01-L-D-DP-A
PJRAS4X2U
PJRAS1X2S02X
