INSYS GSM 4.3
Configuration with AT commands
In order to configure the outputs, use the
command
Replace the parameters as follows:
<output> with
1 for control output 1
2 for control output 2
if the information is missing, output 2 is
used
<man>, manual activation (AT/SMS/DTMF)
with
0 for not released
1 for released
<ri>, switching on incoming call (RING
signal) with
0 for not enabled
1 for enabled
2 for modem connection (DCD) active
<net>, switching on loss of GSM network
with
0 for not enabled
1 for enabled (only if AT**GSMREQ=1).
<alarm>, switching on alarm on respective
alarm input with
0 for not enabled
1 for enabled
In order to enable output 1 "manually", use
the command
In order to disable output 2 "manually", use
the command
In order to pulse output 1, use the com-
mand
Replace <nn> with the desired number of
pulses. The pulse interval is approximately
one second.
AT**OUTPUT<output>=<ma
n>[,<ri>,<net>,<alarm>
]
AT**Out1=1
AT**Out2=0
AT**OUT1=PULSE<nn>
Functions
