Automatic Call Acceptance; Selective Call Acceptance - insys icom GSM 4.3 Manual

Functions

12.14 Automatic Call Acceptance

With the automatic call acceptance, the INSYS GSM 4.3 accepts every call after the
configured number of ring tones.
Configuration with HSComm
In order to enable the automatic call acceptance, activate on the "Basic
Settings" tab on the "GSM Connection" panel the check box "auto an-
swer".
Enter the desired number of ring tones, after which the INSYS GSM 4.3
picks up into the entry field "number of rings before answer".
Configuration with AT commands
In order to enable the automatic call accep-
tance, use the command
In order to disable the automatic call accep-
tance, use the command
In order to configure the number of ring
tones, after which the INSYS GSM 4.3 ac-
cepts the call, use the command
Replace <n> with the number of ring tones
(<n> = 2...255).
In order to query the state of this function,
use the command

12.15 Selective Call Acceptance

The selective call acceptance enables to define, which calls are accepted by the
INSYS GSM 4.3. If the selective call acceptance is activated, the INSYS GSM 4.3
will only accept calls from previously defined callers. The INSYS GSM 4.3 will iden-
tify the caller via CLIP. This must, however, be supported by the network provider.
The list of phone numbers of the INSYS GSM 4.3 for identifying the callers has 30
storage locations altogether.
The INSYS GSM 4.3 checks in the phone number transmitted via CLIP, whether
one of the numbers stored in the list is contained. The check will be started "from
right", i.e. the end of the phone number transmitted via CLIP. This enables to rec-
ognize a phone number even if "+49" or "0049" or a different prefix has been put
in front. Moreover, the number stored for recognition can remain variable using
"wildcards" at certain positions. The stored phone number must not contain sepa-
rators, like hyphens between area code and phone number for example.
56
ATS0=2
ATS0=0
ATS0=<n>
ATS0?
INSYS GSM 4.3
