Page 2: Table Of Contents
Table of Contents LS-3T LS-5T LS-7T Congratulations on the purchase of your new motorized treadmill. To help ensure an enjoyable and trouble-free operation of your new treadmill, we strongly suggest you read this manual carefully and follow its recommendations. Important Safety and .....1 Preset Program User Instructions... - Page 3 IMPORTANT SAFETY INSTRUCTIONS DANGER To reduce the risk of electrical shock, always unplug this appliance from the electrical outlet before cleaning. ♦ Keep electrical cord away from heated surfaces. ♦ Keep hands clear of all moving parts. Never place hands or feet under ♦...
- Page 4 USER PRECAUTIONS Read the following carefully before using your treadmill ♦ Always stretch your muscles before commencing any exercise ♦ This treadmill is equipped with a safety key – Always clip the program. Warm up slowly by walking at a slow speed. Increase cord attached to the safety key to a part of your clothing so the workout intensity gradually until you reach your desired workout safety key will properly detach from the console, therefore...
- Page 5 ASSEMBLY INSTRUCTIONS After unpacking the fitness equipment, examine it carefully for possible damage. If there is any damage or there are missing parts, please contact your retailer or an authorized repair facility for assistance. 1. Since your treadmill is a heavy piece of equipment, we recommend that after removing the box top, you slit the corners of the lower carton and fold down the sides.
- Page 6 ASSEMBLY INSTRUCTIONS After unpacking the fitness equipment, examine it carefully for possible damage. If there is any damage or there are missing parts, please contact your retailer or an authorized repair facility for assistance. 1. Since your treadmill is a heavy piece of equipment, we recommend that after removing the box top, you slit the corners of the lower carton and fold down the sides.
-
Page 7: Assembly Instructio S N
ASSEMBLY INSTRUCTION FIG1 FIG2 FIG3 Upright Assembly 1. Carefully lift (as shown in Fig 2) the frame (#7) from the rear. Remove console (#13), handlebars (#14) first then remove the styrofoam (#3 & 4) from underneath. 2. Lower the frame carefully. 3. -
Page 8: Console Operation
CONSOLE OPERATION Button description Display START / STOP : Display : The console is One (1) large LCD This will “START” and “STOP” the treadmill. with Five (5) separate windows for data. There is also an Emergency “STOP” switch the (SAFETY KEY). Data : SPEED up Time : 88:88... - Page 9 CONSOLE OPERATION Introduction : To start treadmill, first ensure power cord is plugged in, the power switch is turned to the “ON” position and the “Safety Key” is attached to your clothing and to the console. Do not stand on the running belt at this time. Stand on the side rails. The treadmill has one (1) manual and five (5) preset programs (P1 –...
- Page 10 CONSOLE OPERATION Button description Display START / STOP : This will “START” and “STOP” the treadmill. Display : The console is One (1) large LCD There is also an Emergency “STOP” switch the (SAFETY KEY). with Five (5) separate windows for data. SPEED up Data : This will select program and level in set up mode before starting.
- Page 11 CONSOLE OPERATION Introduction : To start treadmill, first ensure power cord is plugged in, the power switch is turned to the “ON” position and the “Safety Key” is attached to your clothing and to the console. Do not stand on the running belt at this time. Stand on the side rails. The treadmill has one (1) manual and five (5) preset programs (P1 –...
-
Page 12: Preset Program
PRESET PROGRAM Each program is divided into ten (10) segments and has three (3) different levels. The preset workout time is thirty (30) minutes. km/h Speed program MPH Speed program... - Page 13 PRESET PROGRAM Each program is divided into ten (10) segments and has three (3) different levels. The preset workout time is thirty (30) minutes. km/h Speed program Incline program MPH Speed program Incline program...
-
Page 14: Maintenance
Belt lubrication Use only 100% Silicone and avoid using aerosol silicone sprays which include additives and petroleum distillates. One ounce of Silicone should be used for each application. LifeSpan offers 100% silicone lubricant that can be ordered at www.lifespanfitness.com. The running belt should be lubricated every 3 months (regardless of use) or every 50 hours of use, whichever comes first. - Page 15 MAINTENANCE Folding/Unfolding LS-7T: WARNING Before folding, please put the incline value to zero (0) level. Fold up: Release to unfold: On right side On right side of handlebar of handlebar 1. Raise the frame. 1. Pull out the knob for locking. 1.
-
Page 16: Warranty
LIMITED WARRANTY LS Series Folding Treadmills Treadmill 90 Days Motor: 90 Days 90 Days 90 Days Contact 877-204-1009. After the 90 Day Warranty period, please go to www.LifeSpanFitness.com and click online customer support or call 801-973-9913 ext 4.
