INSYS GSM 4.3
In order to execute a switch command with
a previsouly assigned clear text name, use
the command
Replace <text> with the repsective clear
text name.
If you don't use a pulse output, but a
switch output, replace <oper> with the
operator "1" or "On" to enable or "0" or
"Off" to disable the output.
In order to pulse the output 1 three times
for example and if it has been assigned as
in above example before, use the command
In order to enable output 2 for example and
if it has been assigned as in above example
before, use the command
In order to disable output 2 for example and
if it has been assigned as in above example
before, use the command
You can also send the SWITCH command via SMS as AT command to the INSYS
GSM 4.3, as described in the Operation via SMS section. You can then also do
without the prefix AT**.
12.20 Activate Switching / Querying of the Outputs / Inputs
via DTMF
The outputs at the INSYS GSM 4.3 can be switched via the DTMF tones of a con-
ventional telephone. The inputs can also be queried via DTMF tones. The input
states as well as the responses of the switching processes will be transformed
acoustically into tone sequences of well differentiated high and low tones.
Configuration with HSComm
In order to enable the DTMF function, activate on the "Basic Settings"
tab on the "GSM Connection" panel the check box "DTMF processing".
After changing the DTMF settings, a reset must be performed that the
changes become effective. For this, clock on the "Reset" button in the
field on the right.
AT**SWITCH <text>
[<oper>]
AT**SWITCH Pump
AT**SWITCH LightON 1
AT**SWITCH LightON 0
Functions
