2 Using the ADSP-SC589 EZ-Board

This chapter provides information to assist you with development of programs for the ADSP-SC589
EZ-Board evaluation system.
The following topics are covered.
Package Contents
ADSP-SC589 EZ-Board
Default Configuration
EZ-Board Installation
EZ-Board Session Startup
Evaluation License
DDR3 Memory
SPI Flash
SPI EEPROM Interface
Audio Interface
S/PDIF Interface
Housekeeping ADC
CAN Interface
UART Interface
Ethernet Interface
USB Interface
PCI Express Interface
Link Ports Interface
Current Monitor Interface
Programmable Oscillator
SD Interface
Debug Interface
Power-On-Self Test
Expansion Interface
Power Architecture
